6" 3 -jaw Reversible Jaws Chuck W. 1-1/2 X 8 Aapter

US $129.00

  • Schaumburg, Illinois, United States
  • Jan 30th
6" Precision 3-Jaw Self Centering Reversible Jaws Lathe Chuck with 1-1/2 x 8 Back Plate 3 - Jaw Chuck: Brand New Semi Steel Body, Diameter 6" Chuck Center Hole: 1.772" Chuck Thickness: 2.56" Bolt Circle Diameter: 5.591" Chuck Back Recess : 5.11" (Diameter) x 0.197" (Depth) Clamping Range:      Inside Jaws:                     Clamping Range: 0.118 - 2.165"                     Jamming Range: 1.968 - 6.299"     Outside Jaws:                   Clamping Range: 2.165 - 5.709"  Both Top Reversible Jaws and Bottom Master Jaws are Forged, Machined, Precision Ground and Hardened to RC 58 -62 Supply with Chuck Kay Back Plate: Diameter: 6-1/4" Spindle Mounting Threaded Hole: 1-1/2" x 8 The buyer have to do some machining work to put the 3-Jaw chuck and the back plate together Payment: Paypal is preferred, We also accept VISA, MasterCard, AMEX and Discover.   Return: Upon receipt, if found defective, please contact us.  we will arrange the return or credit   Shipping: Will ship out within 24 hours by UPS or USPS
