1200w High Powered Programable Buck Dc Switch Power Supply Board W/ttl Zxy-6020s

US $280

??, ???, China
Jan 29th

Open on mobile:
QR code

0-60V 0-20A 1200W High Powered And Programmable DC DC Power Supply Board Switching Power Supply With TTL Serial Interface parameters ZXY-6020S Rated value ( 0C-40C ) voltage 0-60V current 0-20A power 0-1200W DC voltage value input 13V-62V Voltage setting resolution 10mV Current setting resolution 10mA Power effect CV < 0.5%+10mV CC < 1%+5mA Load effect CV < 0.5%+10mV CC < 1%+5mA Output ripple < 50mVpp 100Hz wave transmission ratio < 1/10000 Typical efficiency Vi= 54V,Vo= 26V,Cur.= 20A, efficiency=88% Setting accuracy 10mV,10mA Voltage readback accuracy +/-0.5%+20mV Current readback accuracy +/-1%+5mA State storage capacity M0-M9 common 10 group Cooling style Fans Operation temperature 0-40C Storage temperature -20-70C Environmental conditions Designed for indoor use and operated at maximum relative humidity of 95% Introduction This is a single output,highpowered and programmable switching power supply. It is 60V,20A,1200W,This model has a very small size and ultrathin body. Besides, it is equipped with TTL serial interface. It can provide you with multiple proposal to meet your test demands. The main special function and advantages are as follows: 1. based on the BUCK framework of switch power supply technology, work frequency 150KHz 2. DC input range: DC13V to DC62V suitable for a variety of previous input power 3. digital key operation and multi-function encoder switch operation 4. high resolution and accuracy 5. low noise and ripple,to be on a par with liner power supply 6. high resolution:10mV/10mA 7. intelligent air cooling control 8. support parallel connection and series connection 9. Voltage and current adjustment: coarse control and fine control 10. support measurement shows that the output voltage, current, power, AH, time11. minimum differential pressure 2 v can still work stability 12. power board control board fission design 13. output shutoff button key flexible open or closed output 14. M0 to M9 common 10 group parameter set DC input Support DC input range:DC 13V to DC 120V. Included 1. Power board 1PCS 2. Main control board 1PCS 3. 6P wire (20cm) 1PCS 4. Power line (20cm) 2PCS 5. User Manual 1Pcs Contact Us Please contact us via leaving message,we will reply to you in 12 hours. Please don't hesitate to contact us if you have any questions and idea Goods Return/Refund 1 All of our products have been checked and packaged in a good condition before post out 2 Please note that men made defects are not guaranteed, such as damage after incorrect use and so on 3 The items returned should be kept in their original status 4 We will try our best to work with you to solve the problem Shipping · We Ship to Worldwide United States ,Canada,United Kingdom ,France,Australia we will used E-packed ship ,arrived about 5~15 days . · Items will be shipped within 3 business day on payment received. · Items are shipped from China using Airmail/ ePacket, reach most of the countries within 10 to 30 business days. Or you could choose other express. Check out my other items in my store! Be sure to add me to your favorites list!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	ZXY-6020S
Country/Region of Manufacture	China
