1pc Dc-dc Lm2596 Step-down Adjustable Power Supply Module Cc-cv Led Driver F5

C $2.64

Hong Kong, Hong Kong
Jun 9th

Open on mobile:
QR code

100% brand new and high quality Quantity:1pc Weight:13 g Color: as picture show Size:46mmx23mmx10mm/1.81\"x0.91\"x0.39\"(inch) (approx) ?Ђ Features: 1.Fixed turn the lamp current to 0.1 times the value of the constant current (charge when used to identify whether the battery is full); 2. Increased input reverse polarity protection diode; 3. Using dedicated reference IC, and high-precision sampling resistor, so that the constant current is more stable, (20 degrees to 100 degrees, the constant current 1A, when the temperature drift of less than 1%). ?Ђ Particularly suitable for LED driver *High-power LED constant current drive *Lithium battery charger (including ferroelectric) *4V, 6V, 12V, 14V, 24V battery charger *Nickel cadmium, nickel metal hydride battery pack charger *Solar panels and wind turbines ?Ђ Specifications: *Module Properties: non-isolated constant current and voltage module *Rectification: non-synchronous rectification *Input voltage: 7V-35V *Output voltage: 1.25V-30V *Output current: adjustable maximum 3A *Conversion efficiency: 92% (the highest) *Switching frequency: 150KHz *Output ripple: 50mV (max) 20M bandwidth *Load Regulation: ? 0.5% *Voltage Regulation: ? 2.5% *Operating Temperature: -40 ??to +85 ???Ђ Battery use: * Make sure of the voltage and current of the battery you need to charge * Adjust the constant voltage potentiometer to make the output voltage same to the charge voltage * Potentiometer Adjustment Direction: Clockwise (increase), counterclockwise (decrease) *Use the multimeter in 10A current scale to measure output short-circuit current, and adjust the current potentiometer to make sure the output current to the expected charging current value * The charge current of transfer lamp is default 0.1 times of the charging current (constant current value) * Connected to the battery and try to charging (for previous 5 steps, module input terminal is connected to power source, output load is NOT connected to batteries). ?Ђ LED Constant Current Driver Use: * Make sure operating current and Max operating Voltage of the LED you need to drive. * Adjust the constant voltage potentiometer to make sure the output Voltage is up to LED Max operating Voltage. *Use the multimeter in 10A current scale to measure output short-circuit current, and adjust the current potentiometer. To make sure the output current to the expected LED operating current. * Join LED, test (For the above 3 steps, module input terminal is connected to power source, output load is NOT connected to LED). ?Ђ The scope of application: Charging for lithium ion batteries: when the lithium ion battery voltage is low. If use the constant voltage charging directly. Due to pressure is too large, leading to the battery damage. So from the beginning to use the constant current charging. When charging to a certain, automatic switch back to the constant voltage charging. ?Ђ Charging curve as shown below: red is current, blue is voltage. Package includes: 1pc DC-DC LM2596 Step-down Adjustable Power Supply Module. We offer WORLDWIDE SHIPPING. (Except China, Italy, and Croatia) Orders will be processed and dispatched within 24-48 hours after payment is clear. We only ship to confirmed eBay addresses. Your eBay address MUST MATCH your Shipping address. If you have not received your shipment within 30 business days from payment, please contact us. We will track the shipment and get back to you as soon as possible. Our goal is customer satisfaction! Please note that estimated delivery time is depended on destination countries, and may subject to customs clearance process, and weather condition in your area. Country Delivery Time (days) Not including Handling time, weekend, and holidays 9-12 13-18 19-24 25-29 30-35 >35 United States 5% 50% 30% 11% 5% Refund United Kingdom 10% 63% 19% 3% 4% Refund Australia 21% 50% 14% 7% 7% Refund France 11% 29% 44% 10% 7% Refund Germany 11% 22% 30% 21% 16% Refund Canada 0% 47% 31% 18% 4% Refund Spain 4% 25% 48% 13% 11% Refund We accept PayPal payment only, and must be received within 3 days from the date of purchase. Please leave note in PayPal when making the payment if you have any special requests. Orders will be processed instantly and dispatched within 1-2 days, so we do NOT accept any email/message note after you place orders. IMPORTANT! PLEASE READ! Buyers are responsible for import duties, custom fees and taxes, if any. Please check with your country’s custom office to determine the additional costs impose on the item prior to buying. We offer 14 days return policy. Please contact us within 14 days t from the date you receive your order if you have any issues with the product and would like to return. All returned items MUST BE in the original packaging and you MUST PROVIDE us with the shipping tracking number, specific reason for the return, and your eBay ID. We will refund YOUR FULL WINNING BID AMOUNT, upon receipt of the item in its original condition and packaging with all components and accessories included, AFTER BOTH Buyer and Seller cancel the transaction from eBay. OR, you may choose to have a replacement. Buyer is responsible for return shipping cost. We strive for our customer satisfaction at best possible. If you have any questions, please feel free to email our service specialists 24 Hours a Day, 7 Days a week. We will reply you ASAP. If no response within 24 Hours, please check the spam in your mail box. We greatly appreciate your POSITIVE feedback. Please do NOT leave negative feedback without asking for help. Our aim is to provide Top Level Customer Service, normally so we will try our best to solve any problem you have. Please DON'T leave negative or neutral feedback if you haven't received item in 30 days, because we have mentioned the shipping time repeatedly. We maintain high standards of excellenceand strive for 100% customer satisfaction! Feedback is very important to us. We request that you contact us immediately BEFORE you give us neutral or negative feedback, so that we can satisfactorily address your concerns. Powered by eBay Turbo Lister

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded/Generic
Country/Region of Manufacture	China
UPC	Does not apply
MPN	Does not apply
