3 Axis Usb Controller Card 400khz Cnc Mach3 Breakout Interface Board Win7/8/xp

US $81.80

Shen Zhen, China
Mar 8th

Open on mobile:
QR code

3 Axis USB Controller Card 400KHz CNC MACH3 Breakout Interface Board Win7/8/XP HOME DESCRIPTION PAYMENT SHIPPING TERMS OF SALE ABOUT US DESCRIPTION The item is a CNC system based mach3.You don't need to add other Hardware, and you can complete the signal conversion from the G-code to the movement of the stepper motor drive control. This card is compatible with most stepper drives and servo drives, and it is perfect weapon to replace mach3 parallel interface board. Feature: A USB Port, this interface is connected to the computer through a USB line.You can use the software mach3 to control this board, Note that you should use a USB2.0 cable with shielding and ferrite core,and cable length should be not more than 2 meters. B 5V General INPUT Port,IN1-12,see as Figure 2-2,it is defined as COM, IN1, IN2, IN3, COM, IN4, IN5, IN6, COM, IN7, IN8, IN9, COM, IN10, IN11, IN12 from left to right, The interface uses opto-isolated, using common positive input,COM is used as the common Port. C High 8 General IO output interface, Have a current drive capability within 10MA,defined as GND O17, O16, O15, O14, O13, O12, O11, O10, O9, O8, 5V from left to right. D 5V General Input Port IN13-IN26,it's a 2.54mm double pin port. E The Yellow input terminals is power input within 12~36VDC., the up terminal is Positive and the bottom terminal is Negative. F Two Relay Output relay R1 and R2 are set as O18 and O19 in mach3, each relay's 3 Terminal are CLOSE\COM\OPEN from up to down, G Spindle PWM speed port, the interface requires a reference voltage,eg.10V, the port is set as 10VIN 0-10Vout,GND from up to bottom. H Low 8 General IO output interface, have a current drive capability within 10MA, defined as O1, O2, O3, O4, O5, O6, O7, GND from left to right. O1-O5 are Open drain port. The Maximum drive current up to 100MA, wiring methods I 3-axis stepper motor control signal output Voltage specification: A. System input voltage: 12~36V; B. Operating voltage of input interface: 5V; C. Operating voltage of output interface: 5V; D. Stepper motor control signal output voltage: 5V; Package Content: CNC 3 Axis USB control card * 1 USB cable * 1 CD * 1(include manual and software) PAYMENT We accept PayPal only. SHIPPING 1.Items are shipped from china.we will send out within 1 bussiness day after receive the payment. 2.We only ship to ebay confirmed address. So before bidding, please kindly verify your ebay address. 3.Shipping to USA takes 8-18 days in normal condition by E-packet with tracking number. Shipping to most other countries takes about 12-30 days via Economy Int'l Airmail. Less than $40, without tracking number,if you request tracking number,please pay $3 more and let me know. Over $40,with tracking number free.The shipping time depends on your location and local postal service,as well as the weather condition along the shipping,sometimes may take longer,.please contact us to confirm before leave feedback or open case. 4.Express shipping: Extra $20 --$25 will be charged for the first 500 grams for most countries. Contact us if you need this service. TERMS OF SALE 1.If you are not satisfied when you receive your item, please return it within 30 days for a replacement or money back. Please contact us before you return it. 2.If item is defective in 30 days, We will send you a replacement without extra charger, or offer refund after we receive the defective item. 3.If item is defective after 30 days, you can still send it back to us. We will send you a new one after receiving the defective item. But you have to pay the extra shipping fee. ABOUT US We are honest seller and do our best to serve you. So if you have any concerns,please don’t hesitate to contact us by ebay message. We will do your best to help you out.please don’t leave negative/ neutral feedback or open case before contact us. On Mar-08-15 at 06:47:49 PDT, seller added the following information:
