25' Belden 9180 2 Conductor 26 Gauge Aes/ebu Digital Audio Cable 2c 26awg

US $720

  • Costa Mesa, California, United States
  • May 31st
This is an auction for a 25 Foot Length of NEW Belden 9180 2 Conductor 26 Gauge Shielded, Twisted Pair Brilliance® Series Cable for AES/EBU Digital Audio Applications. This cable has a Grey/Chrome Colored PVC (PolyVinyl Chloride) Insulation Jacket. This Cable has 26 AWG Stranded (7x34) Tinned Copper Conductors, a 26AWG Tinned Copper Drain Wire with an Overall Beldfoil® Shield (100% coverage), and Datalene® FHDPE - Foam High Density Polyethylene Insulation on the Individual Wires. This wire is New Old Stock (N.O.S.) and will be cut from a larger roll. >>NOTE: Orders of Multiple Lengths Will Be Sent as a Single Continuous Length.<< FEATURES:   Conductors: 2 Conductors Stranded 26 Gauge (2C, 26AWG) Jacket: Overall PVC (PolyVinyl Chloride) Jacket, 75°C, 300V RMS. Overall Nominal Diameter: 0.144 in. Shielding: 26AWG Tinned Copper Drain Wire with an Overall Beldfoil® Shield (100% coverage) Ratings: AES/EBU, (UL) CMR, C(UL) CMG, 75°C, 300V RMS UL Flame Test: UL1685 FT4 Loading CSA Flame Test: FT4 Impedance: 110 Ohm Operating Temperature Range: -40°C To +75°C Overall Cabling Color Code Chart (Number, Color): 1 Black 2 White We will combine shipments to save on freight on auctions that are paid for at the same time and shipped in the same box. Please request an invoice if you make multiple purchases on any of our auctions. Payment Terms: PayPal. Payment must be received within 7 days of auction closing. California Residents will be charged sales tax. If you have any questions, PLEASE email me BEFORE bidding! Thank You for looking!
