2pcs 5v 12864 Lcd Display Module 128x64 Dots Graphic Matrix Lcd Blue Backlight

US $17.88

??, ???, China
Jun 9th

Open on mobile:
QR code

2pcs 5V 12864 LCD Display Module 128x64 Dots Graphic Matrix LCD Blue Backlight 12864 LCD Display Module 128x64 Dots Graphic Blue Color Backlight This product is a LCD display module with blue backlight, small and light appearance, suitbale for copiers, fax machines, laser printers, industrial test equipment, networking LCD display module with blue backlight. Small and light appearance, it is easy and convenient to use. Suitable for copiers, fax machines, laser printers, industrial test equipment, networking equipment etc. Backlight: Blue View area: 7.0cm(L) * 4.4cm(W) Dots size: 0.48mm (L) * 0.48mm (W) Dots pitch: 0.52mm (L) * 0.52mm (W) LCD type: STN (Blue) Viewing angle: 6 o?clock Operating temperature: -20 to 70 degree Storage temperature: -30 to 80 degree The controller of this LCD is a ST7920: Items size unit Module volume 93 X 70 X13 mm View area 72 X40 mm Point distance 0.52 X 0.52 mm Point size 0.48 X0.48 mm Parallel mode interface definition: Pin number definition level Function specification 1 VSS 0V Power supply negative 2 VDD +5V Power supply positive 3 V0 - Contrast control 4 RS H/L RS=H:shows data RS=L:controls instruction 5 R/W H/L R/W+H,E=H,data was read DB7-DB0 R/w=L,E=H=L:the data of DB7-DB0 was written to IR or DR 6 E H/L Enable pin 7-14 DB0-DB7 H/L Data line 15 PSB H/L PSB=H,parallel mode,PSB=L,serial mode 16 NC - Empty pin 17 /RESET H/L Reset terminal,low level valid 18 Voult - Module drives voltage output terminal 19 A +5V Backlight power supply positive 20 K 0V Backlight power supply negative Serial module interface definition: Pin number definition level Function specification 1 VSS 0V Power supply negative 2 VDD +5V Power supply positive 3 V0 - Contrast control 4 CS H/L Chip selection terminal,high level valid 5 SID H/L Serial data input terminal 6 CLK H/L Serial synchronous clock 15 PSB H/L PSB=H,parallel mode,PSB=L,serial mode 17 /RESET H/L Reset terminal,low level valid 19 A +5V Backlight power supply positive 20 K 0V Backlight power supply negative Specification: Original box: No Color: Green Item size: 92*69*10mm Net weight: 76g Package weight: 85g 2PCS Shipping Policy Delivery Time We ship to worldwide, it usually takes 10-30 Business Days to delivery. Shipping address We ship to your PayPal address. Please, make sure to provide us with correct, precise, and detailed shipping Address. Send Time Items will be shipped within 1 to 3 business days upon payment received or cleared. Note If you don't receive items over 30 business days, please notify us via eBay message. Return Policy We appreciate your business and offer an instant 7 days return policy.(7 days after receive the item). The returned item has to be in its original condition. We are able to refund your money without shipping cost. Contact us For anything about product, price, shipping or order status, please contact us via eBay message. We love positive feedback and 5 scores DSR. We will leave it for everyone that leaves it for us.
