55 Each Ruland Mdcd19-6-6-ss Special 6mm Stainless Double Shaft Coupling

US $110

La Mesa, California, United States
Jun 21st

Open on mobile:
QR code

55 each RULAND MDCD19-6-6-SS SPECIAL 6mm STAINLESS DOUBLE SHAFT COUPLING NEW! Description Condition: New: without packaging Stamping or markings: RULAND (on each side of the coupling) MDCD19-6-6-SS, SPECIAL M3 THREAD AND EXTRA SPRING 303 STAINLESS STEEL STOCK NO. DD-8822-SS BORE 6MM X 6MM RULAND MANUFACTURING CO., INC (plus other information on the outside plastic sleeve) Weight; about; 7 pounds 1 ounce Information from Ruland Manufacturing Website: MDCD19-6-6-A - Double Disc Coupling Product Number: MDCD19-6-6-A Product Type: Double Disc Coupling Style: Clamp Material: 2024 or 7075 Aluminum Hubs 302 Stainless Steel Disc Springs Finish: Black Anodized Manufacturer: Ruland Manufacturing UPC Number 634529083918 Country of Origin: USA View 3D Model View 2D Model Dimensions Bore B1: 6 mm Bore B2: 6 mm Outer Diameter OD: 19.1 mm Length L: 30.2 mm Hub Length LH: 10.6 mm Max Shaft Penetration: 15.1 mm Fastening Hardware Forged Clamp Screw: M2.5 Number of Screws: 2 ea Screw Material: Alloy Steel Screw Finish: Black Oxide Seating Torque: 1.21 Nm Hex Wrench: 2.0 mm Torque Specifications Static Torque: 2.8 Nm Dynamic Torque Non-Reversing: 1.40 Nm Dynamic Torque Reversing: 0.70 Nm Misalignment Angular Misalignment: 2.0° Parallel Misalignment: 0.10 mm Axial Motion: 0.20 mm Additional Information Torsional Stiffness: 5.8 Nm/Deg Maximum Speed: 10,000 RPM Bore Tolerance: +.03mm / -.00mm Weight: 0.033 lbs Temperature Range: -10°F to 200°F -23°C to 93°C Certifications/ Standards ISO 9001: 2008 Certified Conflict Minerals Compliant RoHS2: Compliant REACH: Compliant Product Notes Note 1: Stainless steel hubs are available upon request. Note 2: Torque ratings are at maximum misalignment. Note 3: Performance ratings are for guidance only. The user must determine suitability for a particular application. Note 4: Torque ratings for the couplings are based on the physical limitations/failure point of the disc springs. Under normal/typical conditions the hubs are capable of holding up to the rated torque of the disc springs. In some cases, especially when the smallest standard bores are used or where shafts are undersized, slippage on the shaft is possible below the rated torque of the disc springs. Keyways are available to provide additional torque capacity in the shaft/hub connection when required. Please consult technical support for more assistance. Note: the couplings that are being offered are stainless steel You are purchasing couplings as best described above. This item was purchased at auction at a going out of business, business. The pictures shown are of the item that is being offered. We try to disclose any imperfections or problems with the items being listed, however we may miss some so we encourage you to take a look at all the photos and ask questions if you are not sure. We want to make sure you are satisfied with your purchase. If this item is being shipped to a California address, then sales tax will be added. We are offering a fourteen (14) day return policy, however the buyer will be responsible for all shipping fees. We reserve the right to change the shipping method and if noted may not be shipped to a P.O. Box. We ship outside the U.S.A. and Canada on some items please ask prior to bidding or purchasing on items so there will be no surprises, we reserve the right not of send items to certain Countries. Thanks you for taking a look! Code: 0-082615
