5(65)A 120V 60HZ multi-function meter SIngle phase Din rail KWH Watt hour LCD, US $28.88 – Picture 0
5(65)A 120V 60HZ multi-function meter SIngle phase Din rail KWH Watt hour LCD, US $28.88 – Picture 0

5(65)a 120v 60hz Multi-function Meter Single Phase Din Rail Kwh Watt Hour Lcd

US $28.88

  • ZHEJIANG, China, China
  • Jan 29th
Open on mobile:
QR code
dear friend: Products need  to delivery on 5th,March, please be patient. If you have any urgent, please don't buy.  Thank you for your cooperation. Function: 1. Bule backlight                   2. Show real voltage V                   3. Show real current  A                   4. Show real power  Kw                   5. Show poer Factory COS                   6. Show real Frequency Hz                   7. Show Total Energy  KWh                   8. Show Positive  KWh                   9. Show reverse KWh                   10. Rest Energy KWh                   DDS238-2 SW type singe phase din rail kwh  meter is designed to measure single phase two wire AC active energy and variable parameter. All of its functions comply with the relative technical requirement for class 1 single phase watt hour meter in IEC61036. It is a long life meter with the advantage of high stability , high over load capability , low power loss and small volume . Basic Function LCD display with backlight Bi-directional total active energy ,reverse active energy measure in the total active energy The meter also display real voltage , real current , real power , real power factor , real frequency Pulse LED indicates working of meter .Pulse output with optical coupling isolation 35mm din rail installation Optional Function the meter can measure and display the total forward/reverse active energy reset energy function (the reset energy kWh display is dependent with the total energy display, this reset will not affect the total energy ) Technical Data Rate voltage 120V  60HZ Working voltage range 0.8-1.2Un Rate Current 5(65)A       Works from 20mA to 65A Frequency 60Hz Connection mode Direct type Display LCD Accuracy class 1.0 Power consumption <2W/10VA Start current 0.004Ib Constant 800-3200 imp/kWh Pulse output Passive pulse, pulse width is 80+5 ms Executive standard IEC62053-21 Work temperature -30-70 Outline dimension LXMXH 90x35x60mm Weight Approx 0.13kg     Noted: Please press the Bule button to switch the model type! 1 Real Frequency Hz   2. Reset Energy KWH   3 Real CURRENT A   4. Power Factor COS   5 Reactive power   6 Real Positive kWh   7 Real voltage   8 Real Power Kw   9 Total Energy KWh Noted: Total Energy can't reset to zero   10 Version number
