35m-4.4g Signal Source Adf4351 Development Board Control For Frequency Sweep

US $56.00

??, ???, China
Jun 9th

Open on mobile:
QR code

Feature: 1, the output frequency range: 35 m - 4.4 G (ADF4351 ) 2, mode of power supply: 5 V 3, the control mode: three line SPI, ADI original PC control software, which can realize all the functions, including frequency, frequency sweep and frequency hopping. 4, the default + - 50 PPM 25 m crystals, phase noise - 112 DBC @ 10 k See below 5, test data and software. Will be near zero DBM. 35 M to 137.5 M phase noise is better than 110 DBC @ 10 k 1 G is better than 100 DBC @ 10 k 2 G is better than 93 DBC @ 10 k 2.2 G is better than 91 DBC @ 10 k 4.4 G is better than 82.3 dBc @ 10 k Better than 86.6 dBc @ 100 k Better than 102 DBC @ 200 k Second harmonic VCO 2.2 G - 4.4 G DBC with this data sheet is very close,ADF4351 the actual phase noise to slightly better than that of ADF4350 , figure was based on the data of ADF4350 test. A lot of people ask the source is a square wave and sine wave, 35 m - 2.2 G frequency division is done so is a square wave, 2.2 G - 4.4 G broadband VCO is internal, such as sine radio frequency signal source, please contact me the default output use broadband matching, the amplitude of points will be near zero DBM, if need to match the characteristic frequency point, please make your own match. test data diagram test instrument 100 hz RBW - 8 g spectrum instrument, VBW 300 hz, can actually instrument to 10 hz RBW, because balance test speed, so the measured phase noise will be better than the below value, if there is a better phase noise spectrum, phase noise can test. 137.5 M test pattern 200M test pattern 500M test pattern 1G test pattern 2G test pattern 2.2G test pattern 4G test pattern Shipping Item will be shipped out within 2 business days after receipt of your payment, we ship the item through hongkong Air mail or China Post. We Ship to Worldwide, but Italy, Nigeria, Brazil will take long delivery time . Before buying, Please make sure your address is correct. Or not, please correct it before payment Ship to worldwide from Hong Kong within 12-24 hours after payment completed received, and will give you the tracking number asap. sometimes we will send it by flat post air mail if just one low price order.Hope you understand. we advise shipping by DHL or EMS,and we have gave a discount for you,you can received it in 4-9 business days. it takes about 15-30days usually if shipping by CHina/Hong Kong post air mail Payment We ONLY accept payment by Paypal. All payments must be received within 7 working days after auction has ended. Non-paying bidders will be reported to ebay. Feedback If you have any questions or comments about our products or policies, please contact us by emails with your purchased item number. You also can contact us by leaving us an eBay message,we will be responded within 24hours. Customer satisfactory is most important to us. If you have a problem or question regarding your transaction please contact us before leaving any type of feedback. Negative feedback does not solve anything. We are always willing to work things out, thank you! Return Policy Refunds are only offered for defective products reported within 7 days upon receipt Buyers need to return the defective item for the replacement at his own cost. Item must be returned by registered airmail to our requested address. We do our best to serve each and every customer the best we can. if you need more items,we can provide you a wholesales price,you can contact us by message or email.
