3.2" TFT LCD Module 240x320 RGB Touch Screen Display Monitor PCB Adapter USA, US $12.00 – Picture 0
3.2" TFT LCD Module 240x320 RGB Touch Screen Display Monitor PCB Adapter USA, US $12.00 – Picture 0

3.2" Tft Lcd Module 240x320 Rgb Touch Screen Display Monitor Pcb Adapter Usa

US $12.00

  • Addison, Illinois, United States
  • Mar 13th
Open on mobile:
QR code
3.2" Touch Screen TFT LCD with 16 bit parallel interface LCD Controller SSD1289 Touch Screen Controller ADS7843 or XPT2046 LCD Type TFT LCD Interface 16-bit parallel Touch Screen Interface SPI Backlight LED Colors 65536 Resolution 320*240 PIN NO SYMBOL DESCRIPTION FUNCTION 1 5V 5V power supply When powered from 5V supply, Pin 1 & Pin 2 as power input, Pin 33 & Pin 34 provide 3.3V output. 2 GND Ground Power Ground 3 D0 Data lines D0 - D15 4 D1 5 D2 6 D3 7 D4 8 D5 9 D6 10 D7 11 D8 12 D9 13 D10 14 D11 15 D12 16 D13 17 D14 18 D15 19 CS LCD chip select Low active 20 RS Instruction/Data register selection RS = 1 : Instruction Register RS = 0 : Data Register 21 WR Write WR = 0, RD = 1 22 RD Read WR = 1, RD = 0 23 RESET Reset the controller chip Low active 24 NC Not connect Not connect 25 BLVCC must be 5V Backlight VCC 26 BLGND Ground Backlight GND 27 BLCNT Backlight brightness adjustment Control the backlight brightness via PWM 28 TP_IRQ Touch screen interrupt Low level while the touch screen detects pressing 29 TP_CS Touch screen chip select Low active 30 TP_SCK Touch screen SPI clock connects to SPI SCK 31 TP_SI Touch screen data input connects to SPI MOSI 32 TP_SO Touch screen data output connects to SPI MISO 33 3.3V 3.3V power supply When powered from 3.3V supply, Pin 33 & Pin 34 as power input, Pin 1 & Pin 2 keep NC. 34 GND Ground Power Ground
“Never used, like new”
Brand Surenoo Technology
Type Semiconductors & Actives
Country/Region of Manufacture China
Semiconductors & Actives Type LCDs & Displays
Country of Manufacture China
