10w Square 6500k White Led Light 950lm 120 Degree 10vdc-12vdc

US $120

default, default, Hong Kong
Jan 29th

Open on mobile:
QR code

10W Square 6500K White LED Light 950LM 120 Degree 10VDC-12VDC Features Highest flux per LED family in the world Very long operating life (up to 100k hours) Lambertian radiation pattern More energy efficient than incandescent and most halogen lamps Low voltage DC operateda Cool beam, safe to the touch Fully dimmable No UV Superior ESD protection lower Rth RoHS compliant — Lead-free Instant light (less than 100ns ) Applications Portable (flashlight, bicycle) Reading lights (car, bus, aircraft) Orientation Mini-accent Decorative Fiber optic alternative Appliance Sign and channel letter Architectural detail Cove lighting Automotive exterior (Stop-Tail-Turn,CHMSL,Mirror side repeat) Edge lit signs (Exit, point of sale) Specifications: Emitting Colour: White 6500K Reverse Voltage: 5.0 V DC Forward Voltage: Typical: 10V Max: 12VDC DC Forward Current: 1000mA Luminous Intensity: 950lm Viewing Angle: 120 - 140 Degree Lead Soldering Temp:260oC for 5 seconds Intensely Bright Absolute Maximum Rating Parameter Symbol Value Units DC Forward Current I F 1000 mA Peak Plused Current (@1kHz ,10% duty cycle) IFP 1500 mA Reverse Voltage VR 15 V Junction Temperature TJ 125 ° ESD Classification (HBM) --- Class 2 --- Storage Temperature Tstg -40-110 ° Operating Case Temperature Topr -40-110 ° Soldering Temperature Tsol 260 ° Electro-Optical Characteristics (Ta=25°C) Parameter Symbol Min. Typ. Max. Units Viewing Angle 2θ1/2 --- 120 --- Degree Luminous Flux(@1000mA) Φ --- 950 --- lm Forward Voltage(@1000 mA) VF 9 --- 12 V Correlated Color Temperature CCT --- 6500 --- K Thermal Resistance Junction-case RθJ-C --- 15 --- ° Notes: 1. Proper current derating must be observed to maintain junctiontemperature below the maxium. 2. LEDs are not desinged to be driven in reverse bias. 3. Lebelight maintains a tolerance of ±10% on flux measurements. 4. Lebelight maintains a tolerance of ±0.1V on forward voltage measurements. 5. CCT ±5% tester tolerance. 6. Typical Color Rendering Index (CRI) is 75 Payment We accept Paypal only. Other payment methods are not accepted. Payment must be received within 7 days after the auction ending. We do not responsible for any custom duty or import tax. Shipping Shipping cost is free to Worldwide but if you want ship by registered air mail the extra cost is fixed $1.50 for any quantity or if order over $20.00 will ship by registered air mail. Delivery Time is approx. 12-25 business days to most US / UK / AU destinations. Country Approx. Delivery time United States / United Kingdom / Australia/Canada 12-18 working days France / Spain / Germany/ Europe/ South America 15-30 working days Russia / Brazil /Italy / 20-35 working days Nigeria, Vietnam, Philippines, India,Lithuania,Latvia, Kazakhstan,Croatia,Ukraine, 20-35 working days Orders will ship out within 1-2 business days after receiving the payment. Delivery will be made by Airmail from Hongkong. All our items will be shipped to buyer's PayPal address, please confirm your address on PayPal before you bid. Delivery time depends on destination and other factors , If you don't receive items over 30 business days , please notify us. We will not responsible for any wrong or undeliverable address. Returns All item are test and well packed before posting. Returned items must not have any signs of abuse or intentional damage. The returned item has to be in its original condition. Returns are accepted within 15 days of receipt. All the shipping and handling is not refundable. If you have any problem, Please Contact Us as soon as possible. We will solve the problem together. Feedback Policy We appreciate your feedback, if you are satisfied with our service, please rate the details of the transaction (Detailed Seller Ratings) on eBay with a "PERFECT Five STARS" and leave us a posit!ve feedback. Our system will automatically do the same for you.If you have any questions, please