5v Dc Stepper Step Motor And Driver Test Module Board Uln2003 For Arduino

US $470

United States
Jan 29th

Open on mobile:
QR code

Description Please Click Here to Buy It Now~ Product description: 1, board size: 38mm X 30mm 2, Use ULN2003 drive chip,500mA 3,In stepping motor port,four channels highlight SMD green LED diode indicates working status 4, In DC motor port,one channel highlight SMD green LED diode indicates working status 5, Power light:highlight red SMD LED diode 6, Equipped with stepping motor standard interface and DC motor standard interface,can directly call waiting when using Wiring method: The wiring method for stepping motor: Left 1 N 1 ~ 1 N 4 connect to the four corresponding IO wires of MCU The right black pins are defined from top to VCC,A,B,C,D (connect to the concentric line,phase A,B,C,D of stepping motor)s The wiring method for DC motor: Left 1 N1 ~ 1 N 4 connect correspondingly to the four IO wires of MCU The right black pins are defined as:below is VCC Power supply method: Connect short circuit hat, choose 5V as the working voltage for stepping motor/DC motor Take off short circuit hat, stepping motor/DC motor can choose external voltage for power supply via pins Speed down stepping motor Diameter:28mm Voltage:5V Stepping angle:5.625 X 1/64 Speed reduction ratio:1/64 Five lines four phases,can be driven by common uln2003,can be used as connecting two phase;can be used with PCB board,direct plug and socket,easy to use on PCB board Package include: 5V DC Stepper Step Motor + Driver Test Module Board ULN2003 For Arduino * 1 Shipping Item will be processed in 24-48 working hours after payment received. US buyers Item will be shipped out from US STOCK. Ecomony shipping: 5-10 working days Standard shipping: 2-5 working days. International buyers Item will be shipped out from ASIA STOCK. Economy shipping: 21-28 working days. Payment We accept Paypal only. All major credit cards are accepted through secure payment processor Paypal. Payment must be received within 14 days of auction closing. If you have bought multiple items from me, you can send me one payment for all the items instead of paying for them individually. When you click the Pay Now Button, eBay will automatically determine if there are other items you have won or purchase from me and will combine them for your review. Warranty and Return Policy 12 months warranty. 30 days money back. Buy with confidence. If you are not satisfied when you receive your item,please return it within 30 days for a replacement or money back. Please contact me before you return it. If item is defective in 3 months, we will send you a replacement without extra charger,or offer refund after we receive the defective item. If item is defective after 3 months, you can still send it back to us. We will send you a new one after receiving the defective item.But you have to pay the extra shipping fee. Contact us We are here from Monday to Saturday,9:00 am - 18:00 pm If you have any questions about the order and product,please feel free to contact us! Engineered for professional eBay sellers! On Dec-08-14 at 18:18:45 PST, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded/Generic
Country of Manufacture	China
