130-300 Mhz Vco Rf, Voltage-controlled Oscillator.

US $170

  • default, Russian Federation
  • Jun 13th
New Coaxial Module Voltage-controlled oscillator VCO (130-300) MHz. Broadband Generator continuous harmonic signals in the frequency band: (130 ... 300) MHz. Control voltage: U = (0,8 ... 16) V. Output Power: (-11 ... + 8) dBm. The relative output of the second harmonic: -10 dBc. Output Impedance: Zout = 50 ohms. Supply voltage; E = (+ 7..+20) V, 110 mA Output RF connector: SMA Aluminum shielded enclosure. Box size: 50.8x50.8x31.8 мм. Dependence of the voltage on the signal frequency (typ):   Uadj, (V). F1, (MHz) P1, (dBm) P2, (dBm) P3, (dBm) 0 - - - - 0,8 130,1 -11,9 -36,1 - 1 133,3 -3,2 -19,2 -40,2 2 147,9 +2,6 -10,3 -31,3 3 160,5 +4,1 -7,8 -32,1 4 172,4 +4,8 -6,3 -33,1 5 184,8 +5,3 -5,1 -35,1 6 198,5 +5,7 -4,2 -35,3 7 212,7 +6,1 -3,5 -32,3 8 227,7 +6,3 -3,1 -31,8 9 242,1 +6,5 -2,6 -33,1 10 255,3 +6,5 -2,4 -33,1 11 267,7 +6,6 -2,5 -39,1 12 279,2 +6,5 -2,6 -33,3 13 288,6 +6,5 -2,8 -28,1 14 295,8 +6,3 -3,2 -26,3 15 301,1 +6,5 -3,3 -25,1 16 304,7 +6,3 -3,8 -25,7
