5a Constant Current Led Driver Lithium-ion Battery Charger Digital Amp/volt Mete

US $14.00

Guang Zhou, China
Jan 29th

Open on mobile:
QR code

5A Constant Current LED Driver Lithium-ion Battery Charging Digital Amp/Volt Meter Adjustable Power Supply Module #090627 Description Features of Power Module: Module Properties: non-isolated step-down module Rectification: Non-Synchronous Rectification Input voltage: 5V-30V Output voltage: 0.8V-29V Output Current: 5A (over 3A should enhance heat dissipation) Conversion efficiency: 95% Maximum Switching frequency: 300KHz Output ripple: 50mV (max) 20M Bandwidth Load regulation: ± 0.5% Voltage regulation: ± 2.5% Working temperature: -40 ℃ to +85 ℃ Size: 51 * 26.3 * 14 (L * W * H) (mm) Features of Meters: Module Name: current and voltage meter Accuracy: 0.1% Refresh rate: about 200ms time Display: Dual 4 0.28 "digital tube Current Range: 0A-5A Voltage Range: 5V-30V Operating current: less than 15mA Display color: red Storage temperature: -10 ℃ to +65 ℃ Input impedance: 50 milliohms Size: 51 * 26.3 * 10mm Features: This modules use high-quality imported chips, high efficiency (up to 95%), low heat, and it can up to 5A maximum current, in conjunction with the original TI op amp control the output current, the overall output is very stable.This module uses the original Sanyo low ESR filter capacitor,the ripple voltage as low as 50mV! Constant voltage constant current module. This module is adjustable buck module, you can adjust the blue adjustable resistor on the module to change the output voltage. The input must be higher than the output about 1V. The minimum output voltage can be 0.8V. Battery charging method: 1 Make sure you need to charge the battery float voltage and charging current, the input voltage of the module; 2 Adjust constant potentiometer, the output voltage is regulated to about 5V. 3 Use a multimeter of 10A current to measure the output current of short-circuit current block, while adjusting the constant current potentiometer to make the output current reaches charging current value; 4 The charging turn lamp current's default is 0.1 times of the charging current (constant value) 5 Adjusting the constant voltage potentiometer to make the output voltage reaches the float voltage; 6 connected to the battery, try to charge. (1,2,3,4,5 step for powering the module input, the output load do not need to connected to the battery.) LED constant current drive methods: 1 Make sure the LED drive operating current and maximum operating voltage you need; 2 Adjust constant potentiometer, the output voltage is regulated to about 5V. 3 Use a multimeter of 10A current to measure the output current of short-circuit current block, while adjusting the constant current potentiometer to make the output current reaches LED operating current value; 4 Adjusting the constant voltage potentiometer to make the output voltage reaches the float voltage; 5 connected to the battery, try to operate. (1,2,3,4 step for powering the module input, the output load do not need to connected to the LED.) Communication protocol description: 1 This module has the computer communication function. Computer can be easily read data of the module's current and voltage, 2 As the module output is TTL level, if you want to achieve the communication with computer, you need to change the TTL level to the RS232 level which can be recognized by computer. 3 protocol as follows: Baud Rate: 9600 Bps BB CC ADDR 00 XX XX CRC (current return command) BB CC ADDR 01 XX XX CRC (voltage returns to the command) Among BB CC for the header (2 bytes) ADDR for the module address (1 byte) 00 to read the current command (1 byte) 01 is a read voltage command (1 byte) XX XX arbitrary value (2 bytes) CRC CRC checksum (1 byte) Package Include: 1x DC Buck Power Module Payment Method We accept only Paypal for both domestic and international. We will ship to the shown address on you PAYPAL Payment notice,Please confirm your shipping address in the PayPal Account. If buyer want to delay the payment because of financial problem, please contact me by the ebay message within 3 days. Shipping Detail Ship by Post Air-mail within 3 working days after full payment is received. The shipment usually takes 15-45 business days to Worldwide. We also provide international Expressed delivery such as EMS, DHL and UPS,extra shipping fees is needed. The shipping time may vary, depends on receiver's location. Feedback Policy We will leave positive feedback to buyer as soon as buyer pays for the item. Leaving Negative feedback or Netural Feedback is never a good way to resolve problem .We hightly appreciate that you can contact with us before you leaving Negative feedback or Neutral feedback .We will offer help to resolve your problems as fast as possible. Customer Service Work Time If you have any questions,Please contact with us via eBay message or our customer service e-mail . please be advised that e-mails will be replied by our customer services officers Mon. - Fri. 11:00 - 20:00 and Saturdays 11:00 – 15:00(Excluding Weekends and Public Holidays) You may expect to receive a response to your inquiry within 24 hours. (Excluding Weekends and Public Holidays) Engineered for professional eBay sellers! On Dec-01-14 at 14:27:45 PST, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Input voltage	5V-30V
Conversion efficiency	95% Maximum
Output voltage	0.8V-29V
Display	Dual 4 0.28 "digital tube
Output Current	5A (over 3A should enhance heat dissipation)