contact us first, simply leaving negat!ve or neutra! feedback can't solve the problem. Our email address leddna.ebay(at)gmail.com normally we will reply your email within 24 hours, weekend within 48 hours. We treasure our loving customer. If you have any problems, we are very glad to help you. We greatly appreciate your positive feedback and will do the same. Do not leave negat!ve feedback before you contact us Customer Services If you have any question, please feel free to contact us through eBay and we will reply you asap. DESCRIPTION PAYMENT SHIPPING RETURN POLICY CONTACT US Search Shop Category ◆ Store Home ► CREE ◈ XM-L2 ◈ XM-L ◈ XP-G2 ◈ XT-E ◈ MC-E ◈ XP-G ◈ XR-E ◆ SinkPad ◆ Ultra Violet LED ◆ LED Aquarium / Grow Light ► 1/3/5/10/20/30W HIGH POWER LED ◈ 1W ◈ 3W ◈ 5W ◈ 10W ◈ 20W ◈ 50W ◆ 50W/100W/150W HIGH POWER LED ◆ LED Floodlight 10W-100W ► LED Strip Light ▷ 3528 SMD LED Strip ♢ Waterproof ▷ 5050 SMD LED Strip ♢ Waterproof ◈ PVC LED Strip 24/48/90/120cm ◆ LED Light Bulb ◆ LED Power Supply / Driver ◆ LED Dimmer / Controller ◆ Alu. Heat Sink ◆ Alu. PCB Circuit Board ◆ DIY LED PRODUCTS ► LED Lens ◈ CREE Lens ◈ 1w-100w Lens ► SMD LED ◈ PLCC-2 3528 SMD LED CHIP ◆ PLCC-6 5050 SMD LED CHIPs ► 8/10mm 0.5w Power LED ◈ 0.5w 8/10mm Strawhat LED 140° ◈ 0.5w 8/10mm Round LED 55° ◈ 0.5w 10mm Bullet LED 12° ► 5/8/10mm DIP LED ▷ 5mm DIP LED ♢ 5mm Round LED ♢ 5mm Strawhat LED ◈ 10mm DIP LED ► 3/5mm Piranha Flux LED ◈ 5mm 0.5W Piranha Flux LED ◆ Other Hot Item 3W RED 80lm 650nm-660nm LED Plant Glow Light USD 2.0 Cree XR-E Q5 Emitter High Power LED 228lm w/ 20mm base USD 2.45 1W Warm White LED 90lm w/ Alu. 20mm Star Base USD 1.0 NEW! Cree Single-Die XM-L LED T6 w/ 16mm Round Base USD 4.45 2P x 30CM Aluminium PCB Circuit Board for 6 x 1w,3w,5w LED in Series USD 3.0 New List Item Cree XML2 XM-L2 LED T6-3A Neutral White 5000-5350K on SinkPad 20mm Copper USD 4.99 Cree XML2 XM-L2 LED T6-3A Neutral White 5000-5350K on Aluminimun 16mm Round Base USD 3.99 10PCS x SinkPad 10mm COPPER Base for Cree XM-L /XM-L2 USD 15.0 Cree XBD XB-D R4-1A Cool White LED 16mm Round Base USD 0.99 3W Ultra Violet UV 420nm-425nm LED Emitter 6-8lm Aquariums/Plants USD 0.99 2PCS x Meanwell LDD 700H DC - DC Constant Current Step-Down LED Driver USD 14.99 5PCS x 60 Degree 21mm Reflector Collimator LED Lens For Cree XML XM-L LED USD 2.99 5PCS x 60 Degree 21mm Reflector Collimator LED Lens For Cree XML XM-L LED USD 2.99 Cree XP-G R5 Cool White Emitter LED 14mm round base USD 0.99 Cree XTE XT-E Cool White LED 14mm Round Base - Up to 380lm@5W USD 1.99 ENB 3x18650 1A 18650 Li-ion Battery USB Emergency Charger Power Bank USD 9.99 10W-100W LED Adapter w/ 53mm Fixed Bracket and 44mm Reflector Collimator LEN USD 4.99 AC110-240V 10W Watt LED Flood-light 500LM Blue Color USD 9.99 NEW! CREE XTE XT-E Royal Blue 450nm-460nm LED 14mm round base / 20mm star base EUR 2.25 12V Warm White 24 Piranha LED, LED Panel Module Energy Saving Panel Light USD 3.99 New! Cree XM-L2 XML2 LED U2-1C on 20mm Copper Round Base USD 4.99 10W Square 6500K White LED Light 950LM 120 Degree 10VDC-12VDC USD 1.99 Cree XM-L2 XML2 LED U2-1C 6000k-7000k on 16mm Round Base USD 2.99 5PCS x SinkPad 10mm COPPER Base for Cree XM-L /XM-L2 USD 8.0 50PCS 5630/5730 0.5W LED Chip - Warm White Color - 50lm USD 4.99 3W Ultra Violet UV Power LED 365nm Emitter USD 12.0 Cree XM-L2 XML2 LED U2-1C 6000k-7000k on 20mm Star Base USD 3.49 5W Ultra Violet UV Power LED 365nm Emitter USD 20.0 Cree XML2 XM-L2 LED T6-3A Neutral White 5000-5350K on SinkPad 16mm Copper USD 4.99 Help & Info Payment Policy Shipping Policy Return Policy FAQ About Us QR Code 10W Square 6500K White LED Light 950LM 120 Degree 10VDC-12VDC Features Highest flux per LED family in the world Very long operating life (up to 100k hours) Lambertian radiation pattern More energy efficient than incandescent and most halogen lamps Low voltage DC operateda Cool beam, safe to the touch Fully dimmable No UV Superior ESD protection lower Rth RoHS compliant — Lead-free Instant light (less than 100ns ) Applications Portable (flashlight, bicycle) Reading lights (car, bus, aircraft) Orientation Mini-accent Decorative Fiber optic alternative Appliance Sign and channel letter Architectural detail Cove lighting Automotive exterior (Stop-Tail-Turn,CHMSL,Mirror side repeat) Edge lit signs (Exit, point of sale) Specifications: Emitting Colour: White 6500K Reverse Voltage: 5.0 V DC Forward Voltage: Typical: 10V Max: 12VDC DC Forward Current: 1000mA Luminous Intensity: 950lm Viewing Angle: 120 - 140 Degree Lead Soldering Temp:260oC for 5 seconds Intensely Bright Absolute Maximum Rating Parameter Symbol Value Units DC Forward Current I F 1000 mA Peak Plused Current (@1kHz ,10% duty cycle) IFP 1500 mA Reverse Voltage VR 15 V Junction Temperature TJ 125 ° ESD Classification (HBM) --- Class 2 --- Storage Temperature Tstg -40-110 ° Operating Case Temperature Topr -40-110 ° Soldering Temperature Tsol 260 ° Electro-Optical Characteristics (Ta=25°C) Parameter Symbol Min. Typ. Max. Units Viewing Angle 2θ1/2 --- 120 --- Degree Luminous Flux(@1000mA) Φ --- 950 --- lm Forward Voltage(@1000 mA) VF 9 --- 12 V Correlated Color Temperature CCT --- 6500 --- K Thermal Resistance Junction-case RθJ-C --- 15 --- ° Notes: 1. Proper current derating must be observed to maintain junctiontemperature below the maxium. 2. LEDs are not desinged to be driven in reverse bias. 3. Lebelight maintains a tolerance of ±10% on flux measurements. 4. Lebelight maintains a tolerance of ±0.1V on forward voltage measurements. 5. CCT ±5% tester tolerance. 6. Typical Color Rendering Index (CRI) is 75 We accept Paypal only. Other payment methods are not accepted. Payment must be received within 7 days after the auction ending. We do not responsible for any custom duty or import tax. Shipping cost is free to Worldwide but if you want ship by registered air mail the extra cost is fixed $1.50 for any quantity or if order over $20.00 will ship by registered air mail. Delivery Time is approx. 12-25 business days to most US / UK / AU destinations. Country Approx. Delivery time United States / United Kingdom / Australia/Canada 12-18 working days France / Spain / Germany/ Europe/ South America 15-30 working days Russia / Brazil /Italy / 20-35 working days Nigeria, Vietnam, Philippines, India,Lithuania,Latvia, Kazakhstan,Croatia,Ukraine, 20-35 working days Orders will ship out within 1-2 business days after receiving the payment. Delivery will be made by Airmail from Hongkong. All our items will be shipped to buyer's PayPal address, please confirm your address on PayPal before you bid. Delivery time depends on destination and other factors , If you don't receive items over 30 business days , please notify us. We will not responsible for any wrong or undeliverable address. All item are test and well packed before posting. Returned items must not have any signs of abuse or intentional damage. The returned item has to be in its original condition. Returns are accepted within 15 days of receipt. All the shipping and handling is not refundable. If you have any problem, Please Contact Us as soon as possible. We will solve the problem together. We appreciate your feedback, if you are satisfied with our service, please rate the details of the transaction (Detailed Seller Ratings) on eBay with a "PERFECT Five STARS" and leave us a posit!ve feedback. Our system will automatically do the same for you.If you have any questions, please contact us first, simply leaving negat!ve or neutra! feedback can't solve the problem. Our email address leddna.ebay(at)gmail.com normally we will reply your email within 24 hours, weekend within 48 hours. We treasure our loving customer. If you have any problems, we are very glad to help you. We greatly appreciate your positive feedback and will do the same. Do not leave negat!ve feedback before you contact us If you have any question, please feel free to contact us through eBay and we will reply you asap. Copyright of LEDDNA. All rights reserved. Powered by SoldEazy Desktop Mobile Buy Watch
