3 Axis Cnc Router Plan Milling, Drilling And Engraver Machine 48"x 48" Plans

US $24.99

Greenville, North Carolina, United States
Jan 30th

Open on mobile:
QR code

AKR 4848 CNC Plans As the builder of this machine you will understand how it works and take pride in the completed project. Drilling and cutting dimension of all components are supplied, with a comprehensive material list with exploded views on how to assemble. Key Features Dual Motors and Ball screw on Y Axis. 2010 Anti backlash Ball screw on X and Y axis. 2005 Anti backlash Ball screw on Z axis. TBR20mm Linear Rail on Y axis . THK 15 mm Linear Guide Bearing rails on X & Z Two linear rails either side on Y Axis. Ball screw and linear rails on Y axis are below work surface to reduce the ingress of dust and shavings. The machine uses NEMA-34 (4.5N.m 640 oz/in. Holding torque) stepper motors. This unit can be scaled up if required. Specifications Size of work piece X Axis 1300mm (51") Y Axis 1300mm (51”) Z Axis 200mm (7.8”) Work surface size Width 1300mm (51”) Table size . . . . . . . . . . . . . . . . .1300 x 1474mm (51" x 58") Height . . . . . . . . . . . . . . . . . . . . 835mm (32") Width . . . . . . . . . . . . . . . . . . . . 1634mm (64") Depth . . . . . . . . . . . . . . . . . . . . 1570mm (62") After clear payment i will e-mail you the plans. You will receive 1 PDF and one SKP file (Google SketchUp 2014) You will need SketchUp 2014 to be able to open the 3D (SKP file) YOU CAN DONWLOAD IT FOR FREE. Each element in the 3D model is a separate component so you can do any kind of additional measuring as you need it.Picture, instructions and tips of the enclosure with the controller also will be provided.List with all of the elements will be in the PDF file. Read before you pay and if you have any questions ask before buying. Machined plates for the machine will be for sale soon! You will receive the detailed plans, material list and electrical drawings to construct your own CNC Router. This is not a Kit, Plans Only NO REFUND (digytal informations)
