5mp Mjpeg Industrial Micro Endoscope Android Pcb Board Usb Cmos Camera Module

US $47.70

SHENZHEN, China
Jun 9th

Open on mobile:
QR code

5MP MJPEG Industrial Micro Endoscope Android PCB Board USB Cmos Camera Module Description 5Megapixel Usb Camera Module USB2.0 OmniVision OV5640 Color CMOS Sensor 2.1MM Lens Main Specifications Module No. ELP-USB500W02M-L21 Sensor OV5640 (1/4inch ) Max. Resolution 2592 (H) *1944 (V) Sensitivity 600mV/ Lux-sec Pixel Size 1.4µm x1.4µm Image area 3673.6µmx2738.4µm Maximum Image Transfer Rate 2592x1944@ 15fps MJPEG / 2048x1536@ 15fps MJPEG 1600x1200@ 15fps MJPEG / 1920x1080@ 15fps MJPEG 1280x1024@15fps MJPEG/ 1280x720@ 30fps MJPEG 1024 x 768@ 30fps MJPEG/ 800 x 600@ 30fps MJPEG 640x480@ 30fps MJPEG / 320x240@ 30fps MJPEG Camera Board Assembly technique SMT (ROSH) Object distance 5CM-100M Resolution 600LW/PH (Center) interface USB 2.0 High Speed protocol USB Video Class(UVC) S/N Ratio 36dB Dynamic Range 68dB Shutter Rolling shutter/ frame exposure Package CSP, Bare Die AGC/AEC/AWB/ABF Auto Output Formats YUYV/MJPEG Adjustable parameter Brightness Contrast Hue Saturation Sharpness Gamma White Balance Exposure Focus Package LQFN-40pin Lens Parameter Standard 2.1mm, optional 2.5/2.8/3.6/6mm/ FOV(D)170 Degree LED board power connector Support 2P-2.0mm socket Power supply USB BUS POWER 4P-2.0mm socket Operating Voltage DC5V Power consumption 150mW (VGA); 200mW (QSXGA); Module Size 38mm × 38mm (compatible 32X32mm) Temperature (Operation) -20°C to 70°C Temperature (Stable Image) 0°C to 60°C USB Cable 1M(2M/3M/5M Optional) Operating system request Win XP/Vista/Win7/Win8 / Linux with UVC(above linux-2.6.26) MAC-OS X 10.4.8 or later/Android 4.0 or above with UVC Certifications FCC and CE Payment 1.We accept Paypal only. 2.Payment must be received within 7 working days. Or unpaid case will be opened automatically. Delivery details 1.We ship goods to customer's confirmed paypal address. Please be sure your paypal address is correct before bidding. 2.Items will be shipped out within 48 hours once payment cleared. By registered air mail with tracking number. Orders placed on weekends or holidays will be processed on Monday or next working day. 3.International buyers please note: Import duties,taxes and charges are not included in the item price or shipping charges. These fees are buyers responsibility. So, Please check with your country's customs office to determine what these additional costs will be prior to bidding. 4.Delivery time: For USA buyers we'll ship by e-packet takes arround 7-12 working days. Other countries we'll ship by Registered Air Mail. Arround delivery time as bellow for your referrence. Australia, Canada 10-18 working days UK, France, Austria, Germany, Spain and other Europe countries: 10-25 working days Greece, Malta 15-40 working days Russian Federation, Italy, Brazil, Africa countries: 20-40 days due to customs restriction The estimated arrival time above just for your refference, Not guaranteed. We don't responsible for any customs duties. Terms of sales 1.If the goods dead on arrival, Please take photoes for us confirmation and reach us first time for exchange or refund. 2.Buyers have purchased a wrong item or don't like the item received, Please return within 7 days and reach us first before returning. 3.Ailipu Technology Co., Ltd warrants our product to be free from manufacturer’s maintenance for 2 years. The warranty will not be covered under the following conditions : a) Out-of-warranty products. b) The product is modified without Ailipu Technology Co.,Ltd approval. c) Obvious attack of appearance whatever it is. d) The product is subjected to unusual physical or electrical stress, including physical damage, burnt components and broken connectors. 4. The customer is responsible for returning the defective product at his own expense. About us Ailipu Technology Co.,Ltd have 10 years history, is a professional manufacturer of surveillance system. We produce traditional analog CCTV camera, standalone DVR recorder for cctv camera,but also produce popular megapixel network IP cameras, NVR recorder for IP cameras too.Besides, Ailipu Technology Co., Ltd already developing its own special USB Cameras for industrial vision. Recently, Ailipu company present new USB cameras module range from 30W Pixel, 1megapixel, 2megapixe, 3megapixel, 5 megapixel to 5megapixel autofocus, which already used in all kinds of industrial system. We can also OEM or customize products specially by customers' requirements. Contact us Any questions please feel free to contact us by ebay message. We'll reply you within 12 hours as time difference. On Aug-12-15 at 21:55:10 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Type	mini
Max. Resolution	2592 (H) *1944 (V)
Connectivity	Closed System/CCTV-Wired
MPN	Does Not Apply
Color Mode	Color
Sensor	OV5640 (1/4inch )
Brand	ELP
AGC/AEC/AWB/ABF	Auto
Features	5MP
Output Formats	YUYV/MJPEG
High Definition	5MP
UPC	Does not apply
