600w Wind Turbine Generator Dc 12/24v+600w Wind/solar Hybrid Charge Controller A

US $59000

CN, China
Jan 30th

Open on mobile:
QR code

600W Wind Turbine generator DC 12/24V + 600W 12/24V Wind/Solar Hybrid Charge Controller 12V system or 24V system in stock. pls leave us a message Feature detais: Low start-up wind speed Low wind speed series wind turbines generate more than 60% effective power than the same rotor diameter wind turbine annually. High-efficient Generator permanent magnet synchronous wind turbine,more than 10% of the efficiency of ultra-GB,starting resistance,only be 1/3 of the GB limit,motor insulation rating class H insulation. Perfect Wind Wheel System The wind turbine wheel are made of a low temperature resistance,aging high strength compound material,can cope with a variety of complex wind conditions,charge wind energy into electrical energy efficiently and sustainably.. Unique Design Of The Rudder Wind turbine rudders are ale to respond to the wind speed and wind direction flexibly,enhancing the efficiency of power generation. Technical Parameter Model SG-600 Rated Power 400W AC voltage AC 12V/24V Rated DC Voltage DC12V/24V Rated Current 33A/17A Rated Speedy 900r/m Max Power 600W Number of blade 3 PCS Start-up wind speed 3m/s Cut-in wind speed 3.5m/s Cut-out wind speed 15m/s Rated wind speed 12m/s Rotor diameter 1230mm Blade material Carbon fiber with nylon Output line anti-winding device Overall three-phase commutator Wind protection Tip stall protection+turned protection+electromagnetic brake Life span 20years Equipment surface protection Aluminum oxide+plastic coating Working temperature -40°C to 70°C Weight 8.5kg Package dimension 672mm*350mm*210mm Power Curve Monthly Power Generation Cure Drawing Picture The controller user’s manual is suitable for 600W 12V wind turbine generator system. 1 Automatic dump load while the wind turbine generator overload. 2 Batteries overcharge protection. 3 Protect cable connect to batteries inverse. 4 Protect batteries charge to solar panel. at night 5. Protect electric shock. Technical specifications : Model SG-W600 Rated voltage(V) 12 Vor 24V Rated current of wind-generator(A) 37A or 13.5A Battery over discharge protection voltage 10.5V or 21V Battery over discharge recovery voltage 11.5V or 23V Final charge voltage(V) 14.4 Vor 28.8V Floating voltage(V) 13 V or 26V Recover time of braking 30min Allowable ambient temperature (℃) -20~40 Dimension(mm) 208x140x74 Weight(g) 1500g 3?Installing steps 3.1 Panels: 3.1.1 Terminals in accordance with the upper part of the label, the right equipment connected to cable: W1?W2?W3:Input terminals of wind turbine generator (Regardless of sequence); S+:Means nothing S-:Means nothing B+:Batteries + B-:Batteries - DC+:Means nothing -1 :Means nothin-2 :Means nothing 3.2 Installing steps 3.2.1Controller based on its protection level, housed in indoor and outdoor drying, ventilation, the controller may not be around the inflammable and explosive materials 3.2.2 Controller should be mounted vertically, hanging solid. 3,2,3 Unloading an external device, due to unloading, the equipment surface temperature will exceed 85 ℃, must be firmly placed on the location where not to be touched easily, meanwhile to maintain a well-ventilated, non-flammable, explosive goods. 3.2.4 Before wiring, to put the first wind turbine brakes manually switch to the "?"position, when wiring to prevent electric shock accidents caused by running generators. 3.2.5 Check the wiring correct, to put the wind turbine brakes manually switch to the "O" position, equipment into operation Security Warning: the boot before the battery must first access controller may not be the case without the battery running generator, or generating units and the controller will cause damage! 3.3 Running state, indicator function setting 3.3.1 Running indicators Controller in operation mode, the indicator will show the different status of the operation of equipment, detailed in the table below: Internal dump load State Explanation L1?L2?L3(Green) Lights Full battery capacity L1?L2 (Green) Lights Normal battery capacity L1 (Green) Lights Low battery capacity L1 (Green) Blinks Battery exhausted (Green) Lights Wind turbine generator is working ≈ (Red) Lights Dump load (Green) Lights Means nothing (Green) Lights Means nothing 4.0 Notes 4.1 Ordering Information 4.1.1 Order should be detailed description of equipment configuration requirements, such as: generator sets parameters, the choice of external dump loading devices, protective grading, as well as overload protection. 4.1.2 Use under special conditions, can be customized in accordance with the usage conditions of users. 4.2 Installation Notes 4.2.1 Before accessing controller to confirm the system equipment, such as, wind turbine, batteries, lightning protection devices, cable selection configuration is correct, accurate installation. 4.2.2 Check-to-ground insulation resistance of equipment should be in line with the wind / light generating system of technical requirements. 4.2.3 Installation, disassembly, repair equipment, wind turbine will be sure to manually switch the brake to the "|" position. 5.0 After-sales service 5.1 Customers in the procurement, use, or for advice on the quality of this product can contact the designated distributors or with the company. Quality warranty: 1. CE TUV and ROHS certificate 2.12 month warranty 3. the buyer is responsible for the return post mail cost 4.15 days refund and 20 days exchange after receiving the product Payment: 1. We prefer you can pay via paypal, thank you ! 2. pls pay within 5 days after winning the auction or buying. Contact : you can contact us via email , we will reply you within 24 hours Engineered for professional eBay sellers!
