4 Axis 250khz Usb Cnc Adapter,mach3 Plugin,homing,tool Setting,slave Axis,api

US $117.00

Altona Meadows, VIC, Australia
Jan 29th

Open on mobile:
QR code

HyCNC-4P-250 is 4 axis USB CNC parallel port adapter with the following features: Connect to PC via USB port, suitable for any netbook, notebook, tablet and desktop PC with USB ports. USB kernel mode driver compatible with 32/64 bit Microsoft Windows XP/Vista/7/8. Compatible with latest MACH3 PC based CNC software. Multiple connection supported (to use API and VMWare). 4 axis linkage operation up to 250KHz stepping frequency per axis with very low jitter in timing. Slave axis supported with auto alignment during homing. Control pulses are generated by onboard hardware. No need to use specific CPU or chipset. Netbooks with Atom270 and GMA950 work fine. Homing and auto tool setting. 2 switching outputs and 2 PWM outputs - PWM1 is for spindle control and PWM2 are controlled by M codes. DB25 connector for easy retro fit parallel port. Watchdog to monitor Mach3's running (if enabled, 50% duty cycle output on PWM2 when Mach3 service watchdog periodically). LED working status indication. Firmware upgradable with failure recovery mode. Programming API provided. Detailed information and operation manual and Latest USB driver, MACH3 plugin, API and firmware The adapter is specially designed for CNC ant doesn't function as an USB printer adapter.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	HyTechWorks
Country of Manufacture	Australia
Model	HyCNC-4P-250B
