4 Nm Nema24 Stepper Motor Cnc Kit 3 Axis 5a Tb6600hg Stepper Driver 36v 10a Ps

US $439.99

HK, Hong Kong
Jun 9th

Open on mobile:
QR code

4 Nm Nema24 Stepper Motor CNC Kit 3 Axis 5A TB6600HG Stepper Driver 36V 10A PS More.. Top Descriptions 3 Pieces 5A 45VDC TB6600HG Microstep Drivers + 3G 5 Axis Breakout Board(Professional Ver) 3 Pieces Nema24 4Nm/567 Oz-in Stepper Motors + 2 Pieces 36V10A Switching Power Supply Descriptions The latest 3G breakout board has been upgraded to the intelligent, professional and industrial-level interface board set by re-designing the PCB board, embedding intelligent memory chip and upgrading the external manual control tools (control pad and display panel). The breakout board controls the microstep drivers more smoothly and with lower noise. With the embedded intelligent memory chip, this professional version 3G 5 Axis breakout board can easily record MAXIMUM 4 Axis' (X, Y, Z, A Axis) G-code running on the CNC software (e.g. Mach3, EMC2, KCAM4, etc.), and then make the stepper motor working without the computer any more. Besides, it has manual programming function. The TB1H is a high performance microstepping driver based on the latest original TOSHIBA high-efficiency TB6600HG IC. The TB6600HG adopts single-chip PWM bipolar sinusoidal chopper to ensure the low vibration and high efficiency. Moreover, the brand new design with BiCD0.13 (45V) process technology on the chipset also ensures maximum 5.0A output current and 45V output withstand voltage. Consequently, as long as the current range of the stepper motor is within 0.2-5 amps, all the 2 Phase or 4 Phase of Nema17, Nema23, Nema24 stepper motors will work perfectly with this new-type TB6600HG Stepper Driver. Click here for the specification of TB6600HG Features I. 3G 5 Axis Breakout Board High performance, cost-effective. Automatically identify PC and control pad control. Real-time display 4 axis position. Automatically finish Tool-settings on X, Y, Z Axis via the control pad, without the support of the computer. Compatible with parallel port communicate CNC software like Mach2, Mach3, LinuxCNC(EMC2), KCAM4 CNC etc. Support G-Code recording via PC and manual programming via the control pad. Two ways to get power, 5V DC power supply or USB port to get power from PC directly. Compatible with all the 2 phase, 3 phase and 4 phase microstep drivers in the market. One Relay output interface to control the spindle motor, air pump, water pump, etc.. 5-axis work LED display, visually display the working condition of the stepper driver controller. 5 input interfaces to set Limit, Estop, Midpoint-Setting, Cutter-presetting/Tool. II. TB6600HG Stepper Driver Board Controller High performance, cost-effective. Automatic idle-current reduction. Supply voltage up to 45V DC. Output current up to 5.0A. Suitable for 2-phase and 4-phase motors. High speed optoelectronic isolation signal input. Single-chip PWM bipolar sinusoidal chopper ensures low vibration and high efficiency. 1, 2, 4 (New Mode), 8, 16 adjustable microstep control, motors run more precisely and smoothly. Cooling Aluminium Box Design for Cooling, and protect the driver board from being damaged by dirt, dust or other liquids. Overload, overcurrent, overheat, overvoltage and undervoltage protection to avoid damaging your computer and devices. III. Stepper Motor GB24H2100-42-4A Applications Suitable for any small-and-medium automatic equipment with CNC controller, such as X-Y-Z tables, labeling machines, laser cutters, engraving machines, and pick-place devices. For advising, such as brand, architechture mould, badge, nameplate, display boards, doorplate, furniture decoration, etc.. For processing various pattern mould. This kit is suitable for below typical CNC machines. TB6600HG DIP-Switch Settings Output Current SW1 SW2 SW3 Microstep Mode SW4 SW5 SW6 0.2A ON ON ON N/A ON ON ON 0.6A OFF ON ON 1(Full Step) OFF ON ON 1.2A ON OFF ON 2 ON OFF ON 1.8A OFF OFF ON 2 OFF OFF ON 2.5A ON ON OFF 4 ON ON OFF 3.3A OFF ON OFF 8 OFF ON OFF 4.2A ON OFF OFF 16 ON OFF OFF 5.0A OFF OFF OFF N/A OFF OFF OFF Interfaces (3G 5 Axis Breakout Board) (TB6600HG Stepper Driver) Connection Diagrams (Breakout-Board-Wiring) (TB6600HG-Wiring) Top Specifications Electrical Specifications of Breakout board Input Voltage 5V DC via power adapter or directly get power from PC via USB port Version Type Professional version Drive type Pulse + Direction + Enable Signal Control Suitable Microstep Driver 2 Phase, 3 Phase, 4 Phase Microstep Driver (M542/M542H/MA860H/3MA2290 etc.) Operationg Environment & Other Specifications of Breakout Board Cooling Natural Cooling or Fan Forced cooling Operating Environment Environment Avoid dust, oil fog, corrosive gas Ambient Temperature 0 °C ~ 50°C (32°F ~ 122°F) Humidity 40%RH ~ 90%RH Operating Temperature 70°C (158°F) Max Storage Temperature -20 °C ~ 65°C (-4°F ~ 149°F) Total Weight Approx. 