2pcs Of 20dbm Rf Module Rf-ttl-100 Sma External Antenna Electronic Free Ship

US $37.99

Dongguan,Guangdong, China
Jan 29th

Open on mobile:
QR code

Welcome to our store! Here provide the best service and the high quality! We have our own factory! Free shipping l Introduce RF-TTL-100 is our latest 100mW wireless transmission module. It working in 148-173.5MHz band and using serial port to send or receive data. Its advantage is that centralized power density, transmission distance(Its transmission distances can reach 2000 meters.) and strong anti-jamming capability. Especially the ability to penetrate diffraction, it is more strong than other band. RF-TTL-100 having the FEC forward error correction algorithm, the coding efficiency is higher and the error correction capability is strong. When in the case of burst interference, it can take the initiative to correct the interference packets , that greatly improving the reliability and transmission distance. The module also having data encryption and compression function. When transmission data in the air, it is random and unsafe. But after the module rigorous encryption and decryption algorithm, the data interception becomes meaningless and improves transport security. The module has four operating modes , and can freely switch at runtime , in the power saving mode , current consumption is only ten of uA, it is very suitable for ultra-low- power applications. 1. Parametric Description Num Parametric Name Detailed Description 1 Module size 20* 36mm 2 Interface 1*7*2.54mm, you can use the universal plate and DuPont line 3 Supply voltage 2.0-3.6V DC 4 Communication voltage 0.7VDD-5.2VDC, VDD is the supply voltage of module 5 Measured distance 1800m@1K 6 Maximum power 20dbm 7 Air Rate 8 adjustable rating 8 Dormancy Current About 1.7uA(M1 =1, M0 = 1) 9 Power Level 8 adjustable rating 10 Transmitting current 89mA@100mW output 11 Receiving current 14.5mA@Mode 0 and 1. The lowest is about 20uA@Mode 2 + 2s wake up 12 Antenna SMA external antenna(You can support our 170M dedicated antenna) 13 Communication Interface UART serial port, 8N1/8E1/8O1, from 1200 to 115200 a total of 8 kinds baud rate 14 Transmitting length Figure 1 Single data packet is 256 bytes 15 Receiving length Single data packet is 256 bytes 16 RSSI Support Built-in intelligent processing 17 Reception sensitivity -119dbm@1Kbps 18 Work temperature -30 - +85°C 19 Work humidity Relative humidity :10% - 90% 20 Storage temperature -40 - +125°C 21 Working frequency 148MHz – 173.2MHZ, 100KHz stepper 2. Module Features l Transmission distance of 2000 meters l 8 kind baud l -119dBm Receiver sensitivity l Ultra-low -power receive l Four operation modes l Sleep current is only 1.7uA l Air wake-up function l Double ring buffer 256Bytes l Built-in watchdog , never crash l Software FEC correction , data compression l Support voltage reading function l Frequency 148-173.5M, 256 channels l Efficient encryption algorithms , error correction function 3. Application l Wireless meter reading l Wireless Sensor l Smart Home l Intelligent Robot l Consumer Electronics l Street lighting control l High-voltage monitoring l Environmental Engineering l Automated data collection l Remote control and monitoring l Other wireless transmission applications 1. Module pins and dimensions Pin Num Pin Name Pin Direction Application 1 M0 Input( Very weak pullup) Match with M1, select 4 operating modes of the module. Do not leave 2 M1 Input( Very weak pullup) Match with M0, select 4 operating modes of the module. Do not leave 3 RXD Input TTL serial input and it connected to an external TXD out pin 4 TXD Output TTL serial output and it connected to an external RXD out pin 5 AUX Output Used to indicate the status of the module 6 VDD Power provide, must be between 2.0 to 3.6 DC(Unit: V) 7 GND Ground Once your item arrives in satisfactory condition, please leave feedback for us. And we will do the same for you. Thank you!
