2 Pc Mitee-bite Model #1 Workholding Id Xpansion Clamps-holding Force 1,900 Lbs

US $47

Hamden, Connecticut, United States
May 28th

Open on mobile:
QR code

2 Pcs. Mitee-Bite Products LLC Made in USA Brand New Model No. #1 (Min. -0.48 to Max.- 0.56") ID Xpansion Workholding Clamps, Holding Force is 1,900 Lbs The ID Xpansion® clamp is the ideal solution to hold parts on an inside diameter for high density machining on vertical or horizontal machining centers. It can also be used as an expanding mandrel on a lathe. These machinable clamps are produced in 12 sizes and can hold internal diameters from under 3/16 to almost 10 inches (4.1 to over 103mm). The flange diameter of the clamp is held to a close tolerance for precision locating in a machined pocket on work cubes and fixture plates. The customer machines the mild steel clamp to match the bore of the part ensuring a proper fit. Often times the clamps can be remachined for different size jobs. The low profile ID Xpansion@ Clamp can hold several parts in one compact area for secondary operations without any clamping interference. They are quickly tightened with a hex key, torque driver or can be mated to hydraulic pull cylinders for automation. Low profile Ideal for secondary operations on lathe parts Easily machined to size on lathe or mill Excellent for palletized setups Allows more parts per workcube or fixture plates Heat-treated and coated screw for long life Clamp body made of mild steel for machinability Tighten with hex key or hydraulic pull cylinders Longer screws for hydraulic applications available ID Xpansion Clamp Machining and Installation Model #00 - #6 ID Xpansion Clamps Expand clamp approximately .002 to .003 (.1mm) over relaxed diameter and machine to fit workpiece bore, either on lathe or mill. If machining the clamp on a lathe use the nut provided, on the back of the clamp, to tighten the tapered screw. This nut is used only while machining the clamp. Machine a pocket in the fixture, for the close tolerance “E” dimension and drill and tap mounting holes per “H” column. Drill and tap a hole from the “I” column in the center of the pocket for the tapered screw. A recessed dowel pin may be installed into the flange for additional rigidity if required. Range of expansion .005 to .025 (.2 to .5mm) depending upon size. Model Number A B C D E (+.000 -.002) F G H* I J Torque (Ft/Lbs) Holding Force (Lbs) #1 .98 .75 .59 .23 1.240 .56 .48 6-32 on .910 BHC 1/4-20 .50 13.3 1,900 These images shows how these Original Fixture Clamp can be use for application. You will only get described clamps nothing else. Note: Please call me @ 401-490-1141 for any questions you may have. Quantity discount available. Visit my Free Shipping 10 Reason to bid or buy my listing or products from eBay We do accept world the most secure & reliable payment method “PayPal”. Listings are described with detail information. Every listing or items have digital images from every angle from buyer’s perspective. You will get what we are advertising on eBay no substitute or alternative products. We are not listing anything on eBay, which we do not have in stock so; you will get your won products definitely. Prompt Shipping - As soon as we get the payment we are shipping products as per customer instruction. Prompts Feedback – We left positive feedback as soon as we ship your products, we do not wait for buyers to leave feedback first. So, you have 100% guarantees that you will get the feedback as soon as complete the transactions. We do expect same from buyer for feedback. We do combine all you items to save shipping cost. Every shipping package have tracking # so, it is easy to track. We will e-mail you tracking# as soon as we ship your auctions. 100 % satisfaction guarantee. Great customer service.
