4 Axis Coils Winder Winding Machine Fully Automatic Computer E

US $350

Shanghai, China
Nov 19th

Open on mobile:
QR code

winding machine computer coils winder fully automatic 4 axis Notes before placing orders: In most cases, if choose economy shipping, shipping time is about 20 to 35 days. Please contact us before opening dispution, we promise to solve every problem carefully. We are NOT responsible for any custom duty or import tax. Features: This series of automatic filament winder computer controller adopts the latest synchronous winding , it is with high precision and there will be no obstacles appear when in excessive speed winding displacement process. Super elevated wisdom model , it has self-inspecting functions, including the errors of the equipments ,excessive speed tracking and the calibration of the speed. Has vernier caliper functions and can measure the winding width and starting point easily. The speed of the cop motor can be changed at random when in operation , and the strand oscillator also can synchronize with it. After the startup of the cop motor , the time of speed growing can be changed at random depend on the type of the machines. Obtain winding excessive speed detecting function , and it can reduce the winding speed automatically to the most steady state. Can settle data: starting point, wire gage, winding displacement width, circles, speed of starting the winding , stopping slow-speed, winding speed, slow lathe speed , winding displacement direction , winding direction , two-terminal stopping , automatic reset, automatic start (job-hopping winding). Specifications: power-line voltage single phase AC 220V 50HZ winding displacement machine step-servo motor Spindle drive 0.75KW Numbers of cop 4 Maximum winding width 100mm Min. precision of the dereeler 0.001mm Maximum framework diameter 100mm Windable wire gage 0.05-0.6mm Maximum turning speed of cop 6000circles/minute,speed adjust function Storable winding groups 999 groups Counting scope 0.0-99999 circles Counting resolution 0.1 circle Complete appliance weight 90 kg Size 1150*580*620mm
