2n3235 Transistor Silicon Npn To-3 (lot Of 9pcs)

US $9.95

Stanton, California, United States
Aug 20th

Open on mobile:
QR code

2N3235 TRANSISTOR SILICON NPN TO-3 (LOT OF 9PCS) SOLID STATE DEVICES INC, SES, WESTINGHOUSE AND UNKNOWN NEW OLD STOCK LOT 32089 F27 Characteristic Specifications SEMICONDUCTOR MATERIAL SILICON INTERNAL CONFIGURATION JUNCTION CONTACT VOLTAGE RATING IN VOLTS PER CHARACTERISTIC 65.0 MAXIMUM BREAKDOWN VOLTAGE, COLLECTOR-TO-BASE, EMITTER OPEN AND 55.0 MAXIMUM BREAKDOWN VOLTAGE, COLLECTOR-TO-EMITTER, BASE OPEN AND 7.0 MAXIMUM BREAKDOWN VOLTAGE, EMITTER-TO-BASE, COLLECTOR OPEN CURRENT RATING PER CHARACTERISTIC 7.00 AMPERES MAXIMUM BASE CURRENT, DC AND 15.00 AMPERES MAXIMUM COLLECTOR CURRENT, DC POWER RATING PER CHARACTERISTIC 117.0 WATTS MAXIMUM COLLECTOR POWER DISSIPATION MAXIMUM OPERATING TEMP PER MEASUREMENT POINT 200.0 DEG CELSIUS CASE INCLOSURE MATERIAL METAL ELECTRODE INTERNALLY-ELECTRICALLY CONNECTED TO CASE COLLECTOR MOUNTING METHOD UNTHREADED HOLE MOUNTING FACILITY QUANTITY 2 TERMINAL TYPE AND QUANTITY 2 PIN AND 1 CASE OVERALL LENGTH 0.400 INCHES MINIMUM AND 0.420 INCHES MAXIMUM OVERALL DIAMETER 0.760 INCHES MINIMUM AND 0.770 INCHES MAXIMUM FEATURES PROVIDED HERMETICALLY SEALED CASE SPECIAL FEATURES JUNCTION PATTERN ARRANGEMENT: NPN (NON-CORE DATA) SPECIFICATION/STANDARD DATA 80131-RELEASE4716 PROFESSIONAL/INDUSTRIAL ASSOCIATION SPECIFICATION

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Number of Pins	2
MPN	2N3235
Series	2N3235
Brand	Unbranded
Type	NPN
Package/Case	TO-3
