Access Control Semi-auto Cylinder Swing Gate

US $575.00

Sell direct from factory, China
Jan 30th

Open on mobile:
QR code

Click For More Access Control Semi-Auto Cylinder Swing Gate Technical Specification : Description Parameter Power Supply Input AC110/220V±10%, 50HZ Working Voltage 24V DC Electro-magnetic drive: 24V DC Housing 2.0mm thickness Stainless Steel Polishing: Brushed surface (Standard) / Polishing surface Product Weight: About 16KG Dimension ?168*1050mm Swing Arm Length 500-900MM( Standard 600mm) Max Tolerance of Swing Arm 60KG Swing drive angle 180 Degree Swing direction Single or Double (adjustable) Drive motor Brushless DC motor 140W/24V Mechanical life: Two million Use age 8 Years Transit Speed 40 persons/min(open often), 25-30 persons/min(close often) Opening/Closing Time 1 - 2 seconds Time needed after Power 3 seconds Automatic reset time after fault 10 seconds Working Temperature: -30°C~50°C Protection Level: IP45 Relative Humidity (RH): 5%-90%(without concretion) Interface: RS485 Control I/O: ±12V electrical level signal or DC12V pulse signal of pulse width >= 100ms Features: 1. Compact appearance,adapt to varied situation(no install place for card reader ), Reliable and durable, low noise and stable operation; 2. Standard electrical interface, various card reader acceptal to our swing gate & can be controlled by computer, Single/Double Directional Optional which can be controlled by both ways or single way; 3. When power off, the gate will be dropped down (optional set free passage when power off) to the request of fire protection, and automatically closes when power on; 4. Surface of mechanical electroplated with yellow dichromic acid, antirust and durable; 5. The swing gate installed Infrared sensor interfaces, could be expanded to Infrared testing function. 6. The horizontal bi-directional movement of the arm allows patrons to pass smoothly through the ADA swing gates, prevent pedestrians from being nipped and from being hurt; 7. Breakdown Self-checking and alarm indication, easy for maintenance and using; 8. The motor will stop working in case of the swing encounter of obstruct; 9. The swing gate arm will lock in case of not receving the open signal; 10. Arms synchronization. (adjustable): Arms are automatically locked until opening signal is received; 11. Anti illegal entering alarm: Light and sound alarm is generated when the illegal invasion and the tail followed; 12. Automatically reset function: It will automatically lock if the pedestrian hasn't pass through the channel in the pre-set time after the opening. The passing time is adjustable; Applications: 1. Cylinder Swing Gate was specifically designed for persons with disabilities. It has an innovative design to enable quicker and easier passage and to fit into tight spaces. Its cabinet was designed to withstand the impact of wheel chairs and carts. It can be for one-way and two-way, pedestrian traffic control. Operation in either a 1 x 90° or 2 x 90° bi-directional mode. These gates are also used to complement our turnstile and optical turnstiles especially where passage of larger items is required.With an opening of up to 900mm, items such as wheelchairs, trolleys and oversized packages are easily accommodated. 2. Cylinder Swing Gate is suitable for both indoor and outdoor(tent). It could be wildly used in the place where intelligentized management is needed such as station, port, subway, factory, mansion, intelligent community, hotel, club, marketplace, enterprise and institution etc. Turnstile accessories: ? Cylinder Swing Gate Mechanism (I single Mechanism) ? Cylinder Swing Gate Housing(304#stainless steel at 2.0mm) ? Cylinder Swing Gate Control Board ? Cylinder Swing Gate Power Supply ? Backup storage battery ? Traffic Indicator ? Passage Status Lights(option) ? correlation infrared(option) Visit Our Store And See Other Items! Add to Favorite Sellers!! Payment: 1.We accept payment via PayPal or HSBC 2,Payment must be received within 7 business days of auction closing. 3.All major credit cards are accepted through our secure payment processor PayPal. Shipping : 1.The product will be shipped via Express logistics(default), the period is about 3 - 6 working days. 2.If you order more items, or the package of Vertical Tripod Turnstiles is more than 1 cubic meters , then it should be shipped by sea freight, customer who want to buy please contact us to check exact the cost of sea freight(we need your specified sea port), 3. we put this advertisement specially for integrator or installer, if you have large amount demand, we could offer better price for bulk purchase. Notice: the delivery period of sea freight normally takes 30-40 days. Top Warranty& Policies: 1.Any durty fee will be paid by the buyers. 2. We have warranty of 1 year after installation, after 1 year, we could provide spare parts at basic cost, according to our experience, the earliest hardware system operated on market has been running for about 8 years and still works very well, so we are confident to sell this system. 3.Due to it is international shipment and will be expensive to return the goods to our factory(even the fault rate is very low), you need to provide Videos, pictures and report if you found the turnstiles is defective(such as a scratch or a dent but still can work) or not working at all, we would also take videos, pictures as proof before delivery, in case any man made mistake during installation, we need to discuss certain percentage compensation or full refund(if it is our fault), or replace some new spare parts(buyer pay for the shipping cost, because you don't need to pay returning cost any more). Contact us : 1.welcome to wholesale and purchase,If you have any question ,Please contact us via eBay message 2.We will reply you within 24 hours.(except weekends and holidays). Visit Our Store And See Other Items! Add to Favorite Sellers!! Top Copyright Hkesuppier 2008. All rights reserved. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
