1pcs Xl6009 Dc-dc Adjustable Step-up Boost Power Converter Module Replace Lm2577

US $1.90

Hong Kong, China
Jan 29th

Open on mobile:
QR code

Ebay Shops Payment Delivery Time Surport & Warranty Store Policy Visit store: tinxi-clothes-shop Welcome to Tinxi store Coustom Notice - Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer responsibility. Please check with the local customs office to determine what these additional costs will be prior to bidding/buying. - We are a company in CHINA. Delivery from China will cost approximately 20-30 working days. Please pay attention to the shipping and delivery time before you bid. Thank you. Search Product Details 1PCS XL6009 DC-DC Adjustable Step-up Boost Power Converter Module Replace LM2577 Article-Nr.:5200140 Product Details: XL6009 Step-up Boost Power Converter Module Condition: New Description: IN-IN + input Positive Input Negative! Positive output OUT + OUT-output negative Test comparison sample reference: Input 3V Output 12V 0.4A 4.8W Input 5V Output 12V 0.8A 9.6W Input 7.4V Output 12V 1.5A 18W Input 12V Output 15V 2A 30W Input 12V Output 16V 2A 32W Input 12V Output 18V 1.6A 28.8W Input 12V Output 19V 1.5A 28.5W Input 12V Output 24V 1 A 24W Vin * Iin * Efficiency = Vout * Iout Vin: Input Voltage Iin: input current Vout: Output Voltage Iout: output current DSN6009 4A is a high-performance step-up switching current (BOOST) module. The module uses the second generation of high-frequency switching technology XL6009E1 core chip performance than the first generation technology LM2577. XL6009 boost module at a lower cost, superior performance, LM2577 module is about to be eliminated 1. Wide input voltage 3V ~ 32V, optimum operating voltage range is 5 ~ 32V; 2. Wide Output voltage 5V ~ 35V; 3. Built-4A efficient MOSFET switches enable efficiency up to 94%; (LM2577 current is 3A) 4. High switching frequency 400KHz, can use a small-capacity filter capacitors that can achieve very good results, the ripple smaller and smaller. (LM2577 frequency only 50KHz) Technical parameters: DSN6009 boost module Module Properties Non-isolated boost (BOOST) Rectification Non-Synchronous Rectification Input Range 3V ~ 32V Output Range 5V ~ 35V Input Current 4A (max), no-load 18mA (5V input, 8V output, no-load is less than 18mA. Higher the voltage, the greater the load current.) Conversion efficiency

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	See Description
Brand	See Description
Model	See Description
