13.56mhz 3kw 1% Accuracy Rf Power Meter Standard

US $2,400.00

Parsippany, New Jersey, United States
Jan 30th

Open on mobile:
QR code

RF Standard High Accuracy RF Instrumentation Our instrumentation line is dedicated to power measurements in RF plasma applications. They incorporate harmonic rejection, customizable filtering as well as temperature and frequency corrections. The combination of features and performance makes our instruments the best on the market, in the 50? segment. The best quality materials and components were selected to guarantee the reliability, stability and repeatability of the measurements. Every instrument comes in a padded, unbreakable plastic enclosure. Because of its small size, portability and connectivity, it can be used either as a laboratory instrument or installed to the chamber for monitoring purposes. We offer measurements and calibration from 250 kHz to 40.68MHz for power levels up to 10kW (for power levels up to 50kW please visit our website). All instruments are calibrated in house using our RF calorimeter, and they are traceable to NIST. We are one of the few companies around the world who is operating an high power RF Calorimeter. Up for sale is new/old inventory at a great price. It has the same electrical characteristics as current line except the enclosure that is made out of steel (new product line has an Aluminum enclosure) and the rechargeable battery may not hold the charge as new. · Frequency agile · Harmonics rejection · RS232 and USB 2.0 interfaces · Portable:12 hours minimum on internal battery · Virtual Panel software interface included · LabView® drivers included Here are the detailed characteristcis of the instrument. We provide, on demand, a calibration certificate. We encourage you to ask questions. FWD Power Full Scale (FS)*: 3kW FWD Power over range: 120% of FS RFL Power Full Scale*: Typical 20% of FS VSWR: Max. 3.00:1 Insertion Loss: Max. 0.05dB Directivity: Min. 30dB Harmonic Rejection: Min. 20dB Impedance: 50? Nominal FWD Power Accuracy*: 1% of reading or 0.1% of PFWD FS, whichever is higher (50? load) RFL Power Accuracy*: 1% of reading or 0.1% of PRFL FS, whichever is higher VSWR Accuracy: Calculated as [1+sqrt(PRFL/PFWD)]/[(1-sqrt(PRFL/PFWD)] Pulsing Signal Capability: Min. 500Hz Nominal Frequency*: 13.56MHz Other frequencies and power levels (up to 50kW) are also available: 250- 460kHz, 27.12MHz or 40.68MHz Frequency range*: ±5% of nominal frequency Calibration cycle: 12 months Calibration corrections: RF power level, frequency, temperature Interface: RS232 and USB2.0 Connectors: LC for 10kW and HN for up to 5kW Sampling rate: 15 Readings/second Power options: wall adapter, USB or internal rechargeable battery Battery life: 12 hours minimum, 16 hours typical Weight: 0.9Kg (2lb) Dimensions: 132mm x 63mm x 125mm (5.2”L x 2.5”W x 5”H) Operating Temperature: 20?C to 35?C (68?F to 95?F) Storing Temperature: -20?C to 70?C (-4?F to 158?F) Humidity, Max.: 95% (non-condensing) Altitude, Max.: 10,000 Ft. (3000m) * For stock instruments. The characteristics can be customized per customer request We ship around the world. Shipment cost depends on your destination and urgency.
