200a 24-100v 24v 48v 60v 72v Current Limited Dc Motor Pwm Speed Controller

US $136.00

Dunaszentgyorgy, Hungary
Feb 17th

Open on mobile:
QR code

>>>Download the DATASHEET from here<<< Use this controller for any brushes motor! Like: trolley, outboard, electric bicycle or more.... Advantages against other motor PWM controller: Built in 5PCS ultra low resistance 130A MOSFETs Connection with high current M6 screws. Universal 0-5V speed controller input. You don't have to use the potentiometer to controll the speed. You can use PLC output or any analoge signal or 0-5V throttle to controll the speed. On /off 2x starter current. 0-20 second speed up potentiometer. For example: slow speed up from 0% to 100% under 20 seconds. Maximum current 200A for 5 seconds (this is perfect for the large starter torque at speed up) Normal current limit is adjustable between 5-100A Ultra high efficiency low speed hight current driving (thanks for the special adaptive controlling. Universal supply voltage between 24-100V DC. (100V is absolute maximum) Capable of synchronisation from external signal. (like from uPC or two piece in sync operation) Overheating protection. In waterproof case Dimensions: 230 x 120 x 40 mm Why choose this controller? On the ebay there is many type of controller the most piece is a chinese simple and cheap controller. They are great until you put a large load to theirs output. -That controllers don't have supply filtering what is very important! Without it the most of the chinese controller regularly burning down. -They haven't got proper freewheele diode against the motor inductive current! -The most of them don't have any current limit function which is very important by a motor. This unit is a current limited speed controller for any brushed DC motor with great LOW ESR capacitor supply filtering and a syncgronous switching freewheel diode! How can you controll the motor speed with this controller? With the current limit potentiometer you can very fine adjust the current what the motor can maximum consumes. For example, you have 1000W 48V DC motor. Your motor nominal current is 20A. Than you adjust the current limit to 25-30A. After them your motor and PWM driver is fully protected against the burning down and over load. Additional protection is the temperature protection. The controller measure the temperature of heatsink. If that exceed the maximum than the controller will shutting down. You can easily control the motor speed between 0-98% with the motor speed controller potentiometer which is connected to the potentiometer terminal. Of course if you have a throttle you can use it. But first you have to sure that is 0-5V. You can use as long potentiometer cable as you want. So you don't have to mount the PWM and the potentiometer juxtaposed. Attention! If you want save money and you don't need waterproof case you can buy PCB controller board. You can find in the store. If you have any question special request or something, please feel free to contact, we are electrical engineers there isn't problem what can't solve. We will see what can we do. If you need more pieces please contact for discount! Warranty: 6 months European shipping: mainly 3-6 days (average) + handling time: 1-3 days Worldwide: mainly 8-12 days (avrerage) + handling time: 1-3 days
