1200w 20a Dc Converter Boost Power Supply Module 8-60v 12v Step-up12-83v 24v 48v

US $25.88

???, ???, China
Jun 9th

Open on mobile:
QR code

Description Input voltage: 8-60V Input Current: 20A Quiescent current: 15mA (12V liter 20V, the output voltage, the higher the current will increase too quiet) Output voltage: 12-80V continuously adjustable Output Current: 20A MAX Over 15A, please enhance heat dissipation (input, output pressure related, the greater the pressure the smaller the output current) Constant Range: 0.5-20A Output Power: Input voltage * 20A, such as: input 12V * 20A = 240W, input 24V * 20A = 480W, Enter 36V * 20A = 720W, input 48V * 20A = 960W, input 60V * 20A = 1200W If you need more power, you can use two modules in parallel, such as the output to 30A, two modules can be used in parallel, The current per module can be adjusted to 15A. Working temperature: -40 to + 85 degrees (ambient temperature is too high, please enhance heat dissipation) Operating frequency: 150KHz Conversion efficiency: up to 95% (efficiency and input and output voltage, current, pressure related) Overcurrent protection: Yes (with reduced flow adjustment, adjustable output current limit, current exceeds the current limit, the output current is automatically reduced to a minimum 5A, vary according to the nature of the load current will be.) Short circuit protection: Yes (input 20A fuse) double short circuit protection, the use of more security. Input reverse polarity protection: None, (if necessary, please enter the string into the diode) Output Counter filling: Yes, for charging plus blocking diode is not required. Installation: four 3mm screws Connection: solderless terminals output Module dimensions:116x52x15mm Weight: 300 g Package Include: 1pcs 1200W 20A DC Converter Boost Power Supply Module 8-60V 12v Step-up12-83V 24v 48v Dear Buyer: Contact us: We have much more products, if you need or have any question ,please contact us first .We will try our best to serve .Welcome to wholesale and to be our parter. Thank you so much! Shipping: We Ship to Worldwide, but Italy Russia Nigeria, Brazil will take long delivery time . Before buying, Please make sure your address is correct. Or not, please correct it before payment Ship to worldwide from Hong Kong within 12-24 hours after payment completed received, and will give you the tracking number asap. sometimes we will send it by flat post air mail if just one low price order.Hope you understand. we advise shipping by DHL or EMS,and we have gave a discount for you,you can received it in 4-9 business days. it takes about 15-30days usually if shipping by CHina/Hong Kong post air mail Feedback: The feedback is very important for us.If you are satisfy with us,pleae leave five stars positive feeback,and welcome to our store again,we will supply the good items and service all the time.If you are not 100% satisfied,Please don't leave a neutral or negative but contact us First, we will do our best to solve the problem for you as soon as possible.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded/Generic
Country/Region of Manufacture	China
MPN	Does Not Apply
UPC	Does not apply