275g (Breakout Board + Control Pad + Display Panel) Dimensions 110*110*25mm Electrical Specifications of TB6600HG Stepper Driver Input Voltage 12V ~ 45V(Peak) DC Output Current 0.2A ~ 5.0A (Peak) Drive Type Pulse + Direction + Enable Signal Control (Single-Chip PWM Bipolar Sine Chopper) Suitable Motor Nema17, Nema23, Nema24(Rated current: 0.2A-5.0A) Operationg Environment & Other Specifications of TB6600HG Stepper Driver Cooling Natural Cooling or Fan Forced cooling Operating Environment Environment Avoid dust, oil fog, corrosive gas Ambient Temperature 0 °C ~ 50°C (32°F ~ 122°F) Humidity 40%RH ~ 90%RH Operating Temperature 70°C (158°F) Max Storage Temperature -20 °C ~ 65°C (-4°F ~ 149°F) Total Weight Approx. 300g Dimensions 105*85*35mm Specifications of Power Supply Input Voltage 90-132VAC/180-264VAC by switch Input frequency 47~63Hz Output voltage 36V Total current 10A Vout adjustable range 36V±10% Size 215*115*50mm Weight 1100g Specifications of Stepper Motor Model GB24H2100-42-4A Shaft Single Shaft (Diameter:10mm; Length:24mm) Rated Current 4.2A/Phase Rated Voltage 3.36V Step angle 1.8°±5% Phase 2 Phases Phase resistance 0.8x(1+10%)Ω/Phase Phase inductance 4.0x(1+20%)mH/Phase Step angle 1.8°±5% Holding torque 4Nm (Approx. 567 Oz-in) Positioning torque 800gf.cm Insulation resistance ≥100MΩ (500VDC) Insulation class Class B Weight 2.0Kg/Piece Top Contents Click here for the Mach3 software Shipping Payment Warranty We sell items to most countries of the world. For cost saving purpose, we can't keep a lot of stock for every item in every location. Your order with us may be sent from anyone of our dispatch centers that has sufficient in stock quantity. Typical delivery durations(for reference only) are: Estimated Delivery Time(Airmail Packets) UK, Australia, New Zealand, South Asia, East Asia 10-15 business days USA, Canada, other EU countries(France,Germany, etc.) 10-18 business days Italy, Spain 20-30 business days South America, Other Countries 15-20 business days Please DO CONTACT AND CONFIRM with us BEFORE you bid IF you: - need the item urgently. - require that the item should be delivered within a certain time. - have any other questions/requirements about delivery. Remarks: *Usually, your order will be dispatched before the next working day after the full payment is cleared when stock lasts. *Notification will be sent after your order is dispatched, please check you email or ebay order records for date of dispatch. *It is not guaranteed that parcel should arrive within the time stated above. However, 95%+ parcels will be delivered within the reference time. *Please contact us if you have any trouble in receiving your orders. We will help you to track them. PayPal: We accept PayPal (Allows you to pay by credit cards, debit cards or echecks securely with NO surcharge) * If you have difficulty to make payment by PalPal please contact us for alternative payment method. Remarks: *Please send payment within 5 days after auction ends. All sales are final, shipping and handling costs are also NOT negotiable. *We will use your PayPal shipping address as the delivery address. *Please make sure that your shipping address is correct. 30 Days Money Back Guarantee: If you are not satisfied with the item purchased from us. Please inform us in writing(e.g. e-mail, eBay message, fax, letter) within 30 days of receipt of goods. We will guide you to return and refund the item. Please note that the postages / custom fees(if any) spended in such an order are on the customer's cost. Free Replacement: If you receive a not-as-described (e.g. defective, incorrect, part missing) item, please contact us when you get the item. We will arrange a replacement as soon as the case is confirmed. Suppliers Warranty: We offer ONE YEAR warranty on this product. If your item has any warranty issue please contact us for a satisfying solution. Requirements: *All qualified returns/replacement must be guided by us. We may not accept your return without informing us in advance. *Customs fee, handling charge, postage and insurance are on customers cost. Agreement: By placing an order, you acknowledge that you have accepted the terms and conditions of sale. You are welcome to contact us with any questions.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	HY
UPC	190080044374
MPN	100443701
