Content on this page requires a newer version of Adobe Flash Player. The Following Items Are Included: 3M Dynatel 2273 Cable/Pipe/Fault Locator Transmitter (BC# 24826) 3M Dynatel 2273M Cable/Pipe/Fault Locator Receiver (BC# 24827) 3M Dynatel 3014 Earth Contact (BC# 24259) 3M Dual Clip Coupler Cable (2) 3M Dyna Coupler Cables 3M 2001 Dyna-Coupler User Manual On CD-ROM BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! 3M Dynatel 2273M Cable/Pipe and Fault Locator Locate Conductor Faults & Trace Underground Cables & Pipes Includes Accessories As Listed Above! Working Condition: Excellent Condition: Refurbished Warranty: 90 Day Exchange Warranty The 3M™ Dynatel™ 2273M Cable/Pipe and Fault Locator is a microprocessor-based systems that incorporate advanced digital signal processing techniques to quickly and efficiently locate conductor or sheath (earth return) faults and trace the path of underground cables and pipes, both copper and fiber optic (with metallic tracer wire). They provide accurate cable or Sonde depth measurements, giving a digital readout in inches, feet and inches, or centimeters (user-selectable). Lightweight, compact and well balanced, these cable/pipe and fault locators allow you to accurately and easily: Locate cable and pipe path Measure cable or Sonde depth with the push of a button Measure signal current in the cable Pin-point conductor or sheath (earth return) faults and cable breaks Discriminate between light and heavy faults Identify cable and cable pairs Tone shorts and grounds in aerial cable Identify cable pairs through wet sections Locate energized power cable Advanced features detect more information about underground utilities. A new feature exclusive to the 3M Dynatel 2273M-iD Cable/Pipe/Fault and Marker Locator is the ability to write, read and lock programmed information into the new 3M 1400 Series EMS iD Ball Markers. Information such as a pre-programmed unique identification number, facility data, owner information, application type, placement date and other details from up to 100 ID markers can all be read, stored with date/time stamp and transmitted back to your PC through a standard RS232 serial port for enhanced resource management. Designed to be more accurate, faster and more integrated than any other locator on the market, the 3M Dynatel 2273M-iD Cable/Pipe/Fault and Marker Locators can perform these additional functions: Pin-point the location and estimate the depth of all existing models of properly installed underground passive EMS markers Direct depth reading of ID markers Locate two different marker frequencies simultaneously Trace a cable path while simultaneously finding buried markers along the way Several unique modes of operation for accurate locates in every situation. For cable path locating, the 3M Dynatel Cable/Pipe and Fault Locators have a highly accurate multi-antenna design for various user-selected locating modes – Directional Peak, Multi-Directional Null, plus an ultra-sensitive Special Peak mode for extreme depths. The receiver includes a unique "expander" function that makes peaks and nulls more pronounced. The expander feature enhances the response for fast tracking and pin-pointing of position. The unique Directional Peak mode combines the response from four peak antennas to indicate left/center/right direction to the cable/pipe while the bar graph and numeric display indicate the sharp and accurate dual-peak response. Automatic gain set with manual override provides maximum flexibility and control. The multi-directional null mode shows null signal response with automatic gain and utilizes the multiple antenna design to show cable/pipe location and direction on a unique “compass” like graphic user interface on the high-resolution display. Precise location of sheath (earth return) faults. The 3M™ Dynatel™ 2273M and 2273M-iD Cable/Pipe and Fault Locators can precisely locate conductor or sheath (earth return) faults on both short and long cable sections faster than ever before. The transmitter unit sends a trace signal simultaneously with a fault-locate signal, allowing the operator to use the cable-locate function when locating faults in long cable sections. Fault strength is indicated on the receiver liquid crystal display (LCD) screen, allowing minor faults to be ignored, if desired. Up to three fault readings may be stored for quick reference. A simple, easy-to-use system. Lightweight and easy to operate, the 3M Dynatel Cable/Pipe and Fault Locators are rugged, ergonomic and require very little operator training. A large backlit digital LCD screen and soft-key operation make them easy to understand for more precise locates. A “memory” feature remembers operator set-up from previous use. An RS232 communications port allows interfacing to an external computer for uploading/downloading of data, unit configuration and remote software upgrades. The system can run over 30 hours on eight AA alkaline batteries. The system consists of three basic components: Transmitter with built-in ohmmeter, which also senses and measures the presence of foreign voltage and tests the continuity of the circuit Rugged, one-piece hand-held receiver with bar graph signal strength and direction, that indicates received signal and proximity to the cable; ID versions locate all 3M EMS Markers and read/write to all 3M EMS-iD Markers Lightweight earth contact frame that is color-coded to correspond with indications from the receiver directing the operator toward the fault The 