1UNIT : CZ-K1P Amplifier Unit, Main Unit, PNP by KEYENCE NEW!!!!!!, US $274 – Picture 0

1UNIT : CZ-K1P Amplifier Unit, Main Unit, PNP by KEYENCE NEW!!!!!!, US $274 – Picture 1

1unit : Cz-k1p Amplifier Unit, Main Unit, Pnp By Keyence New!!!!!!

US $274

OPORTO, Portugal
Jan 29th

Open on mobile:
QR code

1UNIT : CZ-K1P Amplifier Unit, Main Unit, PNP by KEYENCE NEW!!!!!! SPECIFICATIONS Select Language EnglishEnglishModel CZ-K1P Light source Red LED, Green LED, Blue LED Response time 300 ?s/1 ms (switch-selectable) Indicators Output: Red LED, Calibration: Orange LED, External synchronization input: Green LED, Matching rate/received light intensity: LCD (Red/Green) Error indication Excess light intensity, insufficient light intensity, insufficient color difference Calibration method 1-point/2-point calibration (switch-selectable) Tolerance value adjustment Numerical value setting on digital display Differentiation mode C mode/C + I mode/I mode (switch-selectable) Timer function OFF-delay timer (40 ms)/Timer OFF (switch-selectable) Output selection Match output: Turns on when target color matches registered color. Mismatch output: Turns on when target color is different from registered color. (switch-selectable) External synchronization input Response speed: 500 ?s max. External calibration input Input response time: 20 ms min. Registered color selection 8-bank selection (By external input), Non-voltage input, Input response time: 20 ms min. Control output PNP: 40 VDC max. (100 mA max.), Residual voltage: 1.0 V max. Protection circuit Reverse-polarity protection (power supply), overcurrent protection (output), surge absorber (output) Rating Power voltage 12 to 24 VDC ±10%, Ripple (P-P): 10% max. Current consumption. 75 mA max. Environmental resistance Operating ambientluminance Incandescent lamp: 5000 lux max., Sunlight: 10000 lux max. Operating temperature range -10 to 55°C (14 to 131°F), No condensation*1 Operating ambient humidity 35 to 85% RH (No condensation) Vibration 10 to 55 Hz, 1.5 mm 0.06", double amplitude in X, Y, Z directions, 2 hours respectively Shock resistance 500 m/s2 in X, Y, Z directions, 3 times respectively Case material Polycarbonate Weight Approx 115 g (including 2-m 6.6' cable) *1 When extended, the ambient usage temperature varies according to the following conditions. Be sure to mount units on a DIN rail (attached to a metal plate) and ensure that the output current is 20 mA or less. When extended

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	KEYENCE
Model	CZ-K1P
