4 Axis 3040 Cnc Router Engraver Engraving Mill Machine Metal Cutter 800w Us New

US $907.00

Chino, California, United States
Sep 1st

Open on mobile:
QR code

Store category Sign Up Now ! You may also like 4 Axis 3040 CNC Router Engraver Engraving Mill Machine Metal Cutter 800W Spindle Product Description SKU: BING3040T+TS001 Packing list: 1X main unit (Frame) 1X main unit (working base) 2X Fence baffle 1X control box 1X A axis 1X Sinal cable for A axis 1X pump 1X 25pin Parallel lines 2X cutter 2*6mm 2X cutter 3*6mm 10X 4*7mm round head 6X 4*10mm black Inner six angle screw with nut 8X 5*20mm black Inner six angle screw 4X 5*8mm Flat Philip's head screw with nut and gasket 8X 6*11mm BALCK FLAT Inner six angle screw 12X Aluminium fastener 1X 13-15# Wrench 1X 14-17# Wrench 2X six angle Wrench(3mm) 2X six angle Wrench(4mm) 1X Teflon tape 2X Fuse (5A) 1X Power cable 1X Manual Attention: This machine needs to connect to a computer through its controller box with a parrallel cable (both included). It is not recommended to connect to a notebook through a parrallel port as the power saving features tend to interrupt the data flow. It is also not recommended to connect to a computers with 64 bit versions of Windows due to problems with the Parrallel port driver. Description 1.This CNC 3040T machine is suitable for industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. 2.It can work with various materials(metallic & non-metallic), such as: wood, pmma or other plastic, MDF board, native wood, PVC, Acrylic, wood, composite board plywood. and soft metal .like aluminum, copper and silver to engrave them into 3D/2D works etc. 3.It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum alloy, acrylic plates, ABS resin double color plate, PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. 4.The mini CNC router Frame is movable. The machine can connect with computer as other external device such as printer , scanner... 5.With the assist of the CNC ROUTER 3040T, your design idea will be real-time display. CNC ENGRAVING MACHINE parameters: X,Y,Z Working Area: 400(Y)*295X*80(Z)mm Outside dimension: 630*505*495mmL*W*H Table size: 550Y*360Xmm Lathe structure: 6061/6063 Aluminium alloy Max. Feeding height: ≤60mm Drive unit: X axis SFU01204-4 Ball Screws Y axis SFU01204-4 Ball Screws Z axis SFU01204-4 Ball Screws Sliding unit: X axis High intensity Chromeplate shaft Y axis High intensity Chromeplate shaft Z axis High intensity Chromeplate shaft Stepping motor:57 two-phase 3A 150N.cm Spindle motor (tips1,The spindle motor must connect with the VFD. 2,It cannot directly connect with the supply voltage (AC110V). 3,Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor. Outside dimension:65*158mm Material:304 stainless steel,Copper coil,Pressure cast aluminum pipe water jacket VOLTScurrentpower:AC110V 50Hz5A,0.8KW VFD Spindle speed:24000 rpm Max working frequency:400Hz Principal axis collet:ER11colletStandard configuration :6mm Nut Model:ER11-A Cooling:Water-cooling Speed mode:By adjusting the VFD output voltage and operating frequency from 0-24000RPM Lubrication way:lubricated by high grease Repeat accuracy:0.05mm Spindle precision:radial beat acuities 0.03mm Carving Instructions:G code / TAB files / nc file / NCC files Communication interface:through parallel connection with computer environment:windows XP / win7 Maximum Idle speed:1500mm/min Working Speed :50-1500mm / min (different material with different speed settings) Control box parameters: Operating Voltage:AC110V Control unit:Toroidal transformer + PWM power supply module + TB6560 stepping motor drive Computer connection:Parallel port Command code:G code Protection:Emergency stop button Feature: 1,The NEW 0.8KW water-cooled VFD is available operating for long time,which can reinforced the processing abilty of the machine and can be used to process aluminum alloy and hard wood. 2,water cooling spindle works more stable and durable. 3, High quality accurate ball Screws drive make the engrving more precision.Anti-blackflash,high precision,long life circle. 4, CompatabilityType3/ArtCAMParameter How to ues 1.Assembling and locating the CNC machine on steady desk well. 2.Make sure that your computer has a 25pin parallel port output. 3. Place the contral box in a ventilated dry place where there is no dust,no moisture 4.Connecting the control box with the CNC machine and you computer and make sure the plug will not come off. 5.Correctly connect the machine with the controller. Don't suspended the cable which connect the Spindle motor with axis(X,Y,Z,A).Otherwise, It will damage the driver of the controller. 6.Correctly instal the Spindle motor and the heat pump. The heat pump should be covered completely in the water, then turned on the electric current to check whether the water-cooling system working well. 9. Before turn on the machine, please check all the cable and water- cooling system to make sure they are working fine. 6.You can enjoy making you dream with using our CNC machine now. Payment Delivery details Terms of sales About us Contact us Payment We accept PayPal payment only Payment must be received within 7 days after order is made. Fees such as import duties, taxes are not included in the item price or shipping costs. These charges are the buyer's responsibility. Delivery details Shipping: The item will be shipped from our US warehouse to United States, which is more faster than from aboard. 2-9 working days to: USA Terms of sales We maintain high standards of excellence and strive for hundred percent customer satisfaction. Feedback is very important to us. We hope that you contact us immediately before you give neutral or negative feedback, so that we can address your concerns. It is impossible to address issues if we do not know about them! About us Your satisfaction is our ultimate goal. We work hard to earn your trust and future business. Our certified technicians have tested each item before shipping. The unit comes with 1 year limited warranty on all manufacturing defects. a) If you receive a defective item, you may return it or ask for a discount. Please contact us within 14 days after you receive the package. b) What you returned must be intact and in its original packaging as re? u. Customer is responsible for shipping costs of the returned item. c) We will cover the cost of shipping back t with the shipping rate indicated in the registration page. We will send you a new unit or refund the full payment you paid. Thank you. Contact us Business HourBusiness Hour: Monday To Friday: 8:30 AM to 5:00 PM (Beijing China time) Due to time zones, our reply to your questions may not be immediately. But within above working time, we will reply your email within 24 hours. If it's non-workdays, please kindly be patient and wait till Monday. Please contact us with ebay message. Please feel free to contact us if you have any questions. : Monday To Friday: 8:30 AM to 5:00 PM (Beijing China time) Due to time zones, our reply to your questions may not be immediately. But within above working time, we will reply your email within 24 hours. If it's non-workdays, please kindly be patient and wait till Monday. Please contact us with ebay message. Please feel free to contact us if you have any questions. Payment Shipping Return policy About us Contact us Feedback On Sep-01-21 at 19:07:18 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded/Generic
Principal axis collet	ER11colletStandard configuration :6mm
Model	BING3040T
Nut Model	ER11-A
MPN	Does not apply
Cooling	Water-cooling
Country/Region of Manufacture	China
Repeat accuracy	0.05mm
X,Y,Z Working Area	400(Y)295X80(Z)mm
Spindle precision	radial beat acuities 0.03mm
Outside dimension	630505495mmLWH
Carving Instructions	G code / TAB files / nc file / NCC files
Lathe structure	6061/6063 Aluminium alloy
Communication interface	through parallel connection with computer
Max. Feeding height	60mm
Command code	G code
Stepping motor	57 two-phase 3A 150N.cm
UPC	does not apply
VOLTScurrentpower	AC110~220V~240V/50Hz5A,0.8KW VFD
Control	CNC
Spindle speed	24000 rpm
Machine Type	4 Axis Router Machine
Max working frequency	400Hz
