3.2" Tft Lcd Disp Touch Panel Pcb Adapter + Cmos Camera Module Ov7670 Sccb 3.6?m

US $25.98

shenzhen, China
Jun 9th

Open on mobile:
QR code

3.2" TFT LCD disp touch panel PCB adapter + CMOS Camera Module OV7670 SCCB 3.6?m Description 3.2" TFT LCD disp touch panel PCB adapter + CMOS Camera Module OV7670 SCCB 3.6μm TFT LCD can be used to display the images captured by the OV7670. CMOS Camera Module OV7670: Photographic array 640X480 IO voltage of 2.5V to 3.0V (internal LDO for nuclear power 1.8V) Power work 60mW/15fpsVGAYUV Sleep <20?A Operating temperature -30 *C to 70 *C Stable operation 0 *C to 50 *C Output format (8-bit)? YUV/YCbCr4: 2:2 RGB565/555/444 GRB4: 2:2 Raw RGB Data Optical size of 1 / 6 " 25 ° field of view The maximum rate of 30fps VGA Chen Sensitivity 1.3V / (Lux-sec) 46 dB SNR 52 dB dynamic range View Mode Progressive E-1 line to 510 line exposure 3.6m x 3.6m pixel size Dark Current 12 mV / s at 60 *C 3V3 --- input supply voltage (recommended 3.3,5 V can also be, but is not recommended) The GDN ----- ground point SIO_C --- SCCB interface control clock (Note: some of the low-level microcontroller needs pull-up control, and the I2C interface similar) SIO_D --- SCCB interface serial data input (output) end (Note: some of the low-level microcontroller needs pull-up control, and the I2C interface similar) VSYNC --- frame synchronizing signal (output signal) HREF ---- line synchronizing signal (output signal) The PCLK ---- pixel clock (output signals) D0-D7 --- data port (output signal) RESTE --- reset port (normal use pulled) PWDN ---- power selection mode (normal use pull down) OV7670 image sensor, small size, low operating voltage, and provides all the features of the single-chip VGA camera and image processor. SCCB bus control, you can output the entire frame, sub-sampled, take the window way affect data resolution 8. VGA image of the product is up to 30 frames / sec. Users can fully control the image quality, data format and transmission mode. The process of image processing functions including gamma curves, white balance, saturation, chroma, and so can be programmed through the SCCB interface. High sensitivity for low-light applications Low voltage suitable for embedded applications standard SCCB interface compatible with I2C interface RawRGB RGB (GRB4: 2:2, RGB565/555/444), YUV (4:2:2) and YCbCr (4:2:2) output format Support VGA, CIF, and from CIF to 40x30 of various sizes VarioPixel subsampling automatically affect the control functions include: automatic exposure control, automatic gain control, automatic white balance, automatic eliminate light stripes, automatic black level calibration image quality control including color saturation, hue, gamma, sharpness ANTI_BLOOM ISP has to eliminate noise and dead pixel compensation function support for image scaling The lens is the loss of light compensation 50/60Hz automatic detection saturation automatically adjust (UV adjustment) edge enhancement automatically adjust Noise Reduction automatically adjust 3.2" TFT LCD Module Display + Touch Panel + PCB adapter : High Quality Complete LCD w/ Touch screen Complete Module. LCD screen + touch screen, with LCD & touch screen Controller. 8051 / AVR / PIC low power controller can also drive this LCD easily. High portability! Increase development efficiency & lower development cost. Specification: Screen: 65K Colors Driver IC: SSD1289 (Note: The old Version <Come with HX8347 Controller> will be out of manufacture) Size:57.54 (W) x 79.2 (H) x 4.40(T) mm View area:48.60(W) x 64.80(H) mm Display content:240RGB x 320 Dots Resolution:240 x 3 x 320 Dots Pixel dot size:67.5 (L) x 202.5 (W) um Pixel order:STRIPE TYPE Structure type:COG+FPC+BL+TP Backlight type:WHITE LED Payment We accept PayPal payment ONLY. Delivery details 1) All items will be shipped to you Paypal address.please update your latest address when you check out,and please make sure to provide us with correct,precise,and detailed shipping Address. 2) Most of the items will be shipped via HongKong Airmail/Singapore Airmail Note:We will ship your items out via Singapore Post with a tracking number for free if your purchase exceeds $30.If not,and you still need a tracking code,please contact us when you place an order.For countries that are a little far away,especially South America,it is suggest that you add a tracking number for your order,in case of losing parcels. 3) TAX:We'll do our best to assist you to clear the goods,and the tax depends on each country's custom. 4) If you don't receive items over 30 busuness days,please feel to contact with us. 5) Below shipping time for your reference. (Since it is really busy season now,the post office gets so many packages to deal with every day,your parcel may be delayed for a few days.Hope you can understand and be patiet.) Returns 1. No-Question-Asked Refund! If for some reason you're not satisfied with our service or product quality,please contact us within 3 days after you get the package, you can return the products to us in origunal package and we will refund your money after we get the package!(Shipping cost is NOT refundable and you should responsible for the return shipping) 2. No-Question-Asked Replacement! Although all packages are packed professionally, few item(less than 0.1%) might be damaged during the shipping, You are welcome to contact us within 3 days after you receive your package about replacement. 3.Repair Some items migth be broken caused by improper use, we are always happy to offer any helpful repair service.Of course, you can send the broken items back to us and we will help you resolve the situation and charge reasonable repair fees.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	Does Not Apply
Brand	Unbranded/Generic
Country/Region of Manufacture	China
UPC	Does not apply
