5v-ready-spi 1.5" Full Color Oled Module For Arduino / Avr / Pic / Stm / Arm /pi

US $19.99

ZheJiang Prov., China
Jun 9th

Open on mobile:
QR code

SPI 1.5" Full Color OLED Module for Arduino / AVR / PIC / STM / ARM UG-2828GDEAF02 (1PCS OLED panel+1PCS driver Module) This is a [5V Ready] 1.5" OLED module, supporting up to 128RGBx128(full colors) dot matrix display. Brand New, Ready to go. Good for DIY using. Panel ID: UG-2828GDEAF01 Panel Manufacturer:Uni-vision Technology Inc. Interface & Specification: Supply:3V3~5V. Logic:3V3~5V. Max Colors:262,144 Colors. Matrix:128(RGB)x128 Interfaces:4-wire SPI View Angle:almost 180 degree. PCB szie:36.00mm x 36.00(mm) PCB color:Black Weight:10.0g Pins list: GND VCC (3V3~5V) EN(for HV) CLK DIN DC CS RST Resources: Arduino UNO sources code (working in 64K Mode) Download it from: http://oled.jimdo.com Source code is programmed and fully tested by myself,worked well. Please download the correct source shown blow: http://vfdclock.jimdo.com/app/download/8890237769/Ug2828GDEAF01-CODE.rar http://oled.jimdo.com/2013/10/07/ug-2828gdeaf01-oled-module-for-arduino/ http://oled.jimdo.com/2013/12/15/show-3d-text-on-ug-2828gdeaf01-oled-module-for-arduino/ (Do not get the UG2828-GDEAF02 Module source code,they are different panels !!!!!) Source code from iplayfast: https://github.com/iplayfast/OLED-UG-2828GDEAF01-Display Tips: 1. Take care of the panel's FPC part,do not band it too hard,and don't band it frequently. 2. Don't open&close the FPC socket frequently. For other resources like datasheet in PDF format: http://vfdclock.jimdo.com/2013/08/07/1-5-oled-full-color-display-datasheet/ (Do not use the UG2828-GDEAF02 Module source code,they are different panels !!!!!) sample Video: Notice:Video camera causes the flicker rolling bar. http://youtu.be/F23GctIk4H4 http://youtu.be/y68OrPusJgo Contains: 1PCS OLED Module (1PCS Board+1PCS panel),no other stuffs. This is ready to go module,no soldering is needed,you connect it with your ARDUINO UNO,and download the sample program, and run... Module will be fully tested by myself before shipping. We may not be able to provide extra technology support except all the datasheet and src as shown. Thank you for your understanding! Extra: 1.For 1PCS OLED PANEL(Panel only,no driver board)+1PCS FPC socket. +9.99 USD. Notice: Please note that we may need about 3~5 working days for assembling it after payment is received. Payment methods: We ONLY accept PayPal on eBay selling, other payment is not acceptable. Please PAY within 7 days, or we'll re-selling the item. Shipping: We ship to American via ePacket Delivery with tracking number; We ship to Other countries/locations via International Economy Package with tracking number; For shipping to The United Kingdom or Australia or Russian Federation, we strongly recommend you update to the EUB(express); Price for updating to the EUB(express): For shipping to The United Kingdom or Australia: +5.99usd; For shipping to Russian Federation: +3.99usd; Shipping time: 10-20 working days for ePacket Delivery to the U.S.A.(normally you will receive it in about two weeks), depends on the destination location;For other far locations may need more days. Please note that International Economy Package can ship to the World wild with low price,but the transport speed is very unstable,mail delay is very normal,shipping to far locations may cost over 30 days,sometimes the cargoes will be stuck in the airport for over one month(especially in the special meeting time,it happened before). Please understand that we can't control the mail speed.If the mail delayed,please be patient. If you wanna save your time,add extra money for updating to the EMS. We ship to your PAYPAL Verified Address only; Any import tax or charges should be paid by the buyer. Tips: About the Economy Mail to the World Wide: The International Economy Package is mailed to the destination country by CHINA POST and delivered via the local postal system. Delivery time is usually between 14 to 30 business days. Usually delivery status is traceable on the post office website of CHINA POST and(or) the destination country post office website. China Post Office tracking website: http://intmail.183.com.cn/ But sometimes,on those web sites,you can track 0 info or just the info that when the goods are transported inside CHINA. Especially shipping to the far locations,just be patient. For the Economy Mail,if we got the Tracking number for you,it means that the goods are already in the post office. If you have not received the goods in 30 days,notice us,we will ask for the detail tracking information via the local post office.

“DIY stuff,I designed and made it by myself.”

Brand	Unbranded/Generic
MPN	Does not apply
Model	UG2828GDEAF01 OLED MODULE ARDUINO
Country/Region of Manufacture	Unknown
UPC	Does not apply
