5kv 60gohm Insulation Resistance Meter Tester Megohmmeter Polarization Index

US $490.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Note: we'll ship this item via express mail service to USA, Canada, Australia, New Zealand, Ireland, Austria, Belgium, Denmark, Germany, France, Finland, Luxemburg, Malta, Norway, Sweden, Swiss, Spain, UK, Italy, Japan, Korea, Malaysia, Thailand, Indonesia, Philippine. Clients from other countries pls contact with us in advance to confirm the different shipping charges before you bid. DT6605 Features: 1. Wide range measurements from 500V to 5000V and up to 60G?. 2. Large 6000 counts digital display with bargraph and backlight. 3. Polarization index measurement (PI). 4. Auto ranging & Timer measurement function. 5. Indication of output voltage and discharge voltage. 6. Auto-discharge function and voltage output warning function. 7. Auto power off and battery check. 8. MAX/MIN, PEAK, Relative value & Data hold functions for DC/AC voltage measurements. 9. Safety standard IEC61010-1 CAT IV 600V. Specifications: Function Insulation resistance Voltage Resistance Range 500V 1000V 2500V 5000V AC/DCV Measuring range (Auto ranging) 0~6.000M? 0~6.000M? 0~6.000M? 6~60.00M? 0~600.0V (50~1kHz) 0~600.0? 600~6000? 6~60.00M? 6~60.00M? 6~60.00M? 60~600.0M? 60~600.0M? 60~600.0M? 0.6~6.000G? 0.6~6.000G? 600~6000M? 600~6000M? 6~60.00G? 6~60.00G? Accuracy ±5%rdg ±3dgt ; ±20% (>6G? or more) ±1.5%rdg ±5dgt ±1.5%rdg ±10dgt Short Circuit Current 1.3mA approx - Rated test Current (at load Resistance) 1mA-1.2mA 0.5M? 1mA-1.2mA 1M? 1mA-1.2mA 2.5M? 1mA-1.2mA 5M? Open circuit voltage 500VDC/+20%-0% 1000VDC/+20%-0% 2500VDC/+20%-0% 5000VDC/+20%-0% - Continuity check Buzzer sounds at 50? Display 6000 Counts Current consumption About 1000mA (During measurement) 25mA approx. Withstand Voltage 5320V AC for 5 seconds Safety standard IEC 61010-1 CAT IV 600V Pollution Degree 2 Power supply DC12V : R14 x 8 Dimensions 198 ( L) x 148 (W) x 86 ( D) mm Weight 1438g approx. Accessories: Test leads, Instruction Manual and 120V/250V AC adaptor.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	DT-6605
Country of Manufacture	China
MPN	DT-6605
