0.1 ~ 2.4ghz Rf Power Meter Frequency Range 100 ~ 2400 Mhz -65 ~ +0 Dbm 1nw-1w

US $33.02

hONG KONG, Hong Kong
Jun 9th

Open on mobile:
QR code

0.1-2.4GHz radio frequency power meter -65 - +0 dBm 1nW-1W Description: Features: HP360 is a RF power meter, the meter button to complete the operation by the advantages: simple structure, easy to use, stable and reliable performance, high sensitivity and measurement speed and so on. 2, the application: ? RF power measurement; ? instrument calibration; 3, the technical parameters: No. Item Parameter Unit Remark A measurement power range -65 ~ +0 dBm (external RF attenuator can be extended to 100dBm) 2 Resolution 0.1 dBm power measurements 3 measurement frequency range 100 ~ 2400 MHz 4 measuring power 1nW ~ 1W 5 7 ~ 12 VDC operating voltage 6 Operating current <50 mA 7 Operating temperature -40 °C ~ 65 °C Celsius 8 Storage temperature -40 °C ~ 65 °C Celsius 9 size 55 * 45 * 10 mm Length X Width X Height 4, the interface displays instructions: (1) Unit Description: dBm; (2) Key Description: FUN: function keys; MODE: set to change the interface; SEL: from plus key or minus key to self; 4.1, the display of measurement data Interface display font: The first line of "RF-POW -65.5 dBm" The second line "110uV 0nW" Note: The values are displayed dBm signal, the input voltage, the input power. 4.2, set the RF power attenuation values Interface display font: The first line of "RF Attenuator" The second line "SUB 00.0dB" Key operation: FUN: function keys; (select subtraction direction) is displayed as a minus SUB display ADD to add. (Long press FUN key to save the set dB value) SEL: from plus key or minus key to self; Note: Different external RF power attenuator, set the appropriate attenuation coefficient studying the correct power parameters. V. wiring P1 wiring definition: No. Symbol Meaning 1 VDD positive power module (7V ~ 12V) 2 GND negative power module P2 wiring definition: No. Symbol Meaning 1 RF input RF signal 2 GND negative power electronic scales Comment: First, dB is a pure counts: For power, dB = 10 * lg (A / B). For voltage or current, dB = 20 * lg (A / B). dB meaning actually be easier, is to a large (followed by a long string of 0's) or small (in front of a long list of zero) number of relatively brief that out. Such as: X = 1000000000000000 (Total 15 0) Can be expressed as: 10lgX = 150dB X = 0.000000000000001 Can be expressed as: 10lgX = -150 dB dBm definition is miliwatt (milliwatts). 0 dBm = 1mw; dBw defined watt. 0 dBW = 10lg1 W = 10lg1000 mw = 30 dBm. dB power units are always defined by default to 10lg of dollars. Of course, in some cases you can use the signal strength (Amplitude) to describe the functionality and power, this time with 20lg to count. Whether or signal processing control areas are like. For example, sometimes you can see the expression dBmV. Package Contents 100% Brand New 1 x 0.1-2.4GHz radio frequency power meter -65 - +0 dBm 1nW-1W We can also wholesale if you need a large quantity of item please contact us :) Shipping Info : We only accept your Paypal Address,Please Make sure it's 100% right. The items you ordered will be shipped out in 1 business day by Air Mail when your payment is clear. Country Delivery Time Working Days (not including holiday) 5-7 8-10 11-14 15-19 20-22 >25 Working Days + Saturday + Sunday 5-9 10-14 15-20 21-25 26-30 >35 United States Rate (item arrived) 9% 50% 21% 13% 7% Refund or Resend United Kingdom Rate (item arrived) 10% 62% 20% 3.5% 4.5% Refund or Resend Australia Rate (item arrived) 23% 50% 13% 8% 6% Refund or Resend France Rate (item arrived) 1.5% 20.5% 45% 23% 10% Refund or Resend Germany Rate (item arrived) 5.5% 25% 35% 19% 15.5% Refund or Resend Canada Rate (item arrived) 0.0% 44% 35% 18% 3% Refund or Resend Spain Rate (item arrived) 1.5% 25% 50% 14% 9.5% Refund or Resend Payment : We accept PayPal only. All major credit cards are accepted through secure payment processor PayPal. Payment must be received within 7 days of auction closing. If you have bought multiple items from me, you can send me one payment for all the items instead of paying for them individually. When you click the Pay Now button, eBay will automatically determine if there are other items you have won or purchased from me and will combine them for your review. Feedback We maintain high standards of excellence and strive for 100% customer satisfaction! Feedback is very important to us. We request that you contact us immediately BEFORE you give us neutral or negative feedback, so that we can satisfactorily address your concerns. We greatly appreciate your POSITIVE feedback. Please do NOT leave negative feedback without asking for help.We will try our best to solve any problem. If you have any questions, please feel free to contact us by ebay message. We will reply you within 48 Hours. Refund&Reship: If you are dissatisfied with our item or service, then please follow the good eBay practice to contact us by ebay message before leaving any feedback. We are committed to resolve all issues in a friendly and satisfactory manner. We always reply to ebay messages within 1-2 business days. If you do not get a response from us, then please check your ebay message. we only reply ebay message, no send email. Original and return Shipping Info fee will not be refunded or reimbursed under all circumstances. You must agree and acknowledge this term if you bid for this item. Therefore, please do not complain about having to ship back at your own expense. Contact US:: If have any question, Please contact us by ebay message(no e-mail). Reply within 24hours. We care about our valued buyers, if you have any questions, our Customer Service staffs will be very glad to help you. We try our best to reply to your emails as soon as possible, however, due to high volume of daily incoming emails and time zone difference, we may not be able to reply your emails immediately. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	UNbrandes
MPN	does not apply
UPC	does not apply
