3z Rfa-1000 (test)

US $5400

Wayne, New Jersey, United States
May 27th

Open on mobile:
QR code

123eWireless TEST1245 Part: TEST1245 Manufacturer: 123eWireless Weight: 4.0 lbs Length: 3.0 in (76.2 mm) Width: 5.0 in (127 mm) Height: 8.0 in (203.2 mm) Depth: 6.0 in (152.4 mm) Associated HECI(s): test124 Associated CommCode(s): cokmm12 Description Passive Intermodulation (PIM) test source Repeatable high PIM level over wide frequency range Used to verify PIM test equipment operation Used to calibrate Range to Fault module for PIM testing Rugged shock proof design Heat shield for personal protection Dust cover for prolonged life TECHNICAL SPECIFICATIONS Frequency Range 500MHz – 2300MHz RF impedance 50 ohms Return loss 18dB min Nominal PIM level* As per graph RF power rating 10W, continuous | 50W, 3 mins Connector 7/16 Male Mating torque Install slightly more than hand tight to the RF output port of the PIM Analyzer. Tightening with a 7/16 DIN torque wrench is not recommended. Operating temperature range -10° to +50° C Dimensions (L x D) 190 x 60mm (7.48 x 2.36in) Weight 0.5kg (1.0lb) About Launch 3 Telecom Launch 3 Telecom is the premier provider of quality, low-cost, wireless, wireline, voice and data networking equipment. With almost ten years of experience in the telecommunications industry, our worldwide network has the resources to satisfy an ever-expanding base of over 25,000 customers. Headquartered in Hackensack, NJ, just a short ride from New York City, Launch 3 commands a global network of telecom resources that aid in the acquisition and sale of equipment. Every day, thousands of people trust Launch 3 for all their telecom needs. Launch 3 Telecom supplies all major manufacturers such as Nortel, Andrew, Kathrein Scala Division, Ericsson, Powerwave and Alcatel-Lucent to name a few. As a leading telecom distributer, Launch 3 Telecom is an approved government contractor with the Department of Defense and has provided invaluable service to its diverse roster of clients, which includes NASA, AT&T Wireless, BT and WNG. Our commitment to customer service goes far and beyond the bounds of your average telecommunication equipment provider. Whether the product you seek is commonplace or rare, discontinued or outdated, our ability to procure equipment is unparalleled. We pride ourselves on the ability to make the transaction process as quick, simple and profitable for all parties involved. Known for our reliability, Launch 3 is prepared to do whatever it takes to make sure you have your equipment when you want it, every time. Even with no more than an hour's notice, we guarantee results. "Launch 3 once provided crucial parts that were shipped via helicopter to an aircraft carrier, two hours out at sea. That's how essential these parts are in an emergency situation. When someone needs equipment at a moment's notice, that's where we come in."- President of Launch 3 Ventures, LLC. When it comes to asset recovery, Launch 3 is unique in that it accepts all forms of telecom equipment, no matter the value. This sector includes everything from the initial quote to installation/deinstallation. As such, we have three options that can be offered upon appraisal: purchase, consignment and recycle. In the case of the last option, we often offer to perform the full-service free of charge. Find out more about the services we provide at www.launch3telecom.com. Feedback Launch 3 Telecom strives to provide all your telecom equipment needs, every time. Launch 3 Telecom welcomes your feedback on its products and customer service. All comments and questions are appreciated!