3M Dynatel Cable/Pipe and Fault Locators use four active trace frequencies — 577Hz, 8kHz, 33kHz and 200kHz — which can be used individually or simultaneously to compensate for varying field conditions. The receiver incorporates passive power and auxiliary frequencies that do not require the use of the transmitter. The receiver also has the unique capability to accommodate four user-definable auxiliary frequencies and allows the user to perform a self-calibration operation at any frequency at any time. In total, the receiver accommodates 23 frequencies. With the easy-to-use configuration tool, users can enable or disable any frequency to select only the frequencies that they need to use. Both the receiver and the transmitter feature a self-test routine that is executed each time the unit is turned on. A power-up battery test indicates the battery level. Both components are constructed of heavy-duty materials designed to withstand typical field use. ENVIRONMENTAL SPECIFICATIONS Operating Temperature -4° F to 122° F (-20° C to 50° C) Storage temperature -4° F to 158° F (-20° C to 70° C) ELECTRICAL SPECIFICATIONS Receiver Frequencies Trace and tone modes Active: 577Hz, 8kHz, 33kHz, and 200kHz Passive power: 50L, 50H, 100, 60L, 60H, 120 Passive (other): CATV 31.5kHz Auxiliary: 560, 512, 460, 400, 393, 340, 333, 273Hz User defined: up to four frequencies (50~999Hz) Performance Sensitivity @ 1 m/3.3 ft. from cable, Single Peak mode under low noise conditions Depth Display resolution 0.1 dB Depth display range 0 to 30 ft. (9 m) Depth units cm, inch, ft.-in. Depth accuracy +/- 2% +/- 2 in. (5 cm) 0 to 60 in. (1.5 m) +/- 6% +/- 2 in. (5 cm) 60 to 120 in. (1.5 to 3 m) +/- 10% +/- 2 in. (5 cm) 120 to 180 in. (3 to 4.5 m) Cable current display 0.1 dB resolution or 0.01 mA resolution Units: dB or mA Power Battery type: Eight AA size, alkaline Typical battery life 30 hours Transmitter Output frequencies Trace mode 577Hz, 8kHz, 33kHz, 200kHz Sheath (earth return) fault mode 10/20 Hz for sheath (earth return) fault; 577Hz and 33kHz for tracing Tone mode 577Hz and 200kHz pulsed at 8Hz Induction mode 33kHz, 200kHz Output Voltage (maximum) Sheath (earth return) fault 70 Vrms Trace 70 Vrms Tone Normal setting: 10 Vrms, High setting: 60 Vrms Output Power Normal setting: Limited to 0.5W High setting: Limited to 3W, or 5W with extension DC power (option ‘A’ only) Output protection 240 Vrms Power Battery type: Six C size, alkaline (LR14) cells; External DC: 9-18V DC (1A) (option ‘A’ only) Typical battery life Normal output level: 50 hours High output level: 10 hours Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! Contact: Test Equipment Store eBay Sales Phone: 1-419-517-6681 Toll Free : 1-800-548-2381 We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. Shipping Rate Calculator Enter your ZIP/POSTAL code: Select your COUNTRY: United States Canada United Kingdom Afghanistan Albania Algeria American Samoa Andorra Angola Anguilla Antigua and Barbuda Argentina Armenia Aruba Australia Austria Azerbaijan Republic Bahamas Bahrain Bangladesh Barbados Belarus Belgium Belize Benin Bermuda Bhutan Bolivia Bosnia and Herzegovina Botswana Brazil British Virgin Islands Brunei Darussalam Bulgaria Burkina Faso Burma (Myanmar) Burundi Cambodia Cameroon Cape Verde Cayman Islands Central African Republic Chad Chile China Christmas Island Cocos (Keeling) Islands Colombia Comoros Congo, Democratic Republic of the Congo, Republic of the Cook Islands Costa Rica Cote d Ivoire (Ivory Coast) Croatia, Democratic Republic of the Cuba Cyprus Czech Republic Denmark Djibouti Dominica Dominican Republic Ecuador Egypt El Salvador Equatorial Guinea Eritrea Estonia Ethiopia Falkland Islands (Islas Makvinas) Fiji Finland France French Guiana French Polynesia Gabon Republic Gambia Georgia Germany Ghana Gibraltar Greece Greenland Grenada Guadeloupe Guam Guatemala Guernsey Guinea Guinea-Bissau Guyana Haiti Honduras Hong Kong Hungary Iceland India Indonesia Iran Iraq Ireland Israel Italy Jamaica Japan Jersey Jordan Kazakhstan Kenya Kiribati Kuwait Kyrgyzstan Laos Latvia Lebanon Lesotho Liberia Libya Liechtenstein Lithuania Local State/Province Luxembourg Macau Macedonia Madagascar Malawi Malaysia Maldives Mali Malta Marshall Islands Martinique Mauritania Mauritius Mayotte Mexico Micronesia, Federated States of Moldova Monaco Mongolia Montenegro Montserrat Morocco Mozambique Namibia Nauru Nepal Netherlands Netherlands Antilles New Caledonia New Zealand Nicaragua Niger Nigeria Niue North Korea Norway Oman Other Pakistan Palau Panama Papua New Guinea Paraguay Peru Philippines Poland Portugal Puerto Rico Qatar Reunion Romania Russian Federation Rwanda Saint Helena Saint Kitts Saint Lucia Saint Pierre and Miquelon Saint Vincent and the Grenadines Samoa San Marino Saudi Arabia Senegal Serbia, Republic Of Seychelles Sierra Leone Singapore Slovakia Slovenia Solomon Islands Somalia South Africa South Korea Spain Sri Lanka Sudan Suriname Svalbard Swaziland Sweden Switzerland Syria Taiwan Tajikistan Tanzania Thailand Togo Tonga Trinidad and Tobago Tunisia Turkey Turkmenistan Turks and Caicos Islands Tuvalu Uganda Ukraine United Arab Emirates Uruguay Uzbekistan Vanuatu Vatican City State Venezuela Vietnam Virgin Islands (U.S.) Wallis and Futuna Western Sahara Yemen Zambia Zimbabwe We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you ALL MAJOR CREDIT CARDS & PayPal ACCEPTED Powers Your Online Marketplace Grow your business, not your staff with Kyozou eBay Management Software
