5pcs Lm2596s-adj Dc-dc Buck Regulator Power Module 3a Adjustable 5v/12v/24v

US $10.19

ShenZhen, China
Sep 2nd

Open on mobile:
QR code

sunshinylight04 Product Description Description: Descriptions: 1. LM2596 chip module uses high-quality , high efficiency (up to 92% ) , heat a small , can easily bring up 3A ( short ) over current, long working hours is recommended for use in less than 2.5A current , while adding fins (10W output above ) . 2. This module uses machine placement, reflow soldering, and each module before shipment after two hours of aging test, to ensure high reliability. 3. Input voltage range: DC 3.2V-40V (input voltage output voltage must be higher than 1.5V or more. Could not boost) 4. Output voltage range: 1.25V-35V DC voltage is continuously adjustable, high efficiency (up to 92%) the maximum output current of 3A. Specifications: Module property Non-isolation step-down (BUCK) Rectification mode Non-synchronous rectification. Input voltage 3.2V-40V Output voltage 1.25V-35V Input current 3A(maximum) Switching frequency 65KHz The output ripple 30mV(max.) Conversion efficiency 92%( highest) Load regulation ±0.5% Voltage regulation ±2.5% Work temperature -40 -- +85 Size 42*20*14(L*W*H)(mm) Note: 1. Long working hours is recommended for use in less than 2.5A current, while adding a heat sink (10W output above); due buck module, in order to ensure stable output, keep a minimum 1.5V differential. 2. This module is adjustable buck module; the module can be adjusted above sinking blue adjustable resistor to change the output voltage. Input and output pressure is 2V; the minimum can be output 1.25V voltage. 3. Modules indicated above IN-( negative input ), IN + ( positive input ), OUT-( negative output ), OUT + ( positive output ) be sure to pick the correct , otherwise it may cause damage to the module . 4. This module has no output short circuit protection, output short circuit if prolonged, may result in damage to the module. Included: 5 x Regulator Power Module pictures

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
MPN	Does Not Apply
Type	Other
UPC	Does Not Apply
EAN	Does Not Apply
