84x48 Nokia 5110 Lcd Display Module Blue Backlight With Adapter Pcb Brand New

US $98

shenzhen, China
Jan 29th

Open on mobile:
QR code

Product Name: 84X48 Nokia 5110 LCD Display Module Blue Backlight with Adapter PCB Brand New More Items In Our Store,Click Here! Dera customer, Welcome to share us with the effect display We can offer you more discount or gift if you send us! 1.Parameters 1>.Power supply voltage:2.7V-3.3V 2>.Data interface level:2.7-3.3V 3>.Backlight power supply voltage:highest 3.3V 4>.Module size:43.6mm x 43.1mm(width X height) 5>.Installation diameter:2mm 2.Connection 1>.RST--------- reset 2>.CE---------- chip selection 3>.DC---------- data/commands choice 4>.DIN--------- serial data line 5>.CLK--------- serial Clock Speed 6>.3.3V-------- VCC 7>.LIGHT------- backlight control terminal 8>.GND--------- power negative 3.Features: 1>. 84 X 84 dot matrix LCD,can show 4 lines of characters 2>. Use serial interface communicate with the master processor,the number of interface signal line reduced greatly, only 8 signal lines including power and GND.Support different types of MCU,such as the arduino,AVR,PIC,STM32,STC MSP430 and so on.Transfer rate up to 4Mbps,can full speed write display data without waiting time. 3>. Can use the conductive glue to connect the module with the printed board,without connecting cable.The metal hooks on the module can fix the module on the printed board,which is very easy to install and replace. 4>. LCD controller/driver chip has been bound to LCD chip,the volume of LCD is small 5>. Low power supply,the working current in normal situation is lower than 200?A,and has power-down mode Material Download here! Maybe you also need the following parts 1PCS 12864 128X64 Dots Graphic Matrix LCD Module Display LCM Blue Backlight. 5pcs 1.8" Serial SPI TFT LCD Module Display 128X160 + PCB Adapter with SD Socket. 2.2" 2.2in SPI TFT LCD Module Display + PCB adapter. 1PCS 3.5" TFT LCD Module Display + Touch Panel + PCB adapter. 3.2" TFT LCD Module Touch Panel + TFT 3.2" LCD Shield Expansion Board New $9.42 + free shipping $35.85 + free shipping $7.96 + free shipping $22.66 + free shipping $24.54 + free shipping STC(51)-MCU PIC-MCU AVR-MCU ATMEL-MCU STM32-MCU C8051F-MCU MSP430-MCU Crystal Oscillator IC Socket DIY PCB Universal Board Dupont Line Digital tube Buzzer Arduino UNO board PIC Programming unit AVR ATMEL Programming unit Connector Kit USB to TLL Modules Power Modules LCD Modules RS232 TO TLL Moudle For more quantity, please contact us 1) We accept PayPal payment ONLY. inkFrog Analytics On Apr-29-14 at 23:09:39 PDT, seller added the following information:
