10 Sets X Sn-eg8010 Pure Sine Wave Inverter Professional Chip, Ic

US $18.00

Hongkong, Hong Kong
Jan 29th

Open on mobile:
QR code

SIBO 10 sets x SN-EG8010 Pure sine wave inverter professional chip, IC SN-Gear Rack Product Description: EG8010 is a digital, function very well built deadband control, pure sine wave inverter generator chip , used in DC-DC-AC power conversion architecture or two DC-AC single-stage frequency transformer Boost architecture , external 12MHz crystal oscillator, can achieve high accuracy, distortion and harmonics are very small pure sine wave inverter 50Hz or 60Hz ASIC . The chip using CMOS technology , the internal integration SPWM sine generator, dead-time control circuit , the amplitude factor multiplier, soft-start circuit , protection circuit , RS232 serial communication interface and 12832 Serial LCD driver module and other functions. Features: * 5V single power supply * Pin set four kinds of pure sine wave Output frequency : 50Hz pure sine wave of fixed frequency pure sine wave 60Hz fixed frequency 0-100Hz pure sine wave frequency adjustable 0-400Hz pure sine wave frequency adjustable * Unipolar and bipolar modulation * Comes with deadband control , pin set four kinds of dead time : 300nS Deadtime 500nS 1.0uS deadtime deadtime deadtime 1.5uS * External 12MHz crystal oscillator * PWM carrier frequency of 23.4KHz * Voltage, current, temperature feedback real-time processing * Overvoltage, undervoltage , overcurrent , overheating protection function * Pin to set the soft start mode 1S response time * Serial communication to set the output voltage, frequency and other parameters * 128 * 32 external serial LCD module displays the inverter voltage, frequency , temperature, and current and other information * According to the customer's application to modify Yi Jing Microelectronics provide the corresponding function or parameter Application areas: * Single-phase pure sine wave inverter * PV inverters * Wind Power Inverter * Uninterruptible power supply UPS Systems * Digital Generator System * IF power * Single- phase motor speed controller * Single- phase inverter * Sinewave dimmer * Sine wave voltage regulator * Sine wave generator Package including: 10 pcs x SN-EG8010 Pure sine wave inverter professional chip, IC Payment Pay by paypal only. Delivery details To United States, 3~10 days, to other country, 15~40 days. Contact us Pls contact us by ebay contact.We will reply you in 24 hours. Engineered for professional eBay sellers!
