4 units De uso geral basica de um switch Ratings Roller plunger actuator mounting panel (12.7 * 4.8 days., Rolled Stainless Steel) Sensitivity Sensitivity pattern Operation Type General Type Mechanism Snap-action operation Switching mechanism type self-reset Contact method Single-Pole, Double-Throw type Contact form SPDT Contact gap 0.5 mm Output Terminal Screw (M4) Cargo General Cargo Rated current 15 A Ratings (AC) of non-inductive load Rated voltage: 125 VAC, resistive load: 15 A (NC) 15 A (NO), lamp load: 3 A (NC) 1.5 A (NO) Rated voltage: 250 VAC, resistive load: 15 A (NC) 15 A (NO), the lamp load: 2.5 A (NC) 1.25 A (NO) Rated voltage: 500 VAC, resistive load: 10 A (NC) 10 A (NO), the lamp load: 1.5 A (NC) 0.75 A (NO) Ratings (AC) Inductive load Rated voltage: 125 VAC, inductive load: 15 A (NC) 15 A (NO), Motor load: 5 A (NC) 2.5 A (NO) Rated voltage: 250 VAC, inductive load: 15 A (NC) 15 A (NO), Motor load: 3 A (NC) 1.5 A (NO) Rated voltage: 500 VAC, inductive load: 6 (CN) 6 (NO), Motor load: 1.5 A (NC) 0.75 A (NO) Ratings (DC) of non-inductive load Rated voltage: 8 VDC, resistive load: 15 A (NC) 15 A (NO), the lamp load: 3 A (NC) 1.5 A (NO) Rated voltage: 14 VDC, resistive load: 15 A (NC) 15 A (NO), lamp load: 3 A (NC) 1.5 A (NO) Rated voltage: 30 VDC, resistive load: 6 (CN) 6 (NO), the lamp load: 3 A (NC) 1.5 A (NO) Rated Voltage: 125 VDC, resistive load: 0.5 A (NC) 0.5 A (NO), lamp load: 0.5 A (NC) 0.5 A (NO) Rated voltage: 250 VDC, resistive load: 0.25 A (CN) 0.25 A (NO) Lamp load: 0.25 A (CN) 0.25 A (NO) Ratings (DC) Inductive load Rated voltage: 8 VDC, Inductive load: 15 A (NC) 15 A (NO), Motor load: 5 A (NC) 2.5 A (NO) Rated voltage: 14 VDC, Inductive load: 10 A (NC) 10 A (NO), Motor load: 5 A (NC) 2.5 A (NO) Rated voltage: 30 VDC, Inductive load: 5 A (NC) 5 A (NO), Motor load: 5 A (NC) 2.5 A (NO) Rated Voltage: 125 VDC, Inductive load: 0.05 A (CN) 0.05 A (NO), Motor load: 0.05 A (CN) 0.05 A (NO) Rated voltage: 250 VDC, Inductive load: 0.03 A (CN) 0.03 A (NO), Motor load: 0.03 A (CN) 0.03 A (NO) Scores explanation Cargo lamp has an inrush current of 10 times the steady state current. Inductive load has a power factor of 0.4 min. (CA) and a time constant of 7 ms max. (CC). The load on the motor has a starting current of 6 times the steady state current. CN peak current: 30 A No. 15 A Operating temperature: -25 to +80 CEL Storage: -25 to 80 CEL (with no icing or condensation) Ambient humidity Operating: 35 to 85% RH Storage: 35 to 85% RH (with no icing or condensation) character Permissible operating speed of 0.01 mm / s to 1,000 mm / s Operational specification (mechanical) 240 operations / 1 minute max. Specification of operation (electrically) 20 operations / 1 minute max. Contact resistance of 15 mOhm Max (Initial value) Method of measuring method is the voltage drop across the 1, 6 to 8 VDC. Insulation resistance between each terminal of the same polarities: 100 MOhm Min Between live-metallic part and ground:. 100 MOhm Min Between each terminal and non-live part-metallic:. 100 MOhm Min (at 500 VDC Megger) Dielectric strength Between each terminal of the same polarities: 1,000 VAC between live-metallic part and ground: 2,000 VAC between each terminal and non-live-metallic part: 2,000 VAC (50/60 Hz for 1 min) Mechanical life 10,000,000 operations min. Electrical life 500,000 operations min. (Load rating) Vibration resistance (Breakdown) vibration frequency range: 10 to 55 Hz, double amplitude: 1.5 mm, Malfunction: 1 ms max. at the free position and the total travel position. Shock resistance (destruction) 1000 m / s ** 2 Shock resistance (breakdown) Breakdown time is 1 ms max. at the free position and the total travel position of 50 m / s ** 2. Protection General Type IEC60529 (JEM): IP00 Applicable standard (UL) Standard No.: UL508 File No.: E41515 Applicable standard (CSA) No. Standard: CSA C22.2 No.55 File No.: LR21642 Applicable standard (TUV) Standard No.: EN61058-1 File No.: R9451585 Applicable standard (CCC (CQC)) Standard No.: GB14048.5 Applicable standard (EC Directive (Low Voltage)) 2006/95/EC Mounting Method Mounting with screw or nut Material case of thermosetting resin Approx. 