40mhz Dds Full Digital Controlled Function Signal Generator Module Multimeter

US $102.90

Seattle, Washington, United States
Jan 29th

Open on mobile:
QR code

Hi dear friend, You are bidding for unique high stability, low jitter, high accuracy and low distortion high frequency 0.01HZ - 40MHZ differential / single ended function signal generator module, which built on DDS (Direct Digital Synthesis) technology. It's ideal equipment for electronic engineer, laboratory, production lines, teaching and scientific research with friendly user interface. New multimeter module is available now at that version. Highlights: 1) DDS technology 2) High integrated, multi - module (All in one) system 3) Cost effective 4) Up to 40MHZ sine or square output 5) High stability, Low jitter, Low distortion 6) High resolution and high accuracy frequency programming 7) Full digital controlled Offset, Amplitude, Frequency and Phase adjustment 8) Continuous duty cycle adjustment 9) Sync Out Signal for better synchronization to the external system 9) Differential or 2 independent single ended outputs 10) High current drive outputs 11) Very high precision digital multimeter 12) Full digital adjustable pattern generator 13) High frequency counter 14) Flexible power supply (via 220v - 5v adapter, or direct from PC USB port) 15) Friendly user interface That equipment has 6 built in modules that mentioned below: 1) Sine wave generator module built in to generate high accuracy, low jitter, high stability and low distortion high frequency sine wave at 0.01HZ to 40MHZ max. frequency range. You can use a differential sine wave output as 2 single ended independent sine wave outputs with common amplitude and offset calibration. You can use a differential sine output as 2 single ended separated sine waves outputs with 180 degrees phase shift. 2) Square (Clock) wave generator module built in to generate high accuracy, low jitter, high stability and low distortion high frequency square or clock wave at 0.01HZ to 40MHZ max. frequency range. You can use a differential clock output as 2 single ended separated clocks outputs with 180 degrees phase shift. 3) High precision multimeter module have voltage auto ranger, and built in to measure DC voltage values at the range of 0V - 100V. That module has more then 99% accuracy. 4) Pulse, Pattern generator module built in to generate pulses trains with user defined parameters. At that module an user can program to output pulses trains with parameters as he wish. That module has built in continuous mode. 5) Frequency counter module built in to measure signal frequencies at the range from 1HZ – 50MHZ. That module has built in auto ranger that can find relevant signal frequency range automatically. 6) Pulse counter module built in to count incoming pulses number. THAT UNIQUE EQUIPMENT HAVEN'T AN ANALOG AT THE MARKET DUE TO IT'S SPECIFICATIONS, FUNCTIONALITY AND FRIENDLY USER INTERFACE. Equipment technical specifications ? Waveforms Output Module Main output waveforms Sine, Square, Triangle and Sawtooth waves Output swing 8Vp-p (signal output in open loop) (MAX) Differential output swing 8Vp-p (signal output in open loop) (MAX) Amplitude step 50mV Amplitude error less than 10% Frequency range 0.01Hz ~ 40MHz (Sine, Square and Clock) 10Hz ~ 100KHz (Triangle and Sawtooth) Frequency step 0.01Hz (10mHz) Frequency Stability ±1x10-6 Frequency accuracy ±5x10-6 Sine wave DC offset 3.5V (no load) (MAX) Sine wave offset step 50mV Sine wave offset error less than 10% Square wave DC offset 800mV (no load) (MAX) Square wave offset step 50mV Square wave offset error less than 10% Square wave amplitude 8Vp-p (Voffset = 0V) Square wave Duty Cycle 0% - 100% (continuous) Output current drive 20mA (MAX) Single ended output impedance 100?±10% Differential output impedance 200?±10% Sine wave distortion =98% (0.01Hz~10kHz) Rise and fall time of square wave 3ns Sine Wave Jitter (0 – 16MHZ) 80pS Square Wave Jitter (0 – 16MHZ) 80pS Sine Wave Jitter (16 – 30MHZ) 2nS Square Wave Jitter (16 – 30MHZ) 2nS Sine Wave Jitter (30 – 40MHZ) 5nS Square Wave Jitter (30 – 40MHZ) 5nS Square Wave slew rate 400V/uS Sync pulse amplitude 5v Sync pulse width 500ns – 1us Display LCD1602 u High Precision Multimeter Auto ranger mode Enabled Voltage Meter Range 0V - 100V Voltage Meter accuracy More then 99% u Frequency Counter Module Auto ranger mode Enabled Auto ranger signal search duration 15 sec max. Frequency Meter Range 1Hz~50MHz Frequency meter error less than 1%, above 1KHZ Input Voltage Range 3Vp-p~5Vp-p u Pulse Counter Module Counter Range 0-2100000000 Frequency Range 1Hz~250KHz Input Voltage Range 3Vp-p~5Vp-p u Pulse generator Module Frequency Range 0.1Hz~20 KHz Pulse Output Swing 0v - 5v Pulse min. high duration 32uS Pulse high duration adj. step 1uS Pulse min. period 32uS Pulse period adj. step 1uS Pulse output resistance 100 Ohm u SWEEP Module Not Available Yet Frequency range fM1 to fM2 Sweep time 1s~99s u Miscellaneous Power in 220V @ 50HZ through included 220v - 5v adapter or through USB cable direct from USB port Power Consumption 100mA from 5v -> 0.5W Dimensions 10 cm x 10 cm x 4.5 cm Current model built without triangle and sawtooth waves, because it is out of stock. IF YOU BID FOR THAT ITEM, I PROMISE THAT YOU WILL NOT BE SORRY. FOR MORE INFORMATION YOU CAN FIND EQUIPMENT USER MANUAL. When you will press that link you will enter to the download site. Please scroll down in the site page until you will see "Click here to start download from sendspace" button. Please press on it and download will be started. That user manual is a function signal generator module equipment manual with all modules inside. Please find relevant chapter of model that you want to bid or you bidded for, at current lot example that is Sine wave output, Square wave output, Pulse generator, Frequency counter and Pulse counter chapters, and there you could to impress and to learn about how those modules working. IF YOU HAVE A PROBLEM TO OPEN THAT MANUAL, PLEASE SEND ME A MESSAGE VIA EBAY SITE, AND I WILL SEND YOU THAT MANUAL DIRECTLY TO YOUR MAIL. Shipping time 10 - 25 business days. Shipping method is regular mail without tracking number, if you want to ship that item by registered mail with tracking number, please add another 3$ to the item is price. Please attention, a buyer is responsible for border or any additional fees that take affect in his / her country.Have a nice day.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country of Manufacture	Israel
HIGH FREQUENCY GENERATOR	HIGH FREQUENCY GENERATOR
Manufacturer	Board Tech
DIFFERENTIAL GENERATOR	DIFFERENTIAL GENERATOR
FUNCTION GENERATOR	FUNCTION GENERATOR
PATTERN GENERATOR	PATTERN GENERATOR
SIGNAL GENERATOR	SIGNAL GENERATOR
GENERATOR	GENERATOR
SIGNAL GENERATOR MODULE	SIGNAL GENERATOR MODULE
ANALYZER	ANALYZER
