50 Pcs/lot Ic Pic16f72-i/sp, 28-pin, 8-bit Cmos Flash Mcu With A/d Converter

US $68.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Device Included: • PIC16F72 High Performance RISC CPU: • Only 35 single word instructions to learn • All single cycle instructions except for program branches, which are two-cycle • Operating speed: DC - 20 MHz clock input DC - 200 ns instruction cycle • 2K x 14 words of Program Memory, 128 x 8 bytes of Data Memory (RAM) • Pinout compatible to PIC16C72/72A and PIC16F872 • Interrupt capability • Eight-level deep hardware stack • Direct, Indirect and Relative Addressing modes Peripheral Features: • High Sink/Source Current: 25 mA • Timer0: 8-bit timer/counter with 8-bit prescaler • Timer1: 16-bit timer/counter with prescaler, can be incremented during SLEEP via external crystal/clock • Timer2: 8-bit timer/counter with 8-bit period register, prescaler and postscaler • Capture, Compare, PWM (CCP) module - Capture is 16-bit, max. resolution is 12.5 ns - Compare is 16-bit, max. resolution is 200 ns - PWM max. resolution is 10-bit • 8-bit, 5-channel analog-to-digital converter • Synchronous Serial Port (SSP) with SPI™ (Master/Slave) and I2C™ (Slave) • Brown-out detection circuitry for Brown-out Reset (BOR) CMOS Technology: • Low power, high speed CMOS FLASH technology • Fully static design • Wide operating voltage range: 2.0V to 5.5V • Industrial temperature range • Low power consumption: - < 0.6 mA typical @ 3V, 4 MHz - 20 ?A typical @ 3V, 32 kHz - < 1 ?A typical standby current Pin Diagrams Special Microcontroller Features: • 1,000 erase/write cycle FLASH program memory typical • Power-on Reset (POR), Power-up Timer (PWRT) and Oscillator Start-up Timer (OST) • Watchdog Timer (WDT) with its own on-chip RC oscillator for reliable operation • Programmable code protection • Power saving SLEEP mode • Selectable oscillator options • In-Circuit Serial Programming™ (ICSP™) via 2 pins • Processor read access to program memory

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Microchip
IC Package	DIP28_300MIL
Model	GoJGo.com-10358
Category	MCU
MPN	PIC16F72-I/SP
