HC-SR501 Body Infrared Motion Sensor Module Pyroelectric PIR LHI778 Sensor Click To Enlarge Top Descriptions HC-SR501 Body Infrared Motion Sensor Module Pyroelectric PIR LHI778 Sensor SKU:F33# Description Technical parameters: 1. Operating voltage: DC5V to 20V 2. Static power consumption: 65 microamps 3. level output: high-3.3V, low-0V 4. Delay Time: adjustable (0.3 seconds to 18 seconds) 5. embargo time: 0.2 seconds 6. Trigger: L can not be repeated, H can be repeated, the default value of H 7. sensing range: less than 120 degrees angle, 7 meters 8. Operating temperature: -15 ~ +70 degrees 9.PCB Dimensions: 32 * 24mm, the screw hole distance 28mm, screw diameter 2mm, sensor lens size: (diameter): 23mm Features: 1. automatic induction: When some people enter into its high sensing range, sensing range of people leaving the automatic delay off high. Output low. 2. photosensitive control (not installed) can be set during the day or light intensity without induction. Module is reserved for position sensitive resistor is not installed. If required, Install at your own photoresistor.- Contact us,We can help provide resistance 3. Two trigger modes: L can not be repeated, H can be repeated. Can be jumper selected, the default is H. A. trigger can not be repeated: the sensor output high, the delay time is over, the output will automatically from high to low. B. repeatable trigger: the sensor output high after the delay period, if human activities in its sensing range, the output will remain high until after the delay to leave the high Level goes low (sensor module detects the human body every activity will be automatically extended after a delay time and the time of the last event the starting point for the delay time). 4. with induction blocking time (the default setting: 0.2 sec): induction module, after each sensor output (high to low), can be followed by a block of time set in this period of time not to receive sensor Any sensor signal. This feature can be achieved (the output time and the blockade of induction time), the interval between the work can be applied to interval detection products; the same time this feature can inhibit the process of load switching for a variety of interference. 5. Working voltage range: DC5V to 20V operating voltage by default 6. Micropower: 65 microamps quiescent current, particularly suitable for battery-powered appliances. 7. output level signal: easy docking with the various types of circuits. Package list: 1 * HC-SR501 Body Infrared Motion Sensor Module NOTE We try our best to make every transaction perfectly, just for winning your Five-Star rating. If you have any dissatisfaction, please contact us, we will give you the most satisfactory results. PLEASE don't leave a neutral or negative easily. Shipping Item will be shipped within 24 hours on payment received from Hong Kong using Airmail. Only shipped to buyer's PayPal address, please confirm with your PayPal address before you bid. Delivery time depends on destination and other factors, it may takes up to 30 business days. Optionally, Express Shipments with tracking service via EMS/DHL/UPS with a quoted delivery time of 5 to 7 business days is also available . Here is the estimated time for your reference only: Country Delivery Time Working Days (not including holiday) 5-7 8-10 11-14 15-19 20-25 >30 Working Days + Saturday + Sunday 5-9 10-14 15-20 21-25 26-35 >40 United States Rate (item arrived) 9% 50% 21% 13% 7% Refund or Resend United Kingdom Rate (item arrived) 10% 62% 20% 3.5% 4.5% Refund or Resend Australia Rate (item arrived) 23% 50% 13% 8% 6% Refund or Resend Europe (Exclude Russia) Rate (item arrived) 2.5% 22% 42% 24% 9.5% Refund or Resend Asia Rate (item arrived) 8% 45% 35% 10% 2% Refund or Resend Canada Rate (item arrived) 0.0% 44% 35% 18% 3% Refund or Resend Russia Braizl South America Rate (item arrived) 0% 0% 2% 8% 80% Refund or Resend Return It is buyer's responsibility to contact us within 30 calendar days of receiving a defective product. Otherwise, no replacement or refund will be made. All items MUST be returned in their original condition. Buyer is responsible for shipping and proof of delivery on all returns. Payment We only accept PayPal. Payment must be made within 7 calendar days of the auction end time. Non-Paying bidders will be reported. We reserve the right to cancel your order if the payment is not made within 8 calendar days of checkout. Your partner for managing your online business NOTE We try our best to make every transaction perfectly,just for winning your Five-Star rating. If you have any dissatisfaction, please contact us, we will give you the most satisfactory results. PLEASE don't leave a neutral or negative easily.PLEASE don't open any paypal or eBay cases without communication. If not, we will refuse to do busniess with you for next time. Shipping Item will be shipped within 24 hours on payment received from China using Airmail. Only shipped to buyer's PayPal address, please confirm with your PayPal address before you bid. Delivery time depends on destination and other factors, it may takes up to 30 business days.We are not responsible for any custom duty or import tax, you need to pay for the return shipping fee if you don't custom clearance on time. Optionally, Express Shipments with tracking service via EMS/DHL/UPS with a quoted delivery time of 5 to 7 business days is also available . Here is the estimated time for your reference only: Country Delivery Time Working Days (not including holiday) 5-7 8-10 11-14 15-19 20-25 >30 Working Days + Saturday + Sunday 5-9 10-14 15-20 21-25 26-35 >40 United States Rate (item arrived) 9% 50% 21% 13% 7% Refund or Resend United Kingdom Rate (item arrived) 10% 62% 20% 3.5% 4.5% Refund or Resend Australia Rate (item arrived) 23% 50% 13% 8% 6% Refund or Resend Europe (Exclude Russia ) Rate (item arrived) 2.5% 22% 42% 24% 9.5% Refund or Resend Asia Rate (item arrived) 8% 45% 35% 10% 2% Refund or Resend Canada Rate (item arrived) 0.0% 44% 35% 18% 3% Refund or Resend Russia Braizl South America Rate (item arrived) 0% 0% 2% 8% 80% Refund or Resend Return It is buyer's responsibility to contact us within 30 calendar days of receiving a defective product. Otherwise, no replacement or refund will be made. All items MUST be returned in their original condition. Buyer is responsible for shipping and proof of delivery on all returns. Payment We only accept PayPal. Payment must be made within 7 calendar days of the auction end time. Non-Paying bidders will be reported. We reserve the right to cancel your order if the payment is not made within 8 calendar days of checkout. On Sep-27-14 at 23:01:41 PDT, seller added the following information:
