A50r-3 Resilmount Hanger Clips, 250/box, Suspended Ceiling Acoustical Isolation

US $875.00

Congers, New York, United States
Jan 30th

Open on mobile:
QR code

Note The difference between the A50R-1, A50R-2 & A-50R-3 hanger clips, is the load capacity. Each of these clip types are listed separately on eBay. Clips Load Capacity Guide: u A50R-1 Clips, Load Capacity is: 65lbs (eBay Item No. 190931270440) u A50R-2 Clips, Load Capacity is: 120lbs (eBay Item No. 190931277820) u A50R-3 Clips, Load Capacity is: 200lbs (THIS LISTING) What You Are Buying You are buying 1 full box of A50R-3 Resilmount Clips. There are 250 clips included in this box. Each identical clip is new. Application Resilmount™ A50R-3 is specifically designed for the support and acoustical isolation of internal suspended ceiling systems. Features Easily works with all hanger wire Easy installation into new or existing ceiling systems Meets all Standards and guidelines Does not reduce the load capacity of the ceiling system Suitably isolates the ceiling system from the structure to reduce structure-borne noise Elastomer Type: Natural Rubber Shore A Hardness: 65 Load capacity: 200 Lbs. Dynamic Characteristics Rubber mounts differ from spring mounts is that the natural frequency is a function not only of the deflection but also of the rubber hardness. The noise absorption properties of the Resilmount™ A50R-3 allow it to deflect 3/16” when loaded to 200 lbs., in accordance with US Standards, which provided optimal isolation of transferred noise. Installation Notes When selecting hangers, it is recommended that the calculated mass of the ceiling system is increased by 10-20% to avoid overloading of the isolation element. If maximum rated deflections are required, the ceiling system needs to be accurately weighed and point loads assessed in accordance with the architectural specifications of the project. The site contractor can undertake normal installation procedures of the suspended ceiling system. Once the hanging rod has been hung from the substrate, the lower end of the rod needs to be bent up in accordance with the ceiling system manufacturers specifications, providing a ‘hook’ on which the Resilmount™ A50R-3 can be hung. Once the mount is in place, another section of hanging rod is required to be bent and inserted through the lower side of the Resilmount™ A50R-3. The shaft of this rod then becomes the mounting point for the ceiling suspension clip.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Resilmount Sound Isolation Solutions
MPN	A50R-3
Model	A50R-3
Country of Manufacture	Australia
