1700°c 60mm Od Lab Laboratory Horizontal Vacuum Alumina Tube Furnace Heater

US $7,690.00

Livingston, New Jersey, United States
Jan 30th

Open on mobile:
QR code

This listing is for one brand new TF1700 1700°C tube furnace with one alumina tube (OD 60mm, length 1000mm). TF1700 series tube furnaces feature a chamber with alumina fiber insulation and molybdenum silicide heating elements. A double walled steel internal housing helps minimize heat loss to exterior surface. Furnace operation is controlled by Shimaden 40-segment digital controller with built-in RS485 digital communications port and USB adaptor, allowing the user to connect to a PC for remote control and monitoring of the furnace. You can also save or export test results. All our furnaces are CE compliant. Features Compact, portable and lightweight design. Standard package includes set of stainless steel vacuum sealing flanges with valves and pressure meter. Dual flanges support provides better sealing and longer tube life. Microprocessor based self-tuning PID control provides optimum thermal process with minimal overshoot. Multiple atmosphere processes in a single cycle are possible (ex: binder burn out in air and parts sintering under rough vacuum or inert gas environment.) Built-in ammeter and dual voltmeters for easy monitoring and troubleshooting. Built-in computer interface. Long life type B thermocouple. Safety Overheat protection shuts down the furnace if temperature is outside of acceptable range (refer to controller's manual) or when the thermocouple is broken or malfunctions. Power failure protection resumes furnace operation right after the point of failure when power is reestablished. Specifications Tube Material High purity (99%) Al2O3 alumina Tube Size 60mm OD x 50mm ID x 1000mm L Max. Working Temperature 1700°C (3092°F) Refractory Lining 1600 grade fiber alumina Heating Element Molybdenum Silicide (MoSi2) Thermocouple Type B Constant Working Temperature 0-1600°C (0-2912°F) Temperature Controller Shimaden fp93 (made in Japan) with 4 programs and 40 segments (i.e. 4 x 10 segments or 2 x 20 segments). Max Heating & Cooling Rate 5°C (41°F)/min above 1200°C and 10°C (50°F)/min below 1200°C (2192°F) Heating Zone Length 11" Constant Temperature Zone Length 5" Temperature Controller Precision +/- 1°C Vacuum Sealing Flange Kit Stainless steel vacuum sealing flanges with one vacuum gauge, two valves and four thermal ceramic blocks. Electrical requirements 208-240V AC, 50/60 Hz, single phase, 5kW Gas inlet/outlet 1/4" hose barb with 1/4" BSPT (British Standard Pipe Thread) Furnace Dimensions (LxWxH) 25" x 19" x 27" Shipping Dimensions (LxWxH) 47" x 35" x 39" Shipping Weight 550 Lb CE compliance Yes How to program Across International furnace controller Standard package Part description Quantity Part image TF1700 tube furnace 1 pc Stainless steel vacuum sealing flange set w/ pressure meter 1 set Alumina tube 60mm OD x 1000mm L 1 pc Flow meter 1 pc Spare heating element 2 pcs Stainless steel hook 1 pc Alumina ceramic thermal block 2 pairs Thermal gloves 1 pair High temperature Al2O3 alumina crucible (100x40x20mm) 5 pcs Spare fuse 2 pcs USB/RS485 computer interface kit 1 set Furnace operation manual 1 pc Shimaden fp93 temperature controller manual & software 1 pc

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Across International
Model	TF1700.60
