4 Channel USB/Wireless 5V Relay Module WIFI Remote Control Kit, US $150 – Picture 0

4 Channel USB/Wireless 5V Relay Module WIFI Remote Control Kit, US $150 – Picture 1

4 Channel Usb/wireless 5v Relay Module Wifi Remote Control Kit

US $150

Hefei, China
Jun 9th

Open on mobile:
QR code

Watch the product video here: http://www.youtube.com/watch?v=o82buWfITPI&feature=youtu.be This is a WIFI Relay remote control kit. Including 1x 4 Channel USB/Wireless Relay Module 1x Wifly WIFI Wireless module 1x Xbee USB adapter 1x Mini usb cable You can easily control this relay module by your computer using WIFI. USB/Wireless Relay module Description: This USB/Wireless Relay Module allows computer control switching of external devices by using the USB port of your computer! Meanwhile, It has a wireless extension port, can work with XBEE or Bluetooth Bee or Wifly Module, which mean now you can control your device by zigbee or Bluetooth or WiFi ! The TOSR0x module can powered by USB bus or DC power and provides two volt free contact relay outputs with a current rating of up to 10 Amp each. Relay power rating If the relay is used at a voltage or current exceeding this specification, the life of the contacts may be significantly shortened. A full datasheet for the relays used on the TOSR0x is here: G5LA datasheet If you use DC Power ,the Input voltage should be DC5V. First Step - Install the Driver The TOSR0x module uses FT232RL USB to UART chip . Before using the TOSR0x you will need to download the FT232RL Driver. Connect the TOSR0x and windows will detect it and ask for the drivers. Point windows to the inf folder and it will install the driver. The TOSR0x will now appear as a com port. Commands The TOSR0x operates with an easy to use command set as described in the table below. TOSR0x Baud rate : 9600 Test program and example source code To get the TOSR0x up and running in the minimum amount of time we have put together an example program to demonstrate the functionality of the module. Documents: User Manual G5LA datasheet FT232RL Driver Test Program iPhone APP (WIFI) Android APP(WIFI) May you also need: RN-XV WiFly WiFi Module http://www.ebay.com/itm/RN-XV-WiFly-WiFi-Module-/320971319152?pt=LH_DefaultDomain_0&hash=item4abb61a770 Bluetooth Bee Module XBee Pin Out Compatible http://www.ebay.com/itm/Bluetooth-Bee-Module-XBee-Pin-Out-Compatible-/320967478746?pt=LH_DefaultDomain_0&hash=item4abb270dda XBee 1mW Wire Antenna - Series 1 (802.15.4) http://www.ebay.com/itm/XBee-1mW-Wire-Antenna-Series-1-802-15-4-/221037149673?pt=LH_DefaultDomain_0&hash=item3376d73de9 4 Channel USB/Wireless Relay Module -TOSR04(Xbee, Bluetooth and WIFI Extension) http://www.ebay.com/itm/4-Channel-USB-Wireless-Relay-Module-TOSR04-Xbee-Bluetooth-and-WIFI-Extension-/320967383175?pt=LH_DefaultDomain_0&hash=item4abb259887 8 Channel USB/Wireless Relay Module (Xbee,Bluetooth,WIFI ) +cell phone control http://www.ebay.com/itm/8-Channel-USB-Wireless-Relay-Module-Xbee-Bluetooth-WIFI-cell-phone-control-/320981535833?pt=LH_DefaultDomain_0&hash=item4abbfd8c59 2 Channel USB/Wireless Relay Module (Xbee,Bluetooth,WIFI ) +cell phone control http://www.ebay.com/itm/2-Channel-USB-Wireless-Relay-Module-Xbee-Bluetooth-WIFI-cell-phone-control-/221123947740?pt=LH_DefaultDomain_0&hash=item337c03acdc Shipping & Handling 1. Normally ,we provide Worldwide shipping via Air mail from China . Delivery Time: (A) United States / United Kingdom / Australia / Canada: 7 - 25 working days. (B) Other Countries : Maybe take up to 3-8 weeks, depends on local despatch and your country's strict Custom Inspection . 2. We will send your package out within two Business day after we receive the Payment. 3. Also we provide express delivery service to worldwide. 4. We will ship worldwide except the following regions: INDIA, Macau, China, Vietnam, Indonesia, Nigeria (please check beforehand). Return/Refund Policy We hope you enjoy our products. And your satisfactory is very important to us. Any problems please contact us and we'll do our best to fix it out. Here is our misrepresented & unsatisfied merchandise policy. 1. We accept returns for replacement or refund within 7 days after receipt of item(s). Items MUST be in their original condition, not worn or altered. 2. We DO NOT reimburse the return shipping charge. Refunds will be for the original price paid, and will be issued within 7 business days after receipt of the return. On Aug-31-15 at 02:46:26 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Tinysine
MPN	G505474DC29F64
Model	TOSR04
Country/Region of Manufacture	China
UPC	Does not apply
