4th Axis Complete Assembly For Cnc Proxxon Mf70 With Working Mach3 Software

US $240

Whittier, California, United States
Jun 9th

Open on mobile:
QR code

Backlash measurement. This is a complete 4th axis assembly for Proxxon MF70 micro milling machine. The assembly is an ideal for CNC jewelry, small gear making and other 4 axis Proxxon MF70 projects. This unit is specially designed for MF70. But also it can be used for any CNC mini milling machine adding 4th axis operations. It consists of A. Like - new Vexta, 2-phase, Nema 23 stepping motor. Model C014S-9212K with 5VDC, 1.2A, 1.8 degree per step. Resistance 4.1 Ohm per phase . Torque: 98 Oz Inch. The motor comes with a 24 " long 4 wire cable . A 4- pin connector is located between and the phase A. B and directions were labeled. A+ Yellow, A- Blue, B+ Red, B -Black B. Like - new Rino Mechanic ( now Ondrives) worm gear box ( minor surface scuff ) . Model No. ONDO3454 ( Ondrives: PF30-30ANM): Gear Ratio: 30:1 Backlash: <12 arc-minute Reflected Inertia at Input: 7.88 x 10-7 Kg.m2 Efficiency at 1000RPM: 78% You can find price and specs. for new one: http://www.ondrives.com/p/292/pf30-30anm C. New 2" ( 50mm) chuck with three reverse stepped jaws: Precision machined chuck and jaws. Durable steel construction. 2 chuck keys included. 0.08" - 1.125" opening of inside jaw. It is much bigger than 1-12mm ER16 collets of Circular Table 103 . D. Above parts were installed on a .25 inch thick 6061 aluminum alloy plate thru a pair aluminum brackets with all stainless steel bolt, socket cap screws, square nuts, washers and spring washers. E. Working Mach3 mill software ( 5000 line +) with license on CD-R. I have limited quantity of free software and will provide until supply ends. PLEASE WATCH VIDEO ON : http://youtu.be/ctr5zddSUus The dimensions of unit : 16cm ( 6.3") x 11cm ( 4.3") x 11cm ( 4.3"). Weight 4 lbs. 5 oz ( 1.9 Kg ). This complete assembly can be easily installed into dove rail of MF70 by fastening three screws with square nuts(included) through 3 dove rail slots of MF70. No additional work is needed except making alignment with x axis. The distance from center of closed jaws to the bottom of base plate is 40mm. User can remove the base plate and use 3 short screws ( included ) to reduce ( about 6 mm) the distance between center of chuck to base plate. Then user has more travel distance for z+ movement ( but would limit jaw opening- smaller) .Assembled and tested unit includes : Motor , gear box , shaft, bracket sub assembly ( installed), motor cable plus a bag including long screws( x3 )for dove rail, short screws( x3 ) for dove rail and square nuts( x3) for dove rail. MF70 is not included. The S/H fee for domestic buyer is $15, via USPS Priority Mai with Tracking Number. The S/H fee for international buyer is $70, via USPS Express Mail with Tracking Number and Signature Confirmation. Please watch video on youtube: http://youtu.be/ctr5zddSUus Latest feedback Fast Service - great item - thoroughly recommended A+++ Buyer: lamina100(1180) Jun-27-15 09:55 111684498226 very good Buyer: norival2010(14) Jul-10-15 12:54 121674745735 Comment From Date/Time Item # Schneller Versand Buyer: sf25_pilot(31) Sep-10-13 00:52 111130548875 Exactly What I was looking for! Buyer: szum1455(10) Sep-18-13 18:44 121177202325 Fast ship looks nice Buyer: allgoodsurplus(63) Sep-18-13 23:53 111169630269 Great! Thanks! Buyer: karmanmike(232) Sep-19-13 16:13 121168834927 Fantastic ebayer, answers all and any questions - recommend highly Buyer: curiosity2203(124) Sep-23-13 20:19 121175230306 Great ebayer, recommended! Buyer: Member id cheazypeaz ( Feedback Score Of 96) Oct-07-13 06:36 Comment From Date/Time Item # good Buyer: minibikefromhell(59) Nov-10-13 14:05 111176216193 very good Buyer: Member id gevd ( Feedback Score Of 59) Oct-10-13 08:20 Very fast shipping, item as described. Great seller. Buyer: sealion527(380) Oct-19-13 13:21 121192082449 good fast seller Buyer: panayiotisc123(172) Nov-28-13 05:30 111206951865 Incredible !!! Very Very Very excellent and great thanks !!! Buyer: azzbuka(18) Dec-06-13 23:07 121223185852