50 gRatings Roller plunger actuator mounting panel (12.7 * 4.8 days., Rolled Stainless Steel) Sensitivity Sensitivity pattern Operation Type General Type Mechanism Snap-action operation Switching mechanism type self-reset Contact method Single-Pole, Double-Throw type Contact form SPDT Contact gap 0.5 mm Output Terminal Screw (M4) Cargo General Cargo Rated current 15 A Ratings (AC) of non-inductive load Rated voltage: 125 VAC, resistive load: 15 A (NC) 15 A (NO), lamp load: 3 A (NC) 1.5 A (NO) Rated voltage: 250 VAC, resistive load: 15 A (NC) 15 A (NO), the lamp load: 2.5 A (NC) 1.25 A (NO) Rated voltage: 500 VAC, resistive load: 10 A (NC) 10 A (NO), the lamp load: 1.5 A (NC) 0.75 A (NO) Ratings (AC) Inductive load Rated voltage: 125 VAC, inductive load: 15 A (NC) 15 A (NO), Motor load: 5 A (NC) 2.5 A (NO) Rated voltage: 250 VAC, inductive load: 15 A (NC) 15 A (NO), Motor load: 3 A (NC) 1.5 A (NO) Rated voltage: 500 VAC, inductive load: 6 (CN) 6 (NO), Motor load: 1.5 A (NC) 0.75 A (NO) Ratings (DC) of non-inductive load Rated voltage: 8 VDC, resistive load: 15 A (NC) 15 A (NO), the lamp load: 3 A (NC) 1.5 A (NO) Rated voltage: 14 VDC, resistive load: 15 A (NC) 15 A (NO), lamp load: 3 A (NC) 1.5 A (NO) Rated voltage: 30 VDC, resistive load: 6 (CN) 6 (NO), the lamp load: 3 A (NC) 1.5 A (NO) Rated Voltage: 125 VDC, resistive load: 0.5 A (NC) 0.5 A (NO), lamp load: 0.5 A (NC) 0.5 A (NO) Rated voltage: 250 VDC, resistive load: 0.25 A (CN) 0.25 A (NO) Lamp load: 0.25 A (CN) 0.25 A (NO) Ratings (DC) Inductive load Rated voltage: 8 VDC, Inductive load: 15 A (NC) 15 A (NO), Motor load: 5 A (NC) 2.5 A (NO) Rated voltage: 14 VDC, Inductive load: 10 A (NC) 10 A (NO), Motor load: 5 A (NC) 2.5 A (NO) Rated voltage: 30 VDC, Inductive load: 5 A (NC) 5 A (NO), Motor load: 5 A (NC) 2.5 A (NO) Rated Voltage: 125 VDC, Inductive load: 0.05 A (CN) 0.05 A (NO), Motor load: 0.05 A (CN) 0.05 A (NO) Rated voltage: 250 VDC, Inductive load: 0.03 A (CN) 0.03 A (NO), Motor load: 0.03 A (CN) 0.03 A (NO) Scores explanation Cargo lamp has an inrush current of 10 times the steady state current. Inductive load has a power factor of 0.4 min. (CA) and a time constant of 7 ms max. (CC). The load on the motor has a starting current of 6 times the steady state current. CN peak current: 30 A No. 15 A Operating temperature: -25 to +80 CEL Storage: -25 to 80 CEL (with no icing or condensation) Ambient humidity Operating: 35 to 85% RH Storage: 35 to 85% RH (with no icing or condensation) character Permissible operating speed of 0.01 mm / s to 1,000 mm / s Operational specification (mechanical) 240 operations / 1 minute max. Specification of operation (electrically) 20 operations / 1 minute max. Contact resistance of 15 mOhm Max (Initial value) Method of measuring method is the voltage drop across the 1, 6 to 8 VDC. Insulation resistance between each terminal of the same polarities: 100 MOhm Min Between live-metallic part and ground:. 100 MOhm Min Between each terminal and non-live part-metallic:. 100 MOhm Min (at 500 VDC Megger) Dielectric strength Between each terminal of the same polarities: 1,000 VAC between live-metallic part and ground: 2,000 VAC between each terminal and non-live-metallic part: 2,000 VAC (50/60 Hz for 1 min) Mechanical life 10,000,000 operations min. Electrical life 500,000 operations min. (Load rating) Vibration resistance (Breakdown) vibration frequency range: 10 to 55 Hz, double amplitude: 1.5 mm, Malfunction: 1 ms max. at the free position and the total travel position. Shock resistance (destruction) 1000 m / s ** 2 Shock resistance (breakdown) Breakdown time is 1 ms max. at the free position and the total travel position of 50 m / s ** 2. Protection General Type IEC60529 (JEM): IP00 Applicable standard (UL) Standard No.: UL508 File No.: E41515 Applicable standard (CSA) No. Standard: CSA C22.2 No.55 File No.: LR21642 Applicable standard (TUV) Standard No.: EN61058-1 File No.: R9451585 Applicable standard (CCC (CQC)) Standard No.: GB14048.5 Applicable standard (EC Directive (Low Voltage)) 2006/95/EC Mounting Method Mounting with screw or nut Material case of thermosetting resin Approx. 50 g
