24mhz Fy3200s Digital Dds Dual-channel Arbitrary Function Signal Generator Q7g5

US $106.61

China, China
Aug 25th

Open on mobile:
QR code

24MHz FY3200S Digital DDS Dual-channel Arbitrary Function Signal Generator Q7G5 Features: Using DDS direct digital synthesis technology to generate precise, stable, low distortion output signal. CH1 and CH2 completely symmetrical two channels, each channel can be independently set the parameters. Supports user-defined waveform, each arbitrary waveform memory depth 2048*12bits, 250MSa/s sampling rate. With pulse trains burst output function, manual trigger, internal CH2 trigger and external trigger three trigger modes that allow the unit to any output 1~1048575 arbitrary pulse trains. Measurement functions: 100MHz frequency meter and counter function. Signal output amplitude range is 10mVpp- 20Vpp, DC offset adjustment range is -10V to 10V, the resolution is 0.1V. Digital signal output function, CMOS output range 0~10V. Waveform generator up to 12 bits wide, the output waveform is more delicate, waveform distortion is low. With full CNC functions, display and adjust of current output signal parameters, such as the amplitude, offset, frequency, duty cycle, and the phase difference of two signals. After connected with computer, user can control signal generator functions and parameters, and can edit and download arbitrary waveform. High frequency accuracy and resolution: frequency accuracy up to 10^(-6) magnitude, total range frequency resolution is 10mHz. Tracking function: built-in frequency, amplitude, offset, duty cycle, waveform and other parameters follow function, easy to use. Scanning features: frequency linear sweep and logarithmic sweep function, start and end points of scanning can be set freely. Storage features: can store 20 groups parameters set by the user. Operation: key operation, LCD1602 display in English, directly digital setting parameters or continuous adjustment knob. Input over-voltage protection: extended power input range is AC85V to AC260V wide voltage. Output short-circuit protection: all signal output can work above 60s in load short-circuit situation. Specifications: Frequency Parameters Frequency Range Sine Wave Normal Modes: 0Hz~24MHz Square Wave 0Hz~6MHz Triangle Wave 0Hz~6MHz Other Waveform 0Hz~6MHz The Min. Frequency Resolution 10mHz (0.01Hz) Frequency Accuracy (+/-)5*10^(-6) Frequency Stability (+/-)2*10^(-6)/3 Hours Phase Adjustment Range 0~359° Phase Resolution 1° Waveform Parameters Output Waveform Types Sine/Triangle/Square/Sawtooth/Pulse Wave, Lorentz Pulse, Multi-tone, Random Noise, Electrocardiogram, Trapezoidal Pulse, Symplectic Pulse, Narrow Pulse, Gaussian White Noise, Amplitude Modulated Waveform, Frequency Modulated Waveform and User Defined Waveform Sine Wave Harmonic Distortion 0.8%(Referent Frequency 1KHz) Square Wave Rise/Fall Time 20ns(Referent Frequency 100KHz, 10Vpp) Overshoot 7.5% Duty Cycle 0.1%~99.9% Sawtooth Wave Linearity 98% (0.01Hz~10KHz) Pulse Wave Pulse Width Adjusting Range 10nS~1S Rise/Fall Time 20ns TTL Output Level Amplitude >3Vpp Fan-out >20 TTL Load Rise/Fall Time 20ns CMOS Output Low Level <0.3V High Level 1V~10V Level Rise/Down Time 20ns Waveform Output Output Impedance 50(+/-10%) (Typical) Output Amplitude 20Vpp(No Load) Protection All signals output can work above 60s under the condition of load short circuit DC Offset Offset Adjustment Range (+/-)10V Offset Resolution 0.1V External Measurements Frequency Measuring Range GATE-TIME=1S 1Hz - 100MHz Input Voltage Range 1Vpp~20Vpp Counting Range 0~4294967295 Periodic Measurement 20ns Resolution, the Max. Measurable 20s Scanning Function Scan Mode Linear Sweep, Logarithm Sweep Scan Object Frequency Scan Time 1s-999s/Step Frequency Setting Range Start Point and End Point can be set arbitrarily Frequency Scan Range It is determined by the sweep parameter settings General Parameters Memory Quantity 20 Location M0 to M19 (01 for default value) Interface Interface Mode Using USB to Serial Interface Communication Speed 9600bps Protocol Command Line Mode, Protocol Complete Open Power Supply Voltage Range AC 85V to AC 260V Display Display Type LCD 1602 Display Environment Temperature: 0~40°C Humidity: <80% Size 19 * 18 * 7cm / 7.5 * 7 * 2.75in (L * W * H) Weight 577g / 20.36oz Package Size 25 * 21 * 9.5cm / 9.84 * 8.27 * 3.74in (L * W * H) Package Weight 913g / 32.23oz Package List: 1 * Function Signal Generator 1 * USB Cable 1 * Power Plug 1 * CD 2 * BNC Clips Cable Notice: Because,the international air shipping forbid to ship liquid,powder and batteries, If you purchased goods containing such items, we will not be putting them packing. Thank you for your support. Payment must be made within 12 days after the auction/bid ends, or eBay will open Unpaid Item case automatically later. Please read this before buying International Shipping may Be Delayed Due to Customs. Customers are Responsible For All Import Charges, Tariffs, Duties, Taxes, and Fees Associated with Import of the product. Shipping Charges does not include any Import Charges, Tariffs, Duties, Taxes, and Fees Associated with it. We are not responsible for undeliverable address. We reserve the right to charge the shipping fee again for returned items due to wrong address. Items are generally shipped within 10 business day after your payment has been cleared (Sat. & Sun. excluded.) Dear friend, your happy is very important to me!.we stand behind every product we sell.Your bid is a contract - Place a bid only if you're serious about buying the item. If you are the winning bidder, you will enter into a legally biding contract to purchase the item. If payment is not received within 7 days, item may be offered to the next highest bidder or relisted at the seller's sole discretion.If you're not pleased with your purchase, we'll be happy to make an exchange or refund the product price less S&H within 7 days of your purchase. For any exchange or refund, we need the original receipt or a record of the purchase in our system, and the product must be in its original condition, including the box, packaging, and all accessories.Shipping and handling charges are not refundable. We are professional EBAY sales team and lots of ebay buyers very satisfied with our services.You can enjoy top-quality product and high-quality services from us, Trust me that you will have a pleasant shopping experience in here. Please contact us with any comments, questions or suggestions that you may have bysending ebay message, All the mail will be replied within 24 hours. Please ensure your mail box would not blocked / filtered our mails.we will be happy to assist you.please feel free to contact us for WHOLESALES deal,we will surely give you a satisfatory price.We would try our best to serve you with any question / problem. Please contact us first before leaving Negative / Neutral Feedback or open any cases.We work 6 Days a week From 9:00am - 6:00pm Monday - Saturday CHINA Time.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	FY3200S
Other Waveform	0Hz~6MHz
Country/Region of Manufacture	China
Sampling rate	250MSa/s
MPN	Does not apply
Sine Wave	0Hz~24MHz
Brand	Unbranded/Generic
UPC	Does not apply
