4.3" Tft Lcd Display Module +touch Panel + Pcb Adapter + Sd Socket Icsc006a New

US $42.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Product Name: NEW ICSC006A 4.3" TFT LCD Module Display +Touch Panel + PCB adapter + SD Socket More Items In Our Store,Click Here! SKU: 5184 Parsts No. : Package: Brand: Quantity: 1 4.3 inch TFT Display Modules I,Feature 1).SSD1963 is 1215K-byte frame buffer display controller that supports 864 * 480 * 24 graphic content. It is also equipped with different widths parallel interface bus to receive graphics data and commands from the microcontroller. Its display interface supports common memory fewer LCD driver, per - pixel color depth up to 24 bits. 2) module with dual backlit, that there are two backlight driver circuit, you can select a point by welding to choose, the default MP3202 LED driver chip to drive the backlight, backlight if you need to use an alternate circuit, the three backlight control not weld welding any solder (full off), and then welding spare backlight welding points, so GPIO0 set to high or spare backlight can be controlled PWM output circuit.. 3) module default without touching, but touching the chip XPT2046 welded, if the user wants to add their own touch, simply purchase and install on the touch screen can be used to touch. 4)Module default is not welded external FLASH (SPI interface), users need to be on their own, such as welding (has left port for welding). II,Applications 4.3-inch TFT LCD display to adapt to a variety of fields, widely used: ?DIY; ?Entertainment Video; ?Industrial Display Control; ?The portable handheld device; ?Education, Learning III,Parameters IV,Mechanical Drawings unit:mm V,Function Description Product Type: 4.3-inch TFT display module Operating frequency: 10MHz Controller Model: SSD1963 Data Bus: 16-bit data bus Physical Characteristics: Dimensions: 116.2mm x 69.78mm Environmental Operating temperature: -20-80 degrees Celsius Storage temperature: -40-85 degrees Celsius Humidity: 5% -95% VII,Precautions Controller SSD1963 not industrial grade display controller, so if disruption of normal working hours will be displayed instability (eg splash screen, black and white, etc.) Other TFT LCD Display Series Character Display LCD Modules IIC LCD Display Series Nokia LCD Display Series Dots Matrix LCD Display Modules MCU Chips 1. ATMEl AVR MCU 2 PIC MCU 3. STM32 MCU 4. C8051F 5. MSP430 MCU 6. 51 STC MCU Maybe you request 10pcs NEW 40Pin 1*40 2.54mm 20mm Long Header Pin Male Breakable Pin Header 65pcs Breadboard tie line Wire Breadboad + MB-102 Solderless breadBoard PCB Test 2x Mega 2560 ATmega2560-16AU Board (Arduino-compatible)+Free USB Cable Funduino 1PCS Board MB102 Breadboard Power Supply Module 3.3V/5V For Arduino good NEW 4.3" TFT LCD Module Display (with SD card slot) + Touch Panel + PCB adapter $ 2.43 + free shipping $ 6.25 + free shipping $ 33.72 + free shipping $ 2.69 +free shipping $ 39.85 + free shipping Any problem, please contact us freely 1) We accept PayPal payment ONLY. inkFrog Analytics
