2x High Power Zigbee Module For Wireless Sensor Network, Wsn, Internet Of Things

US $42.00

Zhongli City, default, Taiwan
Jan 29th

Open on mobile:
QR code

3 in 1 High Power Zigbee module (I/O switch: Coordinator, Router and end Device) TI CC2530 + CC2590 Solution, Support Mesh Network Support High Power, Long range, Serial Port, Digital I/O, ADC Features: 1. 3 in 1 firmware: Coordinator, Router and end Device 2. TI CC2530 + 2591, High power mode 3. Support Serial Port, Digital I/O and Analog Input interfaces: 4 Digital I/O: Remote control logic high (MIN 2.4V), low (MAX 0.5V). Output drives capability 20mA. , Max Voltage 3.3V. 5. Analog Input(ADC): Max Voltage 3.3V, 8bit- resolution Applications: 1. Home automation, building automation 2. Cable replacement 3. SCADA system, Wireless sensor network, Internet of Things 4. Robot, unmanned carrier 5. PDA, POS, receipt printer, bar code reader, RFID, card reader 6. Power meter, Smart energy, Green power, LED light Specifications: 1. Solution: TI CC 2530 + CC 2591 (High power) 2. Coverage: 300~500 m (High power) (The actual distance is depend on the real environment and the antenna. For reference only) 3. Tx. Power: 18 dBm (High power) 4. Rx. Sensitivity (Nominal): -95 dBm (High power) 5. Baud Rate: Supports 1.2/2.4/4.8/9.6/19.2/38.4/57.6/115.2/230.4 Kbps 6. Connection: Point to Multi-points 7. UART Interface: TxD, RxD, GND, CTS/RTS 8. RS-232 Interface: D_SUB 9-pin female 9. Standard: 2.4 GHz IEEE 802.15.4 / ZigBee Pro Stack 10. Data rate: 250Kbps 11. Data Bit: 8 bit 12. Frequency: 2.4GHz~2.5 GHz 13. Modulation: DSSS 14. Antenna: RF-Out, U.FL connector 15. Power Supply: +3.3 VDC 16. RF characters: Receiver Sensitivity: -95 dBm Frequency Error Tolerance: -50~+50 KHz Output Power (High Power): +18 dBm EVM: 30 % 17. Operation Temperature: -20°C to +75°C 18. Dimensions: 25 x 17.5 mm Remark: All contents are subject to change without notice. Mesh Network: Max. 20 nodes @ 1st level under the coordinator, Max. 4 routers in the 20 nodes Max. 20 nodes @ 2nd level under each router @ level 1, Max. 4 routers in the 20 nodes Max. 20 nodes @ 3rd level under each router @ level 2, Max. 4 routers in the 20 nodes Max. 20 nodes @ 4th level under each router @ level 3, Max. 4 routers in the 20 nodes Max. 20 end devices @ 5th level under each router @ level 4 Max. 4 hoppings between the coordinator to the end device Package Contents: High Power Zigbee module x 2 pcs (If you need more units, please advice the quantity. We will offer the new item for you. Payment: 1. We only accept payment from PayPal in advance. 2. We ship to your PayPal primary address. If you would like to ship the item to an alternate address, you MUST specify the alternate address in the NOTE section when you complete payment in PayPal. 3. We reserve the right to cancel your order if the payment is not finished within 7 days or the non PayPal address. Shipping: 1. Economy shipping: Registered air mail by default shipping way. Generally, it will take 1~3 weeks or more to shipping the package by different area. 2. Standard shipping: EMS (International Express Mail Service), Generally, it will take within 1 week or more to shipping the package by different areas. The extra cost will be charged if you need the quicker way of shipping. 3. We will ship the package immediately within 2-3 business days upon receiving your payment. All goods will be shipped from Taiwan in good packing condition. 4. We will offer the tracking number and you will track via Internet. We have noticed that there will be usually postal delays due to the local public holidays, custom clearance, labor strike or climate disaster. 5. Import duties, taxes and charges are not included in the item price or shipping charges. These charges will be paid by the buyers. Please check with your country's customs office to determine what these additional costs will be prior to bidding / buying. Generally, the value of the products is lower and will not be charged. Returns & Refund & Warranty & Repair: 1. Returns: If you receive the defective or damage products, we will replace or fix without any charge. The buyers have to reply to us within 5 working days and take the pictures and describe the status. The buyers are responsible for sending it back to us safely and we will pay for the postage of sending the good items to the buyer. 2. Refund: We accept the refund due to the compatibility with the computer; the buyers have to reply to us within 5 working days and describe the status. The buyers need to bear the shipping cost of returning. We will refund the bargained cost without freight via PayPal only after we receive the returned items. 3. Please keep the packing and accessories completely and well when return the products. 4. Warranty: 1 year since the shipping date. 5. Repair: After 1 year warranty. We will charge the cost of the postage, components and the man power. If the products or the components are phased out, we will provide the discount for the new models or discard the items. About Us and Customer Service: 1. The products are made in Taiwan, we are responsible for the products, please feel easy to buy. 2. Bulk purchase, Customized Brand, Customized Design, Products Design or Sourcing, please contact us. 3. Working hours: Monday to Friday, 9:00 AM ~ 5:00 PM (Taiwan, Taipei time: +8 GMT) 4. International customer service language: English 5. If you have any questions or need the user manual, please contact us.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	IOT-Link
Country/Region of Manufacture	Taiwan
Model	ZM-H
Country of Manufacture	Taiwan, Province of China
